- Page 1 RE-HDEQ HDMI - HDMI Equaliser OPERATION MANUAL...
-
Page 2: Safety Precautions
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 3: Table Of Contents
Table of Contents 1. Introduction .................. 1 2. Applications ................. 1 3. Package Contents ..............1 4. System Requirements ..............1 5. Features ..................1 6. Specifications ................2 7. Hardware Description ..............3 8. Connection and Installation ............4 9. -
Page 4: Introduction
1. Introduction This mini HDMI to HDMI enhancer can transmitting digital audio and video signal and extending or cascade it without signal loss. It is capable of receiving and transmitting 2.25 Gbps bandwidth rate and the video resolutions supports up to 1080p@60Hz. The other important feature is that the system has built-in the equalizer and CDR (Clock Data Recovery) can provide long cable support even at deep color resolutions. -
Page 5: Hardware Description
2W (Max) 7. Hardware Description The following sections describe the hardware components of the unit. RE-HDEQ . HDMI input: Connect the HDMI input port to the HDMI output port of your source equipment such as DVD/HDMI switcher/HDMI Splitter/HDMI Matrix. Direct power supply from HDMI input source equipment yet if the source can't supply with power users can connect an external power for external HDMI power supply. -
Page 6: Connection And Installation
8. Connection and Installation HDMI 15M RE-PI Power Inserter HDMI splitter RE-PI Power Inserter HDTV... - Page 7 www.cypeurope.com...
