Dualit DHM3 Instruction Manual

CLEANING & CARE
1 WIPE BODY 2 CLEAN
ATTACHMENTS
Turn the speed control to '0' Wash the beaters, dough hooks
and unplug electric cord from and whisk in hot soapy water
electrical outlet before cleaning. after each use. Rinse thoroughly
Wipe the mixer body clean with and dry.
a dry cloth.
TRADITIONAL VICTORIA SPONGE CAKE
SERVES 8
175g soft butter or margarine 175g self-raising flour
175g caster sugar 1 tsp vanilla essence
4 tbsp strawberry jam
4 large eggs
icing sugar to dust
1 tsp baking powder
Preheat your oven to 180ºC/Gas Mark 5
Place the butter or margarine, sugar, baking powder and flour in a large bowl.
Using the flat beaters, mix together on speed 2.
Break in the eggs and mix for a further 10-15 seconds.
Pour into two 18cm cake tins. The tins should be well buttered and bases lined
with silicone mat or baking parchment. Spread evenly and bake for 15-20 minutes.
Leave to cool. Apply the jam to the top of one cake and sandwich together with
the other. Dust liberally with icing sugar and slice into generous helpings.
3 DISHWASHER 4 STORAGE
SAFE
Detach the beaters from the mixer
The beaters, dough hooks and
and store them carefully. The
balloon whisk are all dishwasher
mixer should be stored with the
safe. Use a wash cycle below
cord retracted into the body, the
40°C. Remove prior to drying
plug inserted into the plug storage
cycle. The main body is not
and stood on the swivel base.
dishwasher safe.
QUICK AND EASY LOAF
MAKES A 500G LOAF
3/4 tsp fast action dried yeast
250g strong white flour
12.5g butter 1 tsp sugar
3/4 tsp salt 150ml warm water
Preheat your oven to 220ºC/Gas Mark 7
Using both dough hooks, mix together on speed 1 the flour, salt, yeast, butter
and sugar.
Slowly add the water until the flour forms a craggy ball. Mix for no longer than 2 minutes.
Use your hands to knead the dough into a ball then place back in the bowl to
rise for approximately 20-30 minutes.
Using your hands, knock the air out of the dough. Place the dough in a greased
500g bread tin. Allow to rise in a warm place for 1-2 hours.
Bake for 25-30 minutes or until golden brown.
IMPORTANT SAFETY PRECAUTIONS
READ ALL INSTRUCTIONS
BEFORE USING THE HAND MIXER KEEP
THESE INSTRUCTIONS FOR FUTURE
REFERENCE
• T
HIS IS AN ATTENDED APPLIANCE
D
o not leave appliance unattended during use, unplug after each
use (risk of fire if an unattended appliance is left operating).
• T
his appliance must not be used by children, and persons with very
extensive and complex disabilities. Persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge shall not use
this appliance, unless they are supervised and have been given instruction
concerning the use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children.
• K
eep the appliance and its cord out of reach of children.
• T
his appliance is intended for light indoor domestic use only. If the
appliance is used improperly or for professional or semi-professional
purposes or if it is not used according to these instructions the Guarantee
becomes invalid and Dualit refuses any liability for damage caused.
E
lectrical safety
• B
efore plugging in, check that the voltage on the rating label is the same
as the mains supply.
• U
se this product with rated voltage A.C. outlet only.
• W
e recommend that the appliance is plugged into a socket that has no
other appliance connected to it. Failure to do this may cause an overload,
trip a circuit breaker or blow a fuse. Preferably the socket outlet should
be protected by a Residual Current device (RCD).
• N
OTE: any plug cut from the power supply cord should be disposed of
immediately. Inserting any cut off plug into a 13A socket-outlet is hazardous.
• N
ever use the plug without the fuse cover fitted. Ensure replacement
fuse is the same current value as the original. Replacement fuses are
available and should be ASTA approved to BS1362.
• T
his product is fitted with a resettable thermal cut-out and surge
protection. If the motor stops, the unit is not broken. Stop, unplug allow
to cool and then restart.
• I
n order to avoid a hazard due to inadvertent resetting of the thermal
cut-out, this appliance must not be supplied through an external switching
device, such as a timer, or connected to a circuit that is regularly switched
on and off by the utility.
• A
short retractable power-supply cord is to be provided to reduce risks
resulting from becoming entangled in or tripping over a longer cord.
• D
o not operate any appliance with a damaged lead or plug, or after the
appliance malfunctions or has been damaged or dropped in any manner.
I
f the power cord is damaged it must, for safety reasons, be replaced by
Dualit or an authorised Dualit repairer.
• T
o disconnect, turn any control to off, then remove plug from wall outlet.
• S
witch off the appliance and unplug from the wall socket when not in
use, or before changing accessories or cleaning.
• T
o be protected against electrical hazards, do not immerse the mains
lead, plug or main body in water or any other liquid. Do not allow liquid
into the join where the main body and attachments meet.
G
eneral safety
• T
his appliance should only be operated in a dry, well ventilated area.
• D
o not use in bathroom or outdoors.
• D
o not let cord hang over edge of table or counter.
• K
eep fingers, clothing, utensils and hair away from moving parts.
• K
eep hands and utensils out of container while mixing to reduce the risk
of severe injury to persons or damage to the hand mixer. A scraper may
be used but must only be used when the Hand Mixer is unplugged.
• D
o not disconnect accessories from the main body before the motor
has stopped.
• D
o not attempt to defeat the interlock mechanisms.
• W
hen mixing heavy loads, operate for a maximum of 1 minute, and allow to
cool to room temperature before using again. No recipe contained within the
manual is considered a heavy load.
• B
e certain the attachments are firmly inserted and correctly assembled before
operating appliance.
• T
he use of accessory attachments not recommended by Dualit may
result in fire, electric shock or injury to persons.
• D
o not use a scouring pad or abrasive cleaner on the main body.
• C
AUTION: to prevent damage to the appliance, do not use alkaline cleaning
agents. When cleaning, use a soft cloth and a mild detergent.
• D
o not immerse main body or plug in water.
• N
ever carry or pull the appliance by the cord.
SAVE THESE INSTRUCTIONS
In the interest of improving products, Dualit Ltd. reserves the right to change the
product specification without prior notice.
I
NSTRUCTIONS ON ENVIRONMENT PROTECTION
Do not dispose this product in the usual household garbage at the
end of its life cycle. Please hand it over to a collection point for
the recycling of electrical and electronic appliances. The symbol
on the product, the instruction of use or the packaging will inform
you about the methods of disposal. The materials are recyclable as
mentioned on its marking. By recycling, material recycling or other
forms of re-utilization of old appliances you are making an important contribution
to protect our environment. Please enquire at the community administration for
the authorised disposal location.
IMPORTANT: BEFORE
FIRST USE
• Read this instruction manual before you start using the Hand Mixer. It gives
you important safety information and will ensure you get the most out of your
Dualit Hand Mixer.
• Keep this manual and your proof of purchase in a safe place.
• Unpack the box with care, keeping all the packaging materials until you are
satisfied everything is present and in working order. Once satisfied, remove
all packaging and tags from the Hand Mixer and recycle the packaging
appropriately. Do not remove tags from the cord. You may wish to keep the
box to store your appliance.
• When you turn the Hand Mixer on for the first time, a "new" smell may be
given off, this will dissipate after a few uses. Clean all parts in contact with food
before using for the first time.
DON'T FORGET TO WWW.DUALIT.COM/REGISTER
REGISTER YOUR
HAND MIXER
OR BY POST
