- Page 1 Bedienungsanweisung Instructions for Use Mode d’Emploi MWX 22 BIS...
- Page 2 Dear Customer: First of all, we would like to thank you for Tips on environmental protection preferring our product. We are sure that this modern, functional and practical microwave oven, Eliminating the packaging manufactured with the highest quality materials, will live up to your expectations. The packaging carries the Green Dot.
-
Page 3: Table Of Contents
Table of contents Safety tips ............................28 Installation instructions ........................30 Description of the appliance ......................31 Setting the clock ..........................31 Advantages of the microwave oven ....................32 Microwave oven operating mode ....................32 Why the food is heated ........................32 Instructions for use .......................... -
Page 4: Safety Tips
Safety tips • Warning! In order to avoid any type of flame, • When connecting electrical appliances in the only use the microwave when you are there to vicinity of the microwave, ensure that the supervise. Very high power levels or very long power cables do not touch the microwave cooking times may heat the food to excess and when it is hot and that they do not get caught in... - Page 5 Safety tips The following tips avoid damage to the Be careful! appliance: • When heating small amounts of food, it is • Do not switch on the appliance without the very important not to select long periods of time rotating base and respective plate. or very high power levels, because the food •...
-
Page 6: Installation Instructions
Installation instructions Use the “open” button to open the door and first time, carefully remove this film, starting at remove all packaging materials. Then clean the the underside. inside and the accessories with a damp cloth In order to ensure proper ventilation for the and dry them. -
Page 7: Description Of The Appliance
Description of the appliance 1. Glass window on the door 6. Open button 2. Catch 7. Slot for rotating base 3. Quartz grill 8. Rotating base 4. Mica covers 9. Turntable support 5. Control panel 10. Rotating plate 11. Grill Setting the clock 1. -
Page 8: Advantages Of The Microwave Oven
Advantages of the microwave oven In a conventional cooker, the heat that is radiated The friction between the molecules generates through the resistances or gas burners slowly heat, which raises the temperature of the foods, penetrates the foods from the outside in. defrosting or cooking them or keeping them hot. -
Page 9: Instructions For Use
Instructions for use Warning! Never use the microwave when it is empty, i.e. when it does not contain any food. To operate the microwave, proceed as follows: 1. Plug the appliance into an appropriate electrical socket (see tips on the last page). 2. -
Page 10: Function: Grill
Instructions for use Function: Grill 1. Press the grill button. The button indicator lights up. 2. Enter the operating time (for example, 10 minutes) with the help of the ROTATING BUTTON, by turning it in any direction. 3. Press the START button. The microwave starts to function. Function: Microwave + Grill 1. -
Page 11: Function: Defrosting By Time (Manual)
Instructions for use Function: Defrosting by time (manual) 1. Press the DEFROST button twice. The button indicator lights up. 2. Indicate the defrosting time (for example, 10 min.) using the ROTATING BUTTON, turning it in any direction. 3. Press the START button. The microwave starts to function. 4. -
Page 12: Programming The Microwave
Programming the microwave The normal functions (microwave, grill, microwave 10. Use the ROTATING BUTTON to indicate + grill, defrosting by weight and defrosting by time) the desired cooking time (8 min). may be programmed one after each other, up to a 11. -
Page 13: During Operation
During operation... During the cooking process, you may open the Energy Saving door at any moment, as: This microwave oven has a special energy • THE PRODUCTION OF MICROWAVES IS saving mode which is automatically activated at IMMEDIATELY INTERRUPTED. the end of a ten-minute period of inactivity. •... -
Page 14: Defrosting
Defrosting The following table is a general guideline for the temperature) according to the type and weight of various defrosting and resting times required (to the foods. It also contains the respective guarantee that the food reaches a uniform recommendations for defrosting different foods. Defrosting Time Food Weight (g) -
