INSTALLATION AND SET-UP
The rack uprights
have been installed
at the factory. If
removed for cleaning,
reinstall by hanging
them on the shoulder
rivets on the side
walls of the cabinet.
TOP VIEW
SLIDE POSITION to MAXIMIZE
3" PAN CAPACITY OF UNIVERSAL SLIDES
Full Height
Single Door
18 Levels
(Position 2
nd
from Bottom)
Part No. RPC5-U9
(includes slides and uprights) (includes slides and uprights)
Slides sold in pairs. For additional pair of wire slides, order C5-USLIDEPR-C for Chrome or C5-USLIDEPR-S for Stainless Steel.
To order individual universal uprights only, see item #'s 32A, 32B, 32C.
(continued)
SLIDE INSTALLATION
*
32A
RPC5-9-URT5
8 Required per
cabinet
Full Height
Dutch Doors
17 Levels
(Position 2
(Position Bottom) from Bottom)
Part No. RPC5-U9 Part No. RPC5-U7
(includes slides and uprights)
*
32B
RPC5-9-URT7
4 Required per
cabinet
/ Height / Height
3 1
4 2
Cabinet Cabinet
14 Levels 8 Levels
(Position 3
nd
from Bottom)
Part No. RPC5-U5
(includes slides and uprights)
4
SiteSelect
features
make slide
installation
easier.
*
32A
RPC5-9-URT5
4 Required per
cabinet
32C
RPC5-9-URT3
4 Required per
cabinet
Under Counter
Cabinet
5 Levels
rd
(Position Bottom)
Part No. RPC5-U3
(includes slides and uprights)
™
*
