NetUP HDMI Encoder 8x
User's manual
NMS Version: 2.2.5
SW: 0.17F
HW: 0.8
August 10, 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDMI Encoder 8x and is the answer not in the manual?

Questions and answers

Related Manuals for NetUP HDMI Encoder 8x

Summary of Contents for NetUP HDMI Encoder 8x

  • Page 1 NetUP HDMI Encoder 8x User’s manual NMS Version: 2.2.5 SW: 0.17F HW: 0.8 August 10, 2015...

  • Page 2: Table Of Contents

    Chapter 4 SNMP Operation ....................... 21   4.1 Installation ............................22   4.2 Software Operation ........................22   4.3 NetUP HDMI Encoder 8x Operation .................... 28   4.4 Other Settings ..........................37   Chapter 5 Troubleshooting ........................41   Chapter 6 Packing list ........................... 42  ...

  • Page 3: Chapter 1 Product Introduction

    Chapter 1 Product Introduction 1.1 Outline The NetUP HDMI Encoder 8x is our newest professional HD audio & video encoding and multiplexing device with powerful functionality. It is equipped with 8 HDMI inputs supporting MPEG-4 AVC/H.264 High Profile code format & main Profile code format and 1 ASI input.

  • Page 4: Specifications

    NetUP HDMI Encoder 8x User’s Manual 1.3 Specifications 8 HDMI inputs Input 1 ASI input, BNC interface 1920×1080_60P, 1920×1080_50P 1920×1080_60i, 1920×1080_50i Resolution 1280×720_60P, 1280×720 _50P 720x576_50i, 720x480_59.95i Encoding MPEG-4 AVC/H.264 high profile level 4.0 Video Bit-rate 0.8Mbps~19Mbps (each channel) Rate Control...

  • Page 5: Principle Chart

    NetUP HDMI Encoder 8x User’s Manual 1.4 Principle Chart 1.5 Appearance and Illustration Front Panel Illustration: 4 5 6 Indicate area: All indicators will light on when the device is on the current working state. LCD Screen Power Indicator TS In: Input Lock Indicator...
  • Page 6 NetUP HDMI Encoder 8x User’s Manual Rear Panel Illustration: 8 * HDMI Input Ports ASI Input Port 2 * ASI Output Ports Data Port (for IP Signal Output) NMS (Network Management Port) Power Switch and socket Grounding Pole 4 / 44 Addr: 119311, Russia, Moscow, Ulofa Palme bldg.1, sect 7...

  • Page 7: Chapter 2 Installation Guide

    This chapter describes:  Checking the possible device loss or damage during the transportation  Preparing relevant environment for installation  Installing the NetUP HDMI Encoder 8x  Connecting signal cables  Connecting communication port (if it is necessary) 2.2.1 Device’s Installation Flow Chart：...
  • Page 8 NetUP HDMI Encoder 8x User’s Manual 2.2.2 Environment Requirements Item Requirement When installing a machine frame array in one machine hall, the Machine Hall Space distance between 2 rows of machine frames should be 1.2~1.5m and the distance against wall should be no less than 0.8m.

  • Page 9: Wire's Connection

    When the device adopts united way, the grounding resistance should be smaller than 1Ω. Caution: Before connecting power cord to the NetUP HDMI Encoder 8x, set the power switch to “OFF” position. 7 / 44 Addr: 119311, Russia, Moscow, Ulofa Palme bldg.1, sect 7...

