SVT-WIFI Video Intercom System A

User Manual

Please read this user manual prior to installing the system, and keep it well for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SVT-WIFI and is the answer not in the manual?

Questions and answers

Related Manuals for SVT SVT-WIFI

Summary of Contents for SVT SVT-WIFI

  • Page 1: User Manual

    SVT-WIFI Video Intercom System A User Manual Please read this user manual prior to installing the system, and keep it well for future use.

  • Page 2: Table Of Contents

    6.1.1 iPhone/iPad users ..................5 6.1.2 Android users ....................6 6.2 RJ45 Ethernet Cable Connection ..............7 6.3 How to add additional users to the SVT-WIFI Outdoor Station..... 7 6.4 How to reset the SVT-WIFI Outdoor Station to factory default..... 8 7.System settings....................8 8.User Guide (Control Cam App)................

  • Page 3: Parts And Functions

    1.Parts and Functions Rear View Front View Speaker LED Light Camera RJ45 Doorbell Ethernet Cable Name Plate Call Button Exit Button Antenna Microphone Power Supply Electric Door Lock 2.Terminal Descriptions...

  • Page 4: Specification

    Wi-Fi: Wireless connection. Connect the antenna to enable Wi-Fi connection RJ45: Ethernet cable connection. Connect the Ethernet cable to a modem when Wi-Fi is out of the range of your Wi-Fi network. CN2: 1&2: Exit Button connection. 3, 4 & 5: Door Lock connection. DOORBELL: External doorbell connection POWER: Outdoor Station's power supply connection.

  • Page 5: System Wiring And Connections

    5.System Wiring and Connections 5.1 System Wiring Diagram...

  • Page 6: Electric Door Lock Connection

    Android users can download the ControlCam App directly from the Google Play Store, and IOS users can download it from the Apple Store. Both download and usage are free for SVT Innovations users. >Download the ControlCam App, and install it in your smart phone or tablet.

  • Page 7: Wi-Fi Wireless Connection

    Step 1: Attach the Antenna to the Wi-Fi pin on the back of the outdoor station; Step 2: Unplug the SVT-WIFI outdoor station from the electrical outlet. Power it back ON. Hold the call button for 45 seconds, until the LED light flashes and a "Bi..." sound is heard;...

  • Page 8: Android Users

    Step 1: Attach the Antenna to the Wi-Fi pin on the back of the outdoor station; Step 2: Unplug the SVT-WIFI outdoor station from the electrical outlet. Power it back ON. Hold the call button for 45 seconds, until the LED light flashes and a "Bi..." sound is heard;...

  • Page 9: Rj45 Ethernet Cable Connection

    6.2 RJ45 Ethernet Cable Connection If you are installing the SVT-WIFI Outdoor Station in a place out of the range of your Wi-Fi network, you may use the RJ45 Ethernet cable connection instead. Step 1: Plug in a RJ45 Ethernet cable into the SVT-WIFI outdoor station;...

  • Page 10: How To Reset The Svt-Wifi Outdoor Station To Factory Default

    6.4 How to reset the SVT-WIFI Outdoor Station to factory default: If the outdoor station has been previously connected to a Wi-Fi router, you must first reset it to factory default prior to connecting it again to a new Wi-Fi router: Step 1: Unplug the outdoor station from the power outlet.
  • Page 11 Select "OFF" in the Outdoor call-in option. Then select "Edit" and insert the new user name and password. Select "OK" to confirm. Enable the Outdoor call-in option back to "ON" to receive calls from the SVT-WIFI outdoor station. Note: The IP Camera configuration page offers advanced settings. Most settings...

  • Page 12: User Guide (Control Cam App)

    8. User Guide (ControlCamApp) 8.1 Talking: When a guest presses the call button, the device will receive a ring alert. The user can either accept or decline the call on the pop-up call alert box. Press and hold to start talking and release to listen. 8.2 Unlocking the door/gate: Input the unlock code while on monitoring or talking mode to release the door/gate (Use the default system password as the unlock code).

  • Page 13: Power Supply

    Step 1: Select on the top right corner of the screen. Step 2: Select "Call records to review all calls from the SVT-WIFI outdoor station. Step 3: Select "Video capture file to review pictures and videos captured. 9. Power Supply...
  • Page 16 The design and specifications of this user manual can be changed without any notification to the user. All copyright and interpretation rights are reserved to SVT Innovations Inc.
