Nikon D800 Update Manual

The D800/D800E Firmware Update The D800/D800E Firmware Update
En
Please note the following changes to the User's Manual with the release of the latest camera fi rmware (version A 1.10/B 1.10).
The Custom Settings Menu The Custom Settings Menu
The following items have been added to the Custom Settings Menu.
❚❚ ❚❚ Custom Setting f13: Assign Movie Record Button
Custom Setting f13: Assign Movie Record Button
Select the role played by the movie-record button and command dials
when C is chosen with the live view selector. With the addition of this
item to the Custom Settings menu, the former Custom Setting f13
(Assign MB-D12 AF-ON) has been renumbered f14.
Option
9 ISO sensitivity Press the button and rotate a command dial to choose an
ISO sensitivity.
i Choose image Press the button and rotate a command dial to choose
from pre-selected image areas. Selecting Choose image
area
area displays a list of image areas; highlight options and
press 2 to select or deselect, then highlight Done and
press J.
$ Shutter spd & Press the button and rotate the main command dial to
lock shutter speed in modes f and h; press the button
aperture lock
and rotate the sub-command dial to lock aperture in
modes g and h.
None No operation is performed if the command dials are
rotated while the button is pressed.
❚❚ ❚❚ Custom Setting f15: Assign Remote Fn Button
Custom Setting f15: Assign Remote Fn Button
Choose the role played by the Fn buttons on optional WR-1 or WR-T10
wireless remote controllers.
Option
q Preview Press the button to preview depth of fi eld.
r FV lock Press the button to lock fl ash value (supported fl ash units
only). Press again to cancel FV lock.
B AE/AF lock Focus and exposure lock while the button is pressed.
C AE lock only Exposure locks while the button is pressed.
D AE lock (Reset Exposure locks when the button is pressed, and remains
on release) locked until the button is pressed a second time, the
shutter is released, or the standby timer expires.
F AF lock only Focus locks while the button is pressed.
A AF-ON Pressing the button initiates autofocus.
s Flash off The fl ash will not fi re in photos taken while the button is
pressed.
4 + NEF (RAW) If image quality is set to JPEG fi ne, JPEG normal, or JPEG
basic, "RAW" will be displayed in the control panel and
an NEF (RAW) copy will be recorded with the next picture
taken after the button is pressed (to record NEF/RAW
copies with a series of photographs, keep the shutter-
release button pressed halfway between shots). To exit
without recording an NEF (RAW) copy, press the button
again.
a Live view Press the button to start and end live view.
None The button has no eff ect.
Wireless Remote Controllers
A
The camera shutter can be released remotely using optional WR-R10, WR-T10,
or WR-1 wireless remote controllers (the WR-R10 requires a WR-A10 adapter;
for details, see the manual provided with the controller). If Record movies is
selected for Custom Setting g4 (Assign shutter button), the shutter-release
button on the wireless remote controller can be used to start movie live view and
record movies: press it halfway to start movie live view and all the way down to
start or end movie recording.
Description
Description
The Setup Menu The Setup Menu
The following changes have been made to the setup menu:
❚❚ ❚❚ Wireless Transmitter (WT-4)/Network (UT-1)
Wireless Transmitter (WT-4)/Network (UT-1)
The Wireless transmitter item in the setup menu has been renamed
Wireless transmitter (WT-4) and a Network (UT-1) item has been
added (for more information on the Network (UT-1) item, download
the latest version of the manual for the UT-1 communication unit).
Be sure to update the fi rmware and supplied software for the wireless
transmitter or communication unit to the latest versions. Update the
UT-1 fi rmware to version 2.0 or later and the Wireless Transmitter Utility
software to version 1.5.0 or later.
Locking Focus with the B
Locking Focus with the
During viewfi nder photography, focus can be locked using the B
button in place of the shutter-release button. If AF-ON only is selected
for Custom Setting a4 (AF activation), the camera will not focus when
the shutter-release button is pressed halfway; instead, the camera will
focus when the B button is pressed, at which point focus will lock
and remain locked until the B button is pressed again. The in-focus
indicator will not be displayed in the viewfi nder. The update changes
the behavior of the B button as follows:
• Before the update: The shutter could be released at any time, regardless
of the options selected for Custom Settings a1 (AF-C priority
selection) and a2 (AF-S priority selection).
• After the update: When Focus is selected for Custom Setting a2 (AF-S
priority selection), the shutter can no longer be released in single-
point AF AF-area mode if the camera fails to focus using single-servo
autofocus.
B Button
Button