  • Page 10: Signal Cable Connection

    NetUP HDMI Encoder 8x User’s Manual 2.4 Signal Cable Connection The signal connections include the connection of input signal cable and the connection of output signal cable. The details are as follows: 2.4.1 HDMI input cable illustration: 2.4.2 ASI output cable illustration: 2.4.3 Network Cable illustration (CAT5):...
  • Page 11 NetUP HDMI Encoder 8x User’s Manual 2.4.4 HDMI input interface connection Find the HDMI interface on the device according to the connector mark described on the rear panel illustration, and then connect the HDMI cable (in the accessories). One end is connected to the head-end equipment while the other end to the encoder’s HDMI input port.
  • Page 12 NetUP HDMI Encoder 8x User’s Manual 2.4.6 IP Output Interface connection Find the DATA interface on the device according to the connector mark described on the rear panel illustration, and then connect the network cable (CAT5). Connect one end of the network cable to the encoder’s DATA output connector, and the other end to the TS stream multiplexer...

  • Page 13: Chapter 3 Operation

    NetUP HDMI Encoder 8x User’s Manual Chapter 3 Operation NetUP HDMI Encoder 8x’s front panel has the user interface. Before operating, user can decide whether directly use the default setting or customize the input and output parameters setting. Here is a detailed description of these operations:...

  • Page 14: Video Setting

    NetUP HDMI Encoder 8x User’s Manual the following editing interfaces, the LCD will display the following pages: The option with “►” is the current selection, press the ENTER key to enter the specified submenu to modify the device parameters. 3.2.1 Input Setting Under this menu, users can enter the corresponding encoding channel to set the relevant audio and video input parameters, and select programs to multiplex.
  • Page 15 NetUP HDMI Encoder 8x User’s Manual Press Enter to modify relevant parameter of encoding rate (adjustable range: 0.8M~19M), the specific steps are displayed as follows: 1.1.1.1 Bitrate 8.000Mbps  Bitrate Mode Choose CBR & VBR in this menu. CBR (Constant Bit-rate) means that the bit-rate will be a constant value.
  • Page 16 NetUP HDMI Encoder 8x User’s Manual 1.1.2.1 Bit Rate 1.1.2.2 Format  Audio Bit Rate Setting Set the input audio bit-rate by pressing Enter to enter the main editing screen. And there are: 64Kbps, 96Kbps, 112Kbps, 128Kbps, 160Kbps, 192Kbps, 224Kbps, 256 Kbps, 320Kbps, and 384Kbps options.

  • Page 17: System Settings

    NetUP HDMI Encoder 8x User’s Manual 3.2.1.3 System Settings ►1.1.3.1 Prog Number 1.1.3.2 Video PID 1.1.3.3 Audio PID 1.1.3.4 PMT PID ►1.1.3.5 PCR PID 1.1.3.6 IP Enable 1.1.3.7 Out Address 1.1.3.8 Out Port ►1.1.3.9 Null PKT On this screen, one can set the corresponding system parameters, after setting those parameters, press Enter to apply the changes.
  • Page 18 NetUP HDMI Encoder 8x User’s Manual  IP Enable 1.1.3.6 IP Enable 01/01 [NO]  Out Address/Out Port Setting Modify the out address and out port: 1.1.3.7 Out Address 224.002.002.002 1.1.3.8 Out Port 1002  Null Packet 1.1.3.9 Null Packet...
  • Page 19 NetUP HDMI Encoder 8x User’s Manual 3.2.2 ASI Setting Check the number of ASI input programs on this screen, the LCD will display the following page. Prog: 006 means that the number of input programs is 6 and Out:003 means that 3 of those 6 programs are multiplexed.
  • Page 20 NetUP HDMI Encoder 8x User’s Manual 3.2.3.2 IP Out Address If you enable the IP output function, then you can setup the device’s IP address in the following screen. After you press the Enter, the LCD will display the following page: 3.2.3.3 IP Out Port...

  • Page 21: Asi Output

    NetUP HDMI Encoder 8x User’s Manual 3.2.3.6 ASI Output One can set the ASI output in this screen under this menu, and there are 9 options: MPTS, Channel 1-8. 3.6 ASI Output 01/03 [MPTS] Channel 1 Channel 2 Channel 3 3.2.3.7 UTC Time...

