Page 1: User Manual
SVT-MF4 Outdoor Station A User Manual Please read this user manual prior to installing the system, and keep it well for future use. -
Page 2: Table Of Contents
4.2 Mounting with the Rain Guard................4 4.3 Mounting the Indoor Monitor................4 5. System Wiring and Connections ................. 5 5.1 SVT-4 System with one entrance ..............5 5.2 SVT-4 System with two entrances ..............6 5.3 SVT-4 Wiring Connection ................7 5.3.1 Indoor Station................... -
Page 3: Parts And Functions
1.Parts and Functions Description LED lights High resolution camera Built-in speaker Call button Built-in microphone Name plate Status light. Calling in: red light Monitoring/Talking: blue light Description Built-in microphone Monitor button Intercom button Door unlock button Talk button TFT 7” color display Built-in speaker Talking/Ring volume Brightness... -
Page 4: Terminal Descriptions
2.Terminal Descriptions... -
Page 5: Specifications
NO/NC/COM: Max. 14.5V 200mA Lock Power Supply: Must be used according to lock. Communication transmission: 2-way communication Unlocking time: 01 - 35 seconds with SVT-TD20G device Working temperature: 14°F to 131°F / -10°C to 55°C Communication duration: 120s. Communication transmission: 2-way communication Working temperature: -4°F to 131°F / -20°C to +55°C... -
Page 6: Mounting With The Rain Guard
4.2. MOUNTING WITH THE RAIN GUARD Screw anchors Wall hole Rain cover Screws Screws (fix with rain cover) 4.3. MOUNTING THE INDOOR MONITOR... -
Page 7: System Wiring And Connections
System Wiring and Connections 5.1. SVT-MF4 SYSTEM WITH ONE ENTRANCE... -
Page 8: Svt-4 System With Two Entrances
5.2. SVT-MF4 SYSTEM WITH TWO ENTRANCES... -
Page 9: Svt-4 Wiring Connection
JP1: Remove the black jumper if a access control unit is connected to the outdoor station (SVT-3100 / SVT-4100 / SVT-5100 Access Control System only). J1: Connect the access control unit (SVT-3100 / SVT-4100 / SVT-5100 Access Control System only). -
Page 11: Electric Door Lock Connection
5.3.3 Electric Door Lock Connection 1. Use the port J3 of the lower module to connect a door lock. 2. The door lock is limited to 14.5V, 120mA. 3. Must use an additional power supply for the door lock. Ensure the power supply is compatible with the door lock specifications. -
Page 12: Cable Requirements
6.Cable Requirements Cable Usage CAT5 cable (must solder the wires together to ensure a good connection). 230 feet 30 feet Using different cables may affect the maximum distance the system can reach. 70 meters 10 meters NOTE: 1. The system expands to a maximum of 2 outdoor stations and 4 indoor monitors. 2. -
Page 13: User Instructions
7.User instructions Visitor calls The visitor presses The visitor presses the call button the call button on outdoor on outdoor station-1 station-2 Ring Ring Press the call button at anytime, the indoor monitor will show the view The visitor image shown on from front door... -
Page 14: Monitor
Monitor Press the monitor button Press once Press twice Monitor outdoor Monitor outdoor station 1 station 2 The indicator light of The indicator light of Door 1 is on. Door 2 is on. Press the Press the monitor talk button button Monitor the Press the... -
Page 15: Intercom
Intercom In the standby mode, press intercom button indoor monitor All indoor monitors ring indoor monitor presses button or pick up the handset to talk. During the talking, any indoor monitor presses the intercom Talk begins button Press the TALKPress the TALKING button hang-upbutton or hang-... - Page 16 The design and specifications of this user manual can be changed without any notification to the user. All copyright and interpretation rights are reserved to SVT Innovations Inc.
