THANKS FOR PURCASHING OUR PRODUCT
ARC – 400SI
INVERTER DC MMA WELDING MACHINE
W E I R O
OPERATION MANUAL
(Read the manual carefully before installation, operation and maintenace)
Safety Depends on You
WEIRO are welding and cutting equipment is designed and built with safety in mind.
However, your overall safety can be increased by proper installation... and thoughtful
operation in your part. DO NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT
WITHOUT
READING
THIS
MANUAL
AND
THE
SAFETY
PRECAUTIONS
CONTAINED THROUGHOUT. And, most importantly, think before you act and be careful.
C V . A N U G R A H D U T A N I A G A
Jln. Arief Rahman Hakim 51 Komplek Ruko 21 Klampis Blok D-1
Telp. 031 – 5990089, 5997259 (Hunting)
Fax. 031 – 5966099
Email : adn_office@yahoo.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ARC – 400SI and is the answer not in the manual?

Questions and answers

Summary of Contents for Weiro ARC – 400SI

  • Page 1 (Read the manual carefully before installation, operation and maintenace) Safety Depends on You WEIRO are welding and cutting equipment is designed and built with safety in mind. However, your overall safety can be increased by proper installation... and thoughtful operation in your part. DO NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT...
  • Page 2: Table Of Contents

    Index 1. Principle &Technical data……………………………………..……..( 1 ) 2. Features Applications…………………………………………...…..( 4 ) 3. Installation Guide…………………………………………...………..( 5 ) 4. Operating Instruction …………...……………………………………( 8 )  ARC Series Operating instruction …. ………………………………..( 8 ) 6. Repair & Maintenance…………………………………………..…..(15) Appendix A: EMC Suggestion for installation and use of welder…….…(17) Appendix B: Feedback Form………………………………………….…(19) This operating manual can be fit for ARC (include ARC315 SI /400 SI/500 SI /630 SI) series welding machines.
  • Page 3 Principle & Technical data ARC series Block diagram of principle (ARC series welding machines do not have HF Arc-starting device) Power supply Output 3 phase Rectifier & Rectifier Inverter Transformer Filter Control circuit High frequency arc start Figure 1: Block diagram of principle This series welding machines apply IGBT soft switch inverter technology.
  • Page 4 1. Main technical parameters ► ARC- SI series Parameters Description Primary power 3 phase 400V±10%/50Hz voltage/frequency Rated output 10.3KW 14.4KW 20KW 27.7KW capacity Rated input current Rated duty cycle Range of output 20~315A 20~400A 20~500A 50~630A current Output voltage of 80±8V open load Full-load efficiency...
  • Page 5: Features Applications

    Features & Applications ► Features & Applications for ARC series welding machines ARC series welding machine include 315, 400, 500, 630 etc., which are novelty high-efficient and energy-saving DC Arc welders, suitable for welding mild steel, alloy steel by perfect welding performance. Features and Benefits: ●...
  • Page 6: Installation Guide

    Installation Guide Pre-installation Installation Environment This series is designed for use in adverse environments. Examples of environments with increased adverse conditions are:  In locations in which freedom of movement is restricted, so that the operator is forced to perform the work in a cramped (kneeling, sitting or lying) position with physical contact with conductive parts;...
  • Page 7 1.4.Power Supply Requirements  Input volt must be standard sine wave, effective value 400V, and frequency 50Hz.  Unbalance degree of 3- phase volt must be no more than 5%.  Power supply: Product model Power supply 3 phase 400V±10%/50Hz Min.
  • Page 8 Figure 4: Outside connection diagram of ARC series (1) Ensure firmly connection to welding cable. (2) Connect to remote controller if needed. (3) Adjust every knobs and switches on the front panel to proper position in line with selected mode. (4) Turn on the circuit breaker on the power source.
  • Page 9: Operating Instruction

    Operating Instruction ► Part one: ARC Series Operating Instruction 1. Functional introduction 1.1 Front panel illustration and parts code reference Figure 5: Front Panel (1) Amp/volt LCD  When display mode switch indicates to “Amp”: LCD displays preset open-load current value; LCD displays real welding current during working.
  • Page 10 Used to adjust welding current on panel control mode. (7) Remote control socket It is used to connect to the wire remote control box with remote control cable to adjust welding current, arc force current or down-slope time when it is on the “Remote control” mode, used to weld in extended distance.
  • Page 11 corresponding 3-phase power supply. (3) Specification plate (4) Cooling fan Cool down the heat components in the welding machine. (5) Earthing bolt To ensure operators not to be harmed and welding machine to work normally, make sure the earthing bolt grounded firmly by ground cable, or make sure the ground wire (mixed-colored) of the input power cable grounded firmly.
  • Page 12 than 40m), arc force current should be adjusted in the range of 1-7 . As to large welding current and long cable of electrode holder, where volt potential difference is very high between the two ends of cable, arc force current should be adjusted in the range of 7- 10. 1.2 The rear panel and parts number reference Figure 6: Rear Panel (1) Circuit Breaker...
  • Page 13 1.3 Remote control box Figure 7: Remote Control Box (5) “Amp” meter It displays preset value while in open load, and displays practical value of welding current while in actual working. (6) “Welding current” regulation knob (7) “Arc force current/ down-slope” regulation knob (8) Socket 1 Connect to remote control cable (5) Socket 2...
  • Page 14 Table 8: TIG welding parameters Attention: On MMA, when welding current is low and cable length of electrode holder is short (no more than 40m), arc force current should be adjusted in the range of 1-7 . As to large welding current and long cable of electrode holder, where volt potential difference is very high between the two ends of cable, arc force current should be adjusted in the range of 7- 10.
  • Page 15 2.2.3 High frequency arc-start Procedure flow sheet shows below: Pull TIG torch trigger Pre-gas flow, HF/ scratch arc-start Auto-lock /4-step Non-Auto lock/2-step Release trigger Hold on trigger Welding Welding Hold on trigger Release trigger Down-slope Down -slope 熄弧、停气 停气 fill Push trigger Release trigger Until crater fill...
  • Page 16: Repair & Maintenance

    Repair and Maintenance WARNING: Have a qualified electrician do the maintenance and trouble shooting work. Turn the input power off, using the disconnect switch at the fuse box before working inside the machine. 1. Cautions:  Rivet equipment name tag on the specified area of the case, otherwise the inside parts will possibly be damaged.
  • Page 17 power off, using the disconnect switch at the fuse box before working inside the machine. Don’t open up case uninstructed, the max volt inside machine is 600V, Never discharge high voltage to welder case with welding torch! Shut down power source before changing or repairing welding cable or torch №...
  • Page 18: Appendix A: Emc Suggestion For Installation And Use Of Welder

    Appendix A 1. General The user is responsible for installing and using the arc welding equipment according to the manufacturer’s instructions. If electromagnetic disturbances are detected, then it shall be the responsibility of the user of the arc welding equipment to resolve the situation with the technical assistance of the manufacturer.
  • Page 19 any way, except for those changes and adjustments covered in the manufacturer’s instructions. In particular, the spark gaps of arc striking and stabilizing devices should be adjusted and maintained according to the manufacturer’s recommendations. 3) Welding cables The welding cables should be kept as short as possible and should be positioned close together, running at or close to the floor level.
  • Page 20: Appendix B: Feedback Form

    Appendix B Feedback Form Name of Company Address Contact person Title Telephone No Fax No. Email Address Company’s filed of business Comments : Thank you for taking the time to share your feedback. Your comments and suggestions will help us to serve you better.
