Weiro ARC-400 Operation Manual

Inverter dc mma welding machine

Hide thumbs

Table Of Contents

Quick Links

THANKS FOR PURCASHING OUR PRODUCT

ARC - 400

INVERTER DC MMA WELDING MACHINE

W E I R O

OPERATION MANUAL

(Read the manual carefully before installation, operation and maintenace)

Safety Depends on You

WEIRO are welding and cutting equipment is designed and built with safety in mind.

However, your overall safety can be increased by proper installation... and thoughtful

operation in your part. DO NOT INSTALL, OPERATE OR REPAIR THIS

EQUIPMENT WITHOUT READING THIS MANUAL AND THE SAFETY

PRECAUTIONS CONTAINED THROUGHOUT. And, most importantly, think

before you act and be careful.

C V . A N U G R A H D U T A N I A G A

Jln. Arief Rahman Hakim 51 Komplek Ruko 21 Klampis Blok D-1

Telp. 031 – 5990089, 5997259 (Hunting)

Fax. 031 – 5966099

Email : adn_office@yahoo.com

Table of Contents

Need help?

Do you have a question about the ARC-400 and is the answer not in the manual?

Questions and answers

Summary of Contents for Weiro ARC-400

Page 1 (Read the manual carefully before installation, operation and maintenace) Safety Depends on You WEIRO are welding and cutting equipment is designed and built with safety in mind. However, your overall safety can be increased by proper installation... and thoughtful operation in your part. DO NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT WITHOUT READING THIS MANUAL AND THE SAFETY PRECAUTIONS CONTAINED THROUGHOUT.
Page 2: Table Of Contents
ARC-E 400 Index 1. Principle &Technical data…………………………………………( 1 ) 2. Features & Applications…………………………………………...(6) 3. Installation Guide………………………………………………….(7) 4. Operating Instruction …………...………………………………...(10) 5. Repair & Maintenance…………………………………………….(13) Appendix A: EMC Suggestion for installation and use of welder…….(16) Appendix B: Feedback Form………………………………………….(19) This operating manual can be fit for ARC-E (include ARC-E-315/400/500) series welding machines.
Page 3: Principle &Technical Data
ARC-E 400 Principle & Technical data ARC-E series Block diagram of principle Input 3-phase 380V/50Hz Output 3 phase Rectifier & Rectifier Inverter Transformer Filter Control circuit Figure 1: Block diagram of principle This series welding machines apply IGBT soft switch inverter technology. 3- phase 380V input volt are rectified by rectifier, inverted into HF AC, reduced by HF transformer, rectified and filtered by HF rectifier, then output DC power suitable for welding.
Page 4 ARC-E 400 1. Main technical parameters Parameters Description ARC315E ARC400E ARC500E Rated input voltage 3 phase 380V±10%/50Hz Rated output capacity 10.3KW 14.4KW 20KW Rated input current Rated duty cycle Range of output current 20～315A 20～400A 20～500A Rated open load voltage Full-load efficiency Power factor（full-load）...
Page 5 ARC-E 400 2. Main circuit diagram Figure 3: Main Circuit Diagram...
Page 6 ARC-E 400 3. Components List  ARC315E /400E Item Stock No. Quantity Circuit breaker 745011-00049 C1～C3 Polypropylene capacitor 722001-00023 Q1、Q2 IGBT module 735007-00046 3-phase rectifier module (small) 735005-00009 Varistor 720021-00017 Polypropylene capacitor 722001-00070 IGBT protection board 220005-00056 Power Inductor 220149-00070 Resonance Inductor 220521-00037 Polypropylene capacitor...
Page 7 ARC-E 400  ARC500E Item Stock No. Quantity Circuit breaker 745011-00050 C1～C3 Polypropylene capacitor 722001-00023 Q1、Q2 IGBT module 735007-00068 3-phase rectifier module (small) 735005-00010 Varistor 720021-00017 Polypropylene capacitor 722001-00070 IGBT protection board 220005-00057 Power Inductor 220149-00071 Resonance Inductor 220521-00037 Polypropylene capacitor 722001-00073 Main transformer 220629-00103...
Page 8: Features & Applications
ARC-E 400 Features & Applications ARC-E series inverter arc welding machines are manufactured in line with the following standards: GB15579, 1-2004 “ARC Welding Equipments· Part One· Power Source”. This series machines are SMAW machines with different specifications of rated current: 315A, 400A, 500A, which are novelty high-efficient and energy-saving DC Arc welders, not only are used in carbon steel and low alloy steel welding, but also used in stainless steel, high alloy steel, copper, silver, molybdenum and titanium welding.
Page 9: Installation Guide
