- Page 1 RE-11HS HDMI to HDMI equalizer Operation Manual RE-11HS...
- Page 2 TABLE OF CONTENTS 1. Introduction................2. Features..................3. Package Contents..............4. Operation Controls and Functions.......... 4.1 Front Panel................4.2 Rear Panel................5. Connection and Installation............. 6. Specifications................
-
Page 3: Package Contents
1. Introduction The RE-11HS is perfect for placing at the end of a HDMI cable to boost the signal by up to 40dB to improve the HDMI signal quality to the display. The RE-11HS Equaliser uses v1.3 HDMI specifications, supporting ‘Deep Colour’... - Page 4 4.2 Rear Panel HDMI INPUT DC 5V HDMI input: Connect the HDMI input port to the HDMI output port of your source equipment such as DVD player or set-top-box. Power: Plug the 5VDC power supply into the unit and connect the adaptor to AC wall outlet.
