- Page 1 Cobalt Digital Inc. 9913DA-AES110-RG 110-Ohm (Balanced) AES/EBU Distribution Amplifier with Remote Gain Control User Manual...
- Page 3 © 2016 Cobalt Digital Inc. All rights reserved. Contents of this publication may not be reproduced in any form without the written permission of openGear. Reproduction or reverse engineering of copyrighted software is prohibited. Patents This product is protected by the following US Patents: 4,205,346; 5,115,314; 5,280,346; 5,561,404;...
-
Page 4: Important Safety Instructions
Important Regulatory and Safety Notices Before using this product and any associated equipment, refer to the “Important Safety Instructions” listed below to avoid personnel injury and to prevent product damage. Products may require specific equipment, and/or installation procedures to be carried out to satisfy certain regulatory compliance requirements. - Page 5 Maintenance/User Serviceable Parts Routine maintenance to this openGear product is not required. This product contains no user serviceable parts. If the module does not appear to be working properly, please contact Technical Support using the numbers listed under the “Contact Us” section on the last page of this manual.
- Page 6 All openGear products are covered by a generous 5-year warranty and will be repaired without charge for materials or labor within this period. See the “Warranty and Repair Policy” section in this manual for details.
- Page 7 Environmental Information The equipment that you purchased required the extraction and use of natural resources for its production. It may contain hazardous substances that could impact health and the environment. To avoid the potential release of those substances into the environment and to diminish the need for the extraction of natural resources, Cobalt Digital encourages you to use the appropriate take-back systems.
- Page 8 Company Address Cobalt Digital Inc 2506 Galen Drive Champaign, IL 61821 Sales@cobaldigital.com Support@cobaltdigital.com...
-
Page 9: Table Of Contents
Enabling Card-edge Control ..................3-3 Setting the Output Mode ..................3-3 Specifying the Gain ....................3-3 Control and Monitoring Features .................... 3-6 Status and Selection LEDs on the 9913DA-AES110-RG ........3-6 DashBoard Menus In This Chapter ........................4-1 Status Tabs ..........................4-2 Status Tab ......................... - Page 10 Technical Specifications ......................5-2 Service Information In This Chapter ........................6-1 Troubleshooting Checklist ......................6-2 Warranty and Repair Policy ....................6-3 ii • • • • Contents 9913DA-AES110-RG User Manual...
-
Page 11: Introduction
A Word of Thanks Congratulations on choosing the openGear 9913DA-AES110-RG 110-Ohm (Balanced) AES/EBU Distribution Amplifier with Remote Gain Control. The 9913DA-AES110-RG is part of a full line of Cobalt Digital Products within the openGear Terminal Equipment family of products. You will be pleased at how easily your new 9913DA-AES110-RG fits into your overall working environment. -
Page 12: Overview
AES110-RG supports audio sampling frequencies from 32kHz to 96kHz. Cable equalization and reclocking techniques enable the 9913DA-AES110-RG to recover the incoming digital audio signal reliably. Features The following features make the 9913DA-AES110-RG the best solution for distributing digital audio signals: • 1x8 or 1x4 (high density) AES distribution amplifier •... -
Page 13: Functional Block Diagrams
This section provides a functional block diagrams that outline the workflow of the 9913DA- AES110-RG. Figure 1.1 Simplified Block Diagram — RM20-9913DA110-B Full Rear Module Figure 1.2 Simplified Block Diagram — RM20-9913DA110-B/S Split Rear Module 9913DA-AES110-RG User Manual Introduction • • • • 1-3... -
Page 14: User Interfaces
DashBoard, refer to the chapter “DashBoard Menus”. • on using DashBoard, refer to the DashBoard User Manual. Card-edge Controls The 9913DA-AES110-RG provides LEDs on the card-edge that display the status of the input signals. For More Information… •... -
Page 15: Documentation Terms And Conventions
Documentation Terms and Conventions The following terms are used throughout this manual: • “Board”, and “Card” refer to openGear terminal devices within openGear frames, including all components and switches. • “DashBoard” refers to the DashBoard Control System™. • “Operator” and “User” refer to the person who uses 9913DA-AES110-RG •... - Page 16 1-6 • • • • Introduction 9913DA-AES110-RG User Manual...