ARC-E 400 Installation Guide 1． Pre-installation 1.1 Installation Environment The ARC-E series is designed for use in adverse environments. Examples of environments with increased adverse conditions are:  In locations in which freedom of movement is restricted, so that the operator is forced to perform the work in a cramped (kneeling, sitting or lying) position with physical contact with conductive parts;...
Page 10 ARC-E 400 1.3 Power Source Connections Warning Thermal Arc advises that this equipment be electrically connected by a qualified electrician. ELECTRIC SHOCK can kill; SIGNIFICANT DC VOLTAGE is present after removal of input power. DO NOT TOUCH live electrical parts. ...
Page 11 ARC-E 400 2. Installation The machines are portably designed, can be effortlessly moved by operators without fix-up. But it should be settled in even and dry places with well ventilation. (1) Ensure the welding cable be connected to the power source firmly. (2) Adjust every knobs, and switches on the front panel to proper position in line with selected mode.
Page 12: Operating Instruction
ARC-E 400 Operating Instruction 1. Functional introduction 1.1 Front panel illustration and parts number reference Figure 5: Front Panel (1) Amp LCD (2) Protection on LED Welding machine will automatically stop working when it is overheat, and the LED will be light (3) Default Phase on LED It indicates whether the input voltage is phase missing, if default phase, the LED will be light (4) Arc-starting current regulation knob...
Page 13 ARC-E 400 (6) Welding current regulation knob Used to adjust welding current on panel (7) Welding cable (+) quick socket Connect to electrode holder. (8) Welding cable (-) quick socket Connect to workpiece. 1.2 The rear panel and parts number reference Figure 6: Rear panel (1) Specification plate (2) Input power cable...
Page 14 ARC-E 400 2. Operating instruction Turn on the air switch on the switch box, the “Normal” indication lamp will light on and cooling fan rotates. Before welding normally, set up parameters by adjusting knobs and switches on the front panel according to the selected mode. Customer should refer to parameters defined in table 5 showing below: Work piece thickness （...
Page 15: Repair & Maintenance
ARC-E 400 Repair & Maintenance WARNING: Have a qualified electrician do the maintenance and trouble shooting work. Turn the input power off, using the disconnect switch at the fuse box before working inside the machine. 1. Cautions  Rivet equipment name tag on the specified area of the case, otherwise the inside parts will possibly be damaged.
Page 16: Arc-E
ARC-E 400  Check if the input volt has the phase missing, and range are between 340~420V.  Check if the input cable is connected correctly and firmly with the power source.  Check if the welding cables are connected correctly and firmly. WARNING: Have a qualified electrician do the maintenance and trouble shooting work.
Page 17 ARC-E 400 Appendix A 1. General The user is responsible for installing and using the arc welding equipment according to the manufacturer’s instructions. If electromagnetic disturbances are detected, then it shall be the responsibility of the user of the arc welding equipment to resolve the situation with the technical assistance of the manufacturer.
Page 18 ARC-E 400 3. Methods of reducing emissions 1) Public supply system Arc welding equipment should be connected to the public supply system according to the manufacturer’s recommendations. If interference occurs, it may be necessary to take additional precautions such as filtering of the public supply system. Consideration should be given to shielding the supply cable of permanently installed arc welding equipment, in metallic conduit or equivalent.
Page 19 ARC-E 400 bonding should be achieved by suitable capacitance, selected according to national regulations. 6) Screening and shielding Selective screening and shielding of other cables and equipment in the surrounding area may alleviate problems of interference. Screening of the entire welding installation may be considered for special applications.
Page 20: Appendix B: Feedback Form
ARC-E 400 Appendix B Feedback Form Name of Company Address Contact person Title Telephone No Fax No. Email Address Company’s filed of business Comments： Thank you for taking the time to share your feedback. Your comments and suggestions will help us to serve you better.

This manual is also suitable for:

Arc400
