MYPV AC THOR Assembly Instructions Manual
Photovoltaic-power-manager for hot water and space heating
Hide thumbs
Also See for AC THOR:
- Operation manual (79 pages) ,
- Assembly instructions manual (61 pages) ,
- Instructions for integrating (9 pages)
Table of Contents
Advertisement
Quick Links
Photovoltaic-Power-Manager for hot water and space heating
Assembly Instructions
The Operation Manual of the device is available at
www.my-pv.com.
The following device key is required for online registration of the unit. Keep it safe! Please see
the Operating instructions for further information.
®
AC•THOR
Assembly Instructions, Version 180604
AC•THOR
Device Key
®
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MYPV AC THOR
Summary of Contents for MYPV AC THOR
- Page 1 AC•THOR ® Photovoltaic-Power-Manager for hot water and space heating Assembly Instructions The Operation Manual of the device is available at www.my-pv.com. The following device key is required for online registration of the unit. Keep it safe! Please see the Operating instructions for further information. Device Key ®...
-
Page 2: Table Of Contents
Contents Intended use ............................3 Scope of supply ............................3 Safety instructions ........................3 Limitation of warranty and liability ....................... 4 Connections ............................. 5 Assembly ..............................5 Connecting several temperature probes ..................... 7 Electrical connection ........................7 Electrical connection for multiple units ..................7 Wiring diagrams ............................ -
Page 3: Intended Use
Intended use The electronic AC•THOR Photovoltaic-Power-Manager (in the following, AC•THOR for short) is designed for operating resistive loads such as electric immersion heater elements, electric boilers, electric convectors, electric heating mats or infrared panels. The unit controls the output voltage according to external signals (temperatures, Ethernet- and other control signals) linearly and thus the power output of the connected load. -
Page 4: Limitation Of Warranty And Liability
Comply with the relevant standards when mounting and connecting the device. The unit housing may heat up during operation. Only mount the unit on non-combustible surfaces. The unit is only intended for use in dry rooms indoors. Otherwise there is a risk of fatal electric shock! In sanitary facilities, the relevant regulations must be observed! Do not install the device in an environment contaminated with ammonia. -
Page 5: Connections
Connections Assembly A brief video (German) to explain assembly will also be found online: https://www.youtube.com/watch?v=WFHbayf5VDQ Remove the wall bracket from the rear of the AC•THOR unit. To do this, slide the lock underneath to the right. ® AC•THOR Assembly Instructions, Version 180604... - Page 6 Then fix the wall bracket to the wall with three screws. Three screws and three wall-plugs are supplied. If the screws supplied are not suitable for the substrate, suitable screw must be obtained. To fix it to the wall bracket, the AC•THOR is suspended in the wall bracket by the two long slots on top and then fixed in place by locking it underneath (slide to the left).
-
Page 7: Connecting Several Temperature Probes
Connecting several temperature probes Up to four digital temperature probes (three-core, bus system) can be connected to the AC•THOR. The terminal positions for the three cores are shown in the following illustration. TIP: If more than one probe is used, the cores can also be connected externally in parallel! Temperature probe clamping points... -
Page 8: Wiring Diagrams
Wiring diagrams The current versions are available on www.my-pv.com. Wiring the AC•THOR control side Power meter – connection via router Establishing the automatic connection via router may take as much as a minute! ® AC•THOR Assembly Instructions, Version 180604... -
Page 9: Power Meter - Connection Without Router
Power meter – connection without router ® AC•THOR Assembly Instructions, Version 180604... -
Page 10: Power Meter - Connection Via Powerline Without Router
Power meter – connection via Powerline without router ® AC•THOR Assembly Instructions, Version 180604... -
Page 11: Control By Inverter Or Battery Management
Control by inverter or battery management ® AC•THOR Assembly Instructions, Version 180604... -
Page 12: Control By The Energy Management System
Control by the energy management system ® AC•THOR Assembly Instructions, Version 180604... -
Page 13: Wiring Ac•Thor Applications
Wiring AC•THOR applications Operating mode M1: Hot water 3 kW ® AC•THOR Assembly Instructions, Version 180604... -
Page 14: Operating Mode M2: Hot Water Stratification Charge
Operating mode M2: Hot water stratification charge ® AC•THOR Assembly Instructions, Version 180604... -
Page 15: Operating Mode M3: Hot Water 6 Kw
Operating mode M3: Hot water 6 kW ® AC•THOR Assembly Instructions, Version 180604... -
Page 16: Operating Mode M4: Hot Water + Domestic Hot Water Heat Pump
Operating mode M4: Hot water + domestic hot water heat pump ® AC•THOR Assembly Instructions, Version 180604... -
Page 17: Operating Mode M5: Hot Water + Space Heating
Operating mode M5: Hot water + space heating ® AC•THOR Assembly Instructions, Version 180604... -
Page 18: Connecting Three-Phase Heating Elements
Connecting three-phase heating elements ® AC•THOR Assembly Instructions, Version 180604... -
Page 19: Maintenance
Maintenance Do not attempt to open the unit. The device does not contain any parts that may be repaired by the user. Never splash water on or in the unit! When it is unplugged, the surface of the unit can be cleaned either with a damp cloth, using mild glass cleaner or cleaning tissue for glasses. -
Page 20: Troubleshooting
Troubleshooting The device does not contain any parts that may be repaired by the user. In the event of a fault, please contact your specialist dealer. Disposal Packaging material must be either stored or disposed of as appropriate. Dispose of the product at the end of its service life according to the statutory regulations.
