JYU G3S Instruction Manual

Component Diagrams
Hornet S
Three Axis Gimbal
G3S
Gimbal Installation and Removal
1. Insert the front hooks
of the Gimbal in these
two slots
Instruction Manual
www.JYU.com
2.Camera Control Button (on the Remote
Controller)
Taking Pictures or Video
Press and hold the camera control button on the remote
controller for 3 seconds to begin recording. The set
resolution indicator will begin to blink to show recording
has started. Press and hold the camera control button for
3 seconds to end recording.
A quick press of the camera control button will take a still
picture.
Notice: you can press the camera button to intercept the
video pictures during recording (only effective under 1080P
/ 720P)
Setting the Camera Resolution
Press and hold the camera control button on the remote
controller for 3 seconds. The set resolution indicator will
begin to blink to show recording has started. Press and
release the camera control button to change the resolution
setting until the corresponding status light flashes (The
default resolution is 1080P@60FPS).
Gimbal/ Up and Down
Record/Picture
Using the Video Screen
Installing the Video Screen
Pull the mobile device holder out of the Remote Controller
Place the video screen in the holder and securely press it
in place as shown in diagram 1
Notice: If the display shows "snow" the video signal is not
present - press the buttons on the back of the display one
Connect the screen to the Remote Controller using the 2.5
by one until the video image appears on the screen
mm video cable as shown in diagram 2
Gimbal Specs
Hornet S Gimbal, Camera Specs
Three Axis Gimbal Video Screen (L43)
Operating Range
Net Weight
Image Sensor
ISO
2.5mm Video/Audio Cable
Lens
Shutter Time
Image Resolution
Video Resolution
SD Card Type
2. Insert the rear hook of
the Gimbal in this slot
Operating Temperature
Gimbal Instructions
Gimbal Installation
1. Gimbal LED Status
Press the button and
pull down on the
Gimbal.
Removing the Gimbal
Video Screen Indicators
Mobile Device Holder
①. GPS Signal Strength
Turn the drone and the remote controller on. To see how
to do this, look at <Hornet S Basic Instruction Manual>
Turn the Hornet S power ON
②. Remote Controller Mode (To switch modes,
The Hornet S video signal has been paired with the
read the Remote Controller Instruction Manual)
Remote Controller at the factory so you should see
video immediately
+0~-90º +/- 0.05º
200g
16 Megapixel
50~3200(automatic)
F/2.8, FOV/100 °, 28mm (35mm
equivalent) focus at ∞
1.25-1/4000s(automatic)
(4608 x 3456)
4K@25FPS
2.7K@30FPS
1080P@60FPS
720P@120FPS
TF(Micro_SD) Card, ≥Class 10,
Max 64G
-10~50℃
Status Light and Resolution Pairing Table
LED① LED② LED③ LED④
Key :
10
⑫
CEIL Reached the Max
Altitude
--- No GPS Signal
FAIL Lost Signal
2D Weak GPS Signal
3D Strong GPS signal ③. Remote Controller Signal Strength
④. Drone Uptime
⑤. Drone Battery Electric Current
⑥. Warnings
STAB Disarmed
DISARMED Disarmed
MANU Manual
NO GPS! No GPS Signal
ALTH Set Altitude
LOSERSSI Remote Controller
POSH Set Position (Can only be used
Signal Too Weak
when there is a GPS Signal)
DVH Maintain Speed
Image (Video or Still) Recording Indicator
Gimbal LED Status Function Key
①②③④
Video Image
Resolution Resolution
4K@25FPS
2.7K@30FPS
16M
(4608 x 3456)
1080P@60FPS
720P@120FPS
= Bright = Dull
LOWBATTERY 1 Low Battery -
First Warning
LOWBATTERY 2 Low Battery -
Second
⑦ . Ascension and Rotation Angle of
the Drone (-180°~180°)
⑧. Horizon
⑨ . Distance (0~1000m)
⑩. Direction
⑪ . Altitude (0~1000m)
⑫ . Camera status information
