COUNTING SCALE User and Service Manual
Model: CCT10/CCT20
Please read this manual carefully before operation
----General Precautions
----Operating condition and other attentions
----Warranty
GRAVITY MEASUREMENT, INC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCT10 and is the answer not in the manual?

Questions and answers

Related Manuals for Gravity Measurement CCT10

Summary of Contents for Gravity Measurement CCT10

  • Page 1 COUNTING SCALE User and Service Manual Model: CCT10/CCT20 Please read this manual carefully before operation ----General Precautions ----Operating condition and other attentions ----Warranty GRAVITY MEASUREMENT, INC.

  • Page 2: Important Safety Information

    CCT10/CCT20 USER MANUAL Important Safety Information READ ALL INSTRUCTIONS BEFORE USING SCALES TO ENSURE MAXIMUM SAFETY, BEST PERFORMANCE, AND TO GAIN KNOWLEDGE OF OUR SCALE, IT IS ESSENTIAL THAT YOU OR ANY OTHER OPERATOR OF THE SCALE READ AND UNDERSTAND THE CONTENTS OF THIS MANUAL BEFORE OPERATING THE DEVICE.

  • Page 3: Warranty

    Warranty starts from the date of delivery. During the warranty period, should any repairs be necessary, the purchaser must inform its supplier or Gravity Measurement. The company or its authorized technician reserves the right to repair or replace the components at any of its workshops depending on the severity of the problems.

  • Page 4: Lcd Display

    CCT10/CCT20 USER MANUAL What is inside Box AC/DC adaptor (110V) Counting scale CCT 10/20 Scale, with adhesive film covered platter. Two parts are separated to protect the load cell during transportation. Two wire seals. The wire seal is used usually by the inspector of Department of Weight and Measure or authorized dealer.
  • Page 5 CCT10/CCT20 USER MANUAL CCT20 Size: 80 mm x 71 mm X 2.8 mm, Font height: 16 mm...

  • Page 6: Control Panel

    CCT10/CCT20 USER MANUAL Control Panel COUNT UNITS ALARM COUNT SAMPLE PCS WT...
  • Page 7 CCT10/CCT20 USER MANUAL KEY DESCRIPTION for MODEL CCT10 Press and hold this key for 2 seconds to turn off the scale. Press this key briefly to turn on the scale. A self-test will run on the display and then stabilize showing zero UNITS Select the desired weight unit in setup mode.
  • Page 8 CCT10/CCT20 USER MANUAL Accumulate weight and count. The piece weight window briefly shows -r01-- -- . The scale can accumulation up to 99 times. In the setup mode, it means enter (confirmation). Display total accumulated count,total accumulated weight, and total count.
  • Page 9 CCT10/CCT20 USER MANUAL Press 【M+】key to enter，display A A u G 1 (default UF-2 Piece weight auto- average factory setting） ，Use 0 and 1 keys to enable or disable auto-average function, Press 【M+】key to confirm， press 【CE】key to exit A A u G 0 ：Disable A A u G 1 ：Enable...
  • Page 10 CCT10/CCT20 USER MANUAL S P E E d 0 ：low speed (factory default), 7.5 Hz S P E E d 1 ：standard speed, 15 Hz S P E E d 2 ：High speed, 30 Hz Press 【M+】key to confirm, and press 【CE】key to exit.

  • Page 11: Error Messages And Troubleshooting

    CCT10/CCT20 USER MANUAL Error Messages and Troubleshooting Error Display Meaning h h h h h h Overload Weight on pan exceeds maximum capacity L L L L L L Weight is too low Weight is too low at the negative...
  • Page 12 CCT10/CCT20 USER MANUAL At setup mode, Function at Set up 【M+】 Enter (Confirmation) 【Z】 Move up 【T】 Move down 【CE】 Clear entry or exit Press 【Z】and the 【M+】 to start Standard Calibrations ECF-1 Weight Calibration (Zero and Span) ECF-2 Zero Calibration ECF-3 SPAN Calibration Press 【M+】to confirm, and Press 【Z】...
  • Page 13 CCT10/CCT20 USER MANUAL E C F - 2 Zero Calibration Step 1: Press 【M+】to start (Press 【CE】to exit menu and back to 0 . 0 0 0 0 weighing mode). The first line (Weight window) blinks. Total count displays an internal value.
  • Page 14 CCT10/CCT20 USER MANUAL Approval Calibrations and Functions Setup (Lock section) : While turning on the scale and press and hold【Z】, release both keys after countdown sequence is completed, and L F 1 is shown on Weight window. Use 【M+】to rotate different LF functions.
  • Page 15 CCT10/CCT20 USER MANUAL LF 2 Spec Calibration : Step 1: Press 【M+】to start (Press 【CE】to exit menu and back to 0 6 0 0 0 0 weighing mode). D p 4 Enter the maximum capacity. Use the UNITS key to select calibration D i u 2 weighing unit.
  • Page 16 CCT10/CCT20 USER MANUAL...
  • Page 17 CCT10/CCT20 USER MANUAL Gravity Measurement, Inc. 611 Rotterdam Industrial Park Schenectady, NY 12306 Tel: 518-526-5942 http://www.gravitymeasurement.com GRAVITY MEASUREMENT, INC.