-
Page 17: Installation
Installation In This Chapter This chapter provides instructions for installing the Rear Module(s) for the 9913DA-AES110-RG, installing the card into the frame, cabling details, and updating the card software. This chapter contains the following sections: • Before You Begin •... -
Page 18: Before You Begin
Unpacking Unpack each 9913DA-AES110-RG you received from the shipping container and ensure that all items are included. If any items are missing or damaged, contact your sales representative or Cobalt Digital directly. -
Page 19: Installing The 9913Da-Aes110-Rg
Installing a Rear Module If the Rear Module is already installed, proceed to the section “Installing the 9913DA-AES110-RG”. Use the following procedure to install a Rear Module in a 20-slot frame: Locate the card frame slots on the rear of the frame. -
Page 20: Installing The 9913Da-Aes110-Rg
Installing the 9913DA-AES110-RG This section outlines how to install the 9913DA-AES110-RG in a 20-slot frame. If the 9913DA- AES110-RG is to be installed in any compatible frame other than a Cobalt Digital product, refer to the frame manufacturer’s manual for specific instructions. -
Page 21: Cabling For The 9913Da-Aes110-Rg
The inputs are internally terminated in 110ohm. It is not necessary to terminate unused outputs. Cabling Overview The 9913DA-AES110-RG is used with the following Rear Modules: • RM20-9913DA110-B Full Rear Module — Each module occupies two slots and accommodates one card. -
Page 22: Software Upgrades
The card(s) are automatically re-booted and are temporarily taken offline during the re-boot process. The process is complete once the status indicators for the Card State and Connection fields return to their previous status 2-6 • • • • Installation 9913DA-AES110-RG User Manual... -
Page 23: User Controls
In This Chapter This chapter provides a general overview of the user controls available on the 9913DA-AES110-RG. The following topics are discussed: • Card Overview • Control and Monitoring Features 9913DA-AES110-RG User Manual User Controls • • • • 3-1... -
Page 24: Card Overview
Parameter adjustments made in DashBoard are applied. This is the default setting. SW3, SW4 — Output Mode Selection SW3 and SW4 are used in conjunction to set the output mode of the 9913DA-AES110-RG. Refer to the section “Setting the Output Mode” for details. This DIP Switch is not implemented. -
Page 25: Configuring The Dip Switches
Configuring the DIP Switches This section provides a brief summary of the DIP Switches of the 9913DA-AES110-RG. Refer to Figure 3.1 for the DIP Switch locations. Figure 3.2 shows all the DIP Switches in the OFF position. Figure 3.2 DIP Switch — OFF Positions... - Page 26 SW10 Gain (dB) UNITY 3-4 • • • • User Controls 9913DA-AES110-RG User Manual...
- Page 27 SW10 Gain (dB) 9913DA-AES110-RG User Manual User Controls • • • • 3-5...
-
Page 28: Control And Monitoring Features
Control and Monitoring Features This section provides information on the LEDs for the 9913DA-AES110-RG. Refer to Figure 3.5 for the location of the LEDs. Figure 3.5 9913DA-AES110-RG Card-edge User Controls Status and Selection LEDs on the 9913DA-AES110-RG Basic LED displays and descriptions are provided in Table 3.3. -
Page 29: Dashboard Menus
DashBoard Menus In This Chapter This chapter provides a summary of the DashBoard menus available for the 9913DA-AES110-RG. Parameters noted with an asterisk (*) are the default values. The following topics are discussed: • Status Tabs • Settings Tab 9913DA-AES110-RG User Manual... - Page 30 Description Card Name AES/EBU Distribution Amplifier (110ohm) Product 9913DA-AES110-RG Supplier Cobalt Digital Product (Read-only) Indicates the serial number of the Serial Number board Software Rev #.## Indicates the software version 4-2 • • • • DashBoard Menus 9913DA-AES110-RG User Manual...
- Page 31 Control the card Alters the input gain for the specified channel. CH# Trim -15 to +15 Control (dB) How the Mode is set determines what channel(s) the Trim Control alters. 9913DA-AES110-RG User Manual DashBoard Menus • • • • 4-3...
- Page 32 4-4 • • • • DashBoard Menus 9913DA-AES110-RG User Manual...
-
Page 33: Technical Specifications
Specifications In This Chapter This chapter includes the Technical Specifications table for the 9913DA-AES110-RG. Note that specifications are subject to change without notice. The following topics are discussed: • Technical Specifications 9913DA-AES110-RG User Manual Specifications • • • • 5-1... - Page 34 Technical Specifications This section provides the technical specifications for the 9913DA-AES110-RG. Table 5.1 9913DA-AES110-RG Technical Specifications Category Parameter Specification Number of Inputs Standards AES-3 (SMPTE 276M) Sampling Rates All rates from 32kHz to 96kHz AES Input Impedance (transformer balanced) 110ohm Connector WECO®...
-
Page 35: Troubleshooting Checklist
Service Information In This Chapter This chapter contains the following sections: • Troubleshooting Checklist • Warranty and Repair Policy 9913DA-AES110-RG User Manual Service Information • • • • 7-1... - Page 36 Troubleshooting Checklist Routine maintenance to this openGear product is not required. In the event of problems with your 9913DA-AES110-RG, the following basic troubleshooting checklist may help identify the source of the problem. If the card still does not appear to be working properly after checking all possible causes, please contact your openGear products distributor, or the Cobalt Digital Technical Support department at the numbers listed under the “Contact Us”...
-
Page 37: Warranty And Repair Policy
LIMITED TO THE REPAIR OR REPLACEMENT, AT ITS OPTION, OF ANY DEFECTIVE PRODUCT, AND SHALL IN NO EVENT INCLUDE SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING LOST PROFITS), EVEN IF IT HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. 9913DA-AES110-RG User Manual Service Information • • • • 7-3... - Page 38 The Cobalt Digital Technical Support Department will continue to provide advice on any product manufactured by Cobalt Digital, beyond the warranty period without charge, for the life of the equipment. 7-4 • • • • Service Information 9913DA-AES110-RG User Manual...
- Page 39 Notes: 9913DA-AES110-RG User Manual Service Information • • • • 7-5...
- Page 41 Contact Us Contact our friendly and professional support representatives for the following: • Name and address of your local dealer • Product information and pricing • Technical support • Upcoming trade show information General Business Office 217 • 344 • 1243 and Technical Support PHONE 217 •...