Page 15: General Tips For Defrosting
Defrosting General tips for defrosting 1. Only use microwave-safe dishes for defrosting 8. Place poultry on a turn over plate so that the (porcelain, glass, suitable plastic). juices may drain more easily. 2. The defrosting by weight function and the 9. -
Page 16: Cooking With Microwaves
Cooking with microwaves Before using a container, check if it is suitable for 2. The lower the temperature, the longer the using in a microwave oven (see: “What kind of cooking time. containers may be used?”). 3. Liquid foods heat faster. Cut the food before starting to prepare it. -
Page 17: Important Tips
Cooking with microwaves Important tips! • Eggs with shells and whole eggs should not be • If there are various different containers, heated in microwave ovens as they may such as cups for example, place them explode. uniformly on the rotating plate. •... -
Page 18: Tables And Suggestions - Cooking Vegetables
Cooking with microwaves Tables and suggestions – Cooking vegetables Power Time Resting time Food Quantity (g) Added liquid Program Tips (Watt) (min.) (min.) Cauliflower 1/8 l P 05 9-11 Spread some butter on top. Broccoli 1/8 l P 05 Cut in slices. Mushrooms P 05 Peas... -
Page 19: Cooking With Grill
Cooking with Grill In order to get the best results from the grill, use While the grill is operating, the walls of the the grille that is supplied along with the appliance. cavity and the grille reach very high temperatures. Place the grille in such a position so that it The use of oven gloves is recommended. -
Page 20: Tables And Suggestions - Grill Without Microwave
Cooking with Grill Tables and suggestions – Grill without microwave Food Quantity (g) Time (min.) Tips Fish Dorada 18-24 Spread a light layer of butter on the fish. When half the time has elapsed, turn them Sardine/red scorpion fish 6-8 pcs 15-20 around and sprinkle condiments. -
Page 21: Tables And Tips - Microwave And Grill
Cooking with Grill Tables and tips – Microwave and grill The microwave with grill function is ideal for The microwave and the grill function on an cooking fast and browning meat at the same time. alternate basis. The microwaves cook and the grill It may also be used to prepare foods “au gratin”. -
Page 22: What Type Of Containers May Be Used
What type of containers may be used? • Pay attention to the manufacturer’s instructions Microwave function that are printed on the packaging, In the microwave function, it is important to • Aluminium containers should not be higher remember that the microwaves are reflected by than 3 cm and they should not come into metallic surfaces. -
Page 23: Table – Dishware
What type of containers may be used? Table – dishware Operating mode Microwave Microwave + Grill Grill Type of dish Defrost / heat Cook Glass and porcelain 1) Domestic, non fire-resistant, may be washed in dishwasher Glazed ceramic Fire-resistant glass and porcelain Ceramic, earthenware dishes unglazed glazed without metallic decorations... -
Page 24: Cleaning And Care
Cleaning and care BEFORE CLEANING the microwave, ENSURE 4. Clean accessories after each use. If they are THAT THE PLUG IS NOT IN THE SOCKET. very dirty, steep them first and then use a brush and a sponge. The accessories may be After using the appliance, let it cool off. -
Page 25: Troubleshooting
Troubleshooting The appliance does not function properly: The inside lighting does not come on: • Is the power plug correctly inserted in the • If all of the functions are operating correctly, socket? the bulb is probably blown. You may continue to use the appliance. -
Page 26: Technical Features
Technical Features Description of functions of buttons Symbol Description Power Foods Slow defrosting for delicate foods, keeping food P 01 ---------- 160W Cooking at low heat, boiling rice P 02 ---------- 320W Fast defrosting Melting butter P 03 ---------- 480W Heating baby food Microwave Cooking vegetables and other foods... - Page 27 (MALAYSIA) SDN. TEKA KÜCHENTECHNIK MIDDLE EAST 4 887 2912 teka@emirates.net.ae MIDDLE EAST FZE MEXICO TEKA MEXICANA S.A. de C.V. 555 133 0493 ventas@tekamexicana.com.mx KÜPPERSBUSCH-TEKA PAKISTAN 42 576 1656 42 576 1657 PAKISTAN Pvt. Ltd. POLAND TEKA POLSKA SP. ZO.O.
