TO START
IMPORTANT: SEE MANUAL FOR DETAILED
INSTRUCTIONS OF THESE PROCEDURES.
5
A. Follow SET-UP on Reverse.
B. Close Chuck Guard.
STOP: MAKE SURE ALL FRONT
CONTROLS ARE SET TO "OFF"
OR "0".
C. Plug in the Lathe.
D. Move Forward-OFF-Reverse
Switch to desired direction.
E. Move Power Switch to "ON"
position.
F. Turn Variable Speed Control
Knob to desired speed.
TO STOP
6
A. Turn Variable Speed
Control Knob to "0".
B. Move Forward-OFF-
Reverse Switch to
OFF
"OFF" position.
C. Move Power Switch
to "OFF" position.
D. Unplug the Lathe.
REVERSE
I
OFF
O
1
FORWARD
REVERSE
I
O
1
FORWARD
0
Q U I C K
7" x 10"
PRECISION MINI LATHE
0
Read the user manual completely before using this product. Failure to do
so can result in serious injury.
Always wear ANSI-approved eye protection before using this product
Copyright
©
2012 by Harbor Freight Tools
S T A R T
G U I D E
. All rights reserved. REV: 14c
®
Item: 93212
