Summary of Contents for Pureit Advanced RO plus MF
- Page 1 World’s largest selling water purifier REACH PUREIT AT 1860-210-1000 www.pureitwater.com Based on Unit shipment sales for 2013. Excludes pitchers and faucet mount systems sales and includes only in-home point-of-use drinking water treatment systems.
- Page 3 We once again thank you for buying Pureit Advanced RO + MF / RO + UV we look forward to a long and fruitful association with you. * Will vary basis the model; Pureit Advanced RO + MF has MF membrane, Advanced RO + UV has UV chamber.
-
Page 4: Table Of Contents
RO + MF / RO + Uv Advanced 6-stage Technology Advanced 6-stage purification through RO + MF / RO + UV Unique Features of Pureit Advanced RO + MF / RO + UV ....... 3 technology TdS Removal up to 1800 Pureit Advanced RO + MF / RO + UV Unique Technology ....... -
Page 5: Specifications
Height 422.6 mm Width 380 mm Depth 165.6 mm Weight of Pureit Advanced RO + MF / RO + UV ~ 5.8 kg–(dry weight) Flow Rate Approximately 9–12 litres per hour Storage Tank Capacity 5 litres PP Melt Blown Pre-Sediment Filter, Pre-RO Carbon Filter, Post-Carbon Sediment... -
Page 6: Pureit Advanced Ro + Mf / Ro + Uv * Unique Technology
KNOW YOUR PUREIT AdvANCEd RO + MF / RO + Uv WATER-FLOW dIAGRAM Flow Restrictor Rejected Water 10. RO Filter Post-Carbon Front Cover 11. MF Filter / UV Chamber Sediment Filter RO Filter Sediment Filter Pre-Carbon Filter 12. Post-Carbon Sediment Filter... -
Page 7: Important Installation Instructions
TDS Meter Reject Water Make sure you test the input water TDS before installing Pureit Advanced RO + MF / RO + UV The minimum input water TDS should ideally be more than 200 PPM and maximum Ensure Pureit Advanced RO + MF / RO + UV is not installed above any electric socket. - Page 8 Pureit Advanced RO + MF / RO + UV should not be connected to any hot water tap. Install your Pureit Advanced RO + MF / RO + UV away from any direct sunlight and ensure there is enough ventilation.
- Page 9 If the pressure is less than 5 PSI then you need to buy purifier for more than 2 days. ‘Pressure Enhancing Pump’ which can be bought at an additional cost. Ensure you buy them from the authorised service personnel of Pureit. Reject Water Reject Water Do not put heavy or sharp objects on the purifier.
- Page 10 IMPORTANT INSTALLATION INSTRUCTIONS IMPORTANT INSTALLATION INSTRUCTIONS Reject Water Reject Water If the power cord is damaged, the power adapter must be replaced and not used. Do not plug or unplug the power cord with wet hands. Ensure that the plug isn’t wet while plugging in or plugging out to avoid risks such as electrical shock or fire.
-
Page 11: Ordering Gkk-1 And Gkk-2
You can clean the tap by using disinfectants like bleach/hypochlorite. Discard 2 litres of water after cleaning the tap. This is to ensure that you continue to get ‘As safe as boiled water’ from your Pureit Advanced RO + MF / RO + UV Reject Water... - Page 12 CLEANING ANd MAINTENANCE CLEANING ANd MAINTENANCE Reject Water Do not extensively clean and rub the decorative parts Turn off the Ball Valve and switch off the power if you notice as this might lead to scratches on the parts. any leakage from the purifier. Reject Water Always switch off the ‘Ball Valve’...
- Page 13 When shifting your house, get the purifier duly inspected and packed This can only be done by a qualied company personnel or an authorised agent. by the Pureit service technician. Remove water from the storage tank and pack the purifier properly during shifting.
-
Page 14: General Do's And Don'ts
What are all the consumables which are all you have to do is call Pureit Helpline number and we will deliver a new GKK to you at your home for a The RO removes dissolved salts, hardness, pesticides and to be replaced? heavy metals like arsenic, lead and mercury. -
Page 15: Pureit Advanced Ro + Mf / Ro + Uv * Water Purifier
1. Please retain the bill of purchase. 2. Please quote Serial number, Model and Date of Purchase in all your correspondence. Will vary basis the model; Pureit Advanced RO + MF has MF membrane, Advanced RO + UV has UV chamber. -
Page 16: Troubleshooting
Helpline number (1860-210-1000) b. The filters or the membranes need to be replaced/cleaned – Please replace or get them cleaned by calling the Pureit Helpline number. The purification is taking more time This might be because of one or more of the following reasons: a. -
Page 17: Pureit Advanced Ro + Mf / Ro + Uv Warranty Details
• ‘User manual’ shall mean the instructions for installation, use and maintenance contained in the leaflet published by Warranty does not cover accessories external to the equipment supplied by the dealer. the company, and delivered to the Customer at the time of sale of the ‘Pureit Advanced RO + MF / RO + UV ’. In case of repairs or replacement of any part/s of the unit, this warranty will thereafter continue and remain in • Visit the Pureit website for more detailed instructions on cleaning/maintenance of your purifier. - Page 18 DATE: 8 Mar 2016 SCALE: 100% PROCESS COLOURS: K (Black) JOB No.: 3869 APPLICATION USED: SPOT COLOURS: CLIENT: HUL INDESIGN PACKAGE: CS 4 TOTAL COLOURS: Single CAMPAIGN / JOB TITLE: Marvella RO+UV and RO+MF QUARK PACKAGE: COPY WRITER SIGN OFF: an ISO 9001:2008 certified company FILE NAME / VER: ILLUSTRATOR:...
