PA-20 Mobile Computer
Quick Start Guide
http;//www.argox.com
See User Manual for more information
Depending on the configuration ordered, the PA-20 shipping container
may include:
CD ROM
Quick Reference
Guide
Power supply
PA-20
To attach the hand strap
1.
Fix the small cord of the strap around the pillar of the terminal.
(Figure 1)
Insert the handle of the strap in the thin loop. (Figure 2)
2.
The strap is fixed to the terminal. Hold the hand strap around the
wrist when carrying the terminal
Figure1
Hand strap
strap
Power plug
Battery pack
Figure2
Feature
Screen
Scan Button
Power Button
Reset Button
Connector
Scan Window
First time initiation of this product; please make
sure to charge the main battery for at least 16 hours
！
to ensure a proper charge.
Battery Cover
Battery Cover Latch
Buzzer
