Weiro FARC-200 Operation Manual

Inverter dc mma welding machine
Hide thumbs

Advertisement

Quick Links

THANKS FOR PURCASHING OUR PRODUCT
FARC - 200
INVERTER DC MMA WELDING MACHINE
W E I R O
OPERATION MANUAL
(Read the manual carefully before installation, operation and maintenace)
Safety Depends on You
WEIRO are welding and cutting equipment is designed and built with safety in mind.
However, your overall safety can be increased by proper installation... and thoughtful
operation in your part. DO NOT INSTALL, OPERATE OR REPAIR THIS
EQUIPMENT WITHOUT READING THIS MANUAL AND THE SAFETY
PRECAUTIONS CONTAINED THROUGHOUT. And, most importantly, think
before you act and be careful.
C V . A N U G R A H D U T A N I A G A
Jln. Arief Rahman Hakim 51 Komplek Ruko 21 Klampis Blok D-1
Telp. 031 – 5990089, 5997259 (Hunting)
Fax. 031 – 5966099
Email : adn_office@yahoo.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the FARC-200 and is the answer not in the manual?

Questions and answers

Related Manuals for Weiro FARC-200

Summary of Contents for Weiro FARC-200

  • Page 1 (Read the manual carefully before installation, operation and maintenace) Safety Depends on You WEIRO are welding and cutting equipment is designed and built with safety in mind. However, your overall safety can be increased by proper installation... and thoughtful operation in your part. DO NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT WITHOUT READING THIS MANUAL AND THE SAFETY PRECAUTIONS CONTAINED THROUGHOUT.

  • Page 2: Table Of Contents

    Index 1. Principle & Technical data………………………………………..( 1 ) 2. Installation Guide…………………………………………………...( 4 ) 3. Repair & Maintenance……………………………………………...(7) Appendix A: EMC Suggestion for installation and use of welder…….. (10) Appendix B: Feedback Form………………………………………..… (12) ·１·...

  • Page 3: Principle & Technical Data

    Principle & Technical data FARC series block diagram of principle: AC230V±10% / 50/60Hz Output 1-phase Rectifier & Rectifier inverter transformer Filter Control circuit Figure 1: Block diagram of principle This series welding machines applies HF MOSFET inverter technology. 1- phase 230V±10% input volt is rectified by rectifier, inverted into HF AC, reduced by HF transformer, rectified and filtered by HF rectifier, then output DC power suitable for welding.
  • Page 4 1. Main technical parameters ► FARC series: Model FARC180 FARC200 FARC250 Type MOSFET Inverter 1-phase AC230±10% ~ 50/60Hz Rated input voltage (V) (1-phase AC220±15% ~ 50/60Hz) Rated input capacity (KVA) 27.2 41.6 Rated input current (A) (28.4) (32.5) (43.5) Rated duty cycle @ 25℃ (%) Rated output open-load voltage (V) Range of output current (A) 20～180...
  • Page 5 2. Main circuit diagram ► FARC series: Figure 3: ARC/ARC-II Series Main Circuit Diagram ·４·...

  • Page 6: Installation Guide

    Installation Guide 1． Pre-installation 1.1 Installation Environment FARC series welding machines are designed for use in adverse environments. Examples of environments with increased adverse conditions are:  In locations in which freedom of movement is restricted, so that the operator is forced to perform the work in a cramped (kneeling, sitting or lying) position with physical contact with conductive parts.
  • Page 7 1.3 Power Source Connections Warning Thermal Arc advises that this equipment be electrically connected by a qualified electrician. ELECTRIC SHOCK can kill; SIGNIFICANT DC VOLTAGE is present after removal of input power. DO NOT TOUCH live electrical parts.  SHUT DOWN welding power source; disconnect input power employing lockout/tagging procedures.
  • Page 8 2. Installation: The input power supply of this series of welding machine is 1- phase AC 230V±10%， 50/60Hz. The switchboard with circuit breaker is needed. Connect the ground cable firmly. 3. Machine Assembling Guide: (1) Connect the welding cable firmly. (2) Turn on the power switch of the welding machine.

  • Page 9: Repair & Maintenance

    Repair & Maintenance WARNING: Have a qualified electrician do the maintenance and trouble shooting work. Turn the input power off, using the disconnect switch at the fuse box before working inside the machine. 1. Cautions:  Rivet equipment name tag on the specified area of the case, otherwise the inside parts will possibly be damaged.
  • Page 10 3. Procedure for regular checking prior to maintenance  Check if all front panel switches are on the proper positions.  Check if the input volt has the phase missing, and range are between 187~253V.  Check if the input cable is connected correctly and firmly with the power source. ...
  • Page 11 № TROUBLE CAUSES WHAT TO DO 1) Check Power switch and 1) Power switch is damaged Power on LED does not the fan 2) No electricity on the light up, fan does not run, 2) Check power supply on electricity grid no output when machine the electricity grid 3) Short circuit in the power...

  • Page 12: Appendix A: Emc Suggestion For Installation And Use Of Welder

    Appendix A 1. General The user is responsible for installing and using the arc welding equipment according to the manufacturer’s instructions. If electromagnetic disturbances are detected, then it shall be the responsibility of the user of the arc welding equipment to resolve the situation with the technical assistance of the manufacturer.
  • Page 13 welding power source so that good electrical contact is maintained between the conduit and the welding power source enclosure. 2) Maintenance of the arc welding equipment The arc welding equipment should be routinely maintained according to the manufacturer’s recommendations. All access and service doors and covers should be closed and properly fastened when the arc welding equipment is in operation.

  • Page 14: Appendix B: Feedback Form

    Appendix Feedback Form Name of Company Address Contact person Title Telephone No Fax No. Email Address Company’s filed of business Comments: Thank you for taking the time to share your feedback. Your comments and suggestions will help us to serve you better.
