Epson SureColor S-Series Maintenance Manual

Professional Imaging
Follow the instructions below to perform short- and long-term maintenance of an Epson® SureColor S-Series printer.
For more information, see your User's Guide, view instructional videos at www.proimaging.epson.com,
or visit epson.com/support.
Your S-Series maintenance kit includes:
Large cleaning sticks
(x25)
It is also recommended you have:
Ink cleaner kit (part #T699300)
Maintenance is performed on the schedule below or if ink drops, head strikes, or other print quality issues arise.
Standard User: Every 4 days
Medium User: Every 2 days
Heavy User: Once a day
Clean platen and media
edge guides.
Clean print head(s) and
surrounding areas. Be careful
not to touch ink channels as
you clean from back to front.
SureColor S-Series
®
Gloves T-wiper
(x2)
Cleaning cartridge (part #T699000)
Time: Approximately 10-15 minutes
Supplies Required: Large cleaning sticks, ink cleaner kit, T-wiper, wiper cleaner, lint-free cloths.
Process: With large cleaning stick soaked in ink cleaning fluid, follow the guide below.
Clean print head surface(s).
Starting from the inside, move
the T-wiper towards you.
To prevent damage to the
print head, do not move the
T-wiper back and forth.
Flushing pads
(x2)
(not supplied by Epson; check with
your dealer for the correct cloth)
Clean wiper(s). Remove
wiper(s) and clean
attachment area(s).

Maintenance Guide

Wipers Wiper cleaners
(x2) (x2)
Lint-free cloths
Clean wiper rail(s).
Clean capping stations and
remove any debris from
around the caps.
