MOUNTING THE CONTROL PAD AND CAMERA ARM

Expect to spend about two hours on this installation.

PLANNING FOR WIRING

CopyCam has three cable connections that converge in the camera
arm, as shown below.
Control pad
with floppy drive
CopyCam wiring can be either:
against a wall, the typical approach for adapting an existing
•
facility, or
within a wall, a potential for new construction or renovation
•
NO TE : NO TE :
Use the positioning templates provided to assure proper location of
the control pad and camera arm. Failure to do so may result in
inhibited access to the floppy disk drive in the control pad, or in
incomplete copies of the board.
MOUNTING THE CONTROL PAD AND CAMERA ARM
Camera arm
Power
adapter
rn e t
10 0 B a s e T E th e
7
