Reynolds Building Systems the Easton Assembly Manual page 9

Step 6A Assemble 10' Long Back Walls
1. Position a 48" wide wall frame against a 72" wall frame as shown below. Nail frames
together with 10d sinkers.
2. Square wall frame. Measure diagonally (corner to corner). The measurements will be the
same when the wall is square.
Select siding panels that are 79-1/2" in length for the back wall and the front wall.
When installed, the siding will extend 3/4" below the bottom plate and 3-3/4" above
the top plate. Cut siding flush with the bottom plate if installing the building on a
cement slab.
3. Select a 24" wide panel, with the 'tongue' edge, and install this panel with the 'cut' edge'
flush with the end of the wall and extending 3/4" below the bottom plate.
4. Install (2) two more siding panels.
Tongue Edge
Cut Edge
5. Repeat to assemble another 10' long wall frame, do not apply siding.
48" Wall Plate
Siding Extends 3/4" Below Plate
72" Wall Plate
