Brady BBP 16E Quick Start Manual

Thermal Transfer / Direct Thermal

Quick Start Guide

Printer Overview
Fan-fold paper
LED indicators
entrance chute
Touch
screen
Media view
Operatiion Paper exit
window
buttons chute
Note: The interface picture here is for reference only. Please refer to the product specification for the interfaces availability.
Printer right side cover
Media guide bar
Ribbon
rewind
spindle
Ribbon
release
button
Internal rewind
spindle
Print head pressure
adjustment knobs
Barcode Printer
Ethernet interface
SD card
socket
USB
interface
USB host
interface
RS-232C
interface
Power jack
socket
Print head
Ribbon
sensor
Platen
Label roll
guard
3" Label
Media sensor
supply spindle
Label guide
Print head
release lever
Ribbon supply
spindle
(option)
Loading the Ribbon
(1) Open the printer right side cover.
GPIO interface
Push the print head release lever
(Option)
to open the print head mechanism.
Centronics
interface
Power switch
(4) Wind the ribbon clockwise about
3~5 circles onto the ribbon rewind
spindle until it is smooth and
properly stretched.
Remove Used Ribbon
Damper
Media sensor
lock lever
(1) Break the ribbon between ribbon
guide plate and the ribbon rewind
spindle.
(2) Install the ribbon onto the ribbon (3) Wrap the ribbon onto the ribbon
supply spindle. Thread the ribbon rewind spindle. Keeping the
through the ribbon sensor slot and ribbon flat and without wrinkles.
then through the open space in
between print head and platen.
* Loading path for ribbon
(5) Close the print head mechanism
by pushing the both sides of print
head mechanism. Make sure the
latches are engaged securely.
(2) Push the ribbon release button to (3) Then, slide off the ribbon from
release the ribbon on the ribbon ribbon rewind spindle.
rewind spindle.
Y2271916