  • Page 22: Network Setting

    NetUP HDMI Encoder 8x User’s Manual 3.2.4 Network Setting Set the network parameters by pressing Enter, the LCD will display the following screens: The MAC address is read-only in the keyboard operation interface, so one can only check the physical address under this interface, and the modification must be done with the network updating tools.
  • Page 23 NetUP HDMI Encoder 8x User’s Manual 3.2.5 Saving Configuration To save the modifications, press Enter, and the LCD will show the following screen: 3.2.6 Loading Configuration In this screen, one can select the modified configuration and the factory default configuration.

  • Page 24: Chapter 4 Snmp Operation

    NetUP HDMI Encoder 8x User’s Manual Chapter 4 SNMP Operation Network Management System SNMP Network management system is applied to digital TV equipment operation, control, management, parameters setting, etc. It allows centralized control of the digital TV equipment over the network.
  • Page 25 NetUP HDMI Encoder 8x User’s Manual 4.2.2 Main Interface User can create a device node tree in the left column by adding, modifying and deleting the device node. This software provides a powerful node operation function, and the user can edit various parameters in the device tree for management and classification.
  • Page 26 NetUP HDMI Encoder 8x User’s Manual 4.2.3 Adding Frequency Point The Add Freq Point dialog box popes up when the user clicks the Add Freq Point item in the Edit pull down menu on the menu row. The device will confirm the given frequency while user clicks OK.
  • Page 27 NetUP HDMI Encoder 8x User’s Manual 4.2.4 Adding Equipment under Given Frequency Point User should choose the frequency point in advance, and then the dialog box of Add Equipment will pop up when user clicks “Add Equipment” item in the Edit pull down menu on the menu row.
  • Page 28 “▼” Or Click “?” to auto search the type of device. NOTE: The default IP for NetUP HDMI encoder 8x is 192.168.0.136, also you can check its IP address in the front panel of device in case the IP changed unexpected.

  • Page 29: Save Configuration

    NetUP HDMI Encoder 8x User’s Manual 4.2.6 Delete Equipment User can choose the equipment to be deleted in the left column, and then click the “delete” item in the pull down menu which appears by clicking the right mouse key.

  • Page 30: Netup Hdmi Encoder 8X Operation

    NetUP HDMI Encoder 8x User’s Manual 4.3 NetUP HDMI Encoder 8x Operation User can choose the encoder in the device tree; the procedure will display the encoder interface in operating area. The interface is mainly composed of encoding video parameters, audio parameters and the encoding system parameters, output parameters and etc.
  • Page 31 NetUP HDMI Encoder 8x User’s Manual Set: to make the current parameters shown in the SNMP software activate. Get: to read the current device’s activating parameters and show them on SNMP software.  IP Out Enable Check the checkbox with a “√”, to enable the IP output (MPTS). Users can decide whether to open the IP output function or not.
  • Page 32 NetUP HDMI Encoder 8x User’s Manual  SDT Insertion In this field, users can decide whether to effect the SDT insertion function.  MPTS Filter Null Packet If this function is effected, then the null packets in IP output stream will be filtered.
  • Page 33 NetUP HDMI Encoder 8x User’s Manual 4.3.2 Multiplexing CH01-CH08: The 8 HDMI Encoding Channels CH09: The 1 ASI Input Channel The programs in the left column represent all input programs and which port they come from, while the programs in the right column represent the output programs and from which port they are from.
  • Page 34 NetUP HDMI Encoder 8x User’s Manual Select the target item and input the new value in the box below, then click to effect the modification. : The parsing overtime value 4.3.3 Tables 4.3.3.1 PID Filter Table 32 / 44 Addr: 119311, Russia, Moscow, Ulofa Palme bldg.1, sect 7 Web: http://netup.tv...
  • Page 35 NetUP HDMI Encoder 8x User’s Manual Users can operate PID filter in this table by checking the check boxes of corresponding items and click CONFIRM to effect. Refresh: getting PID filter table from the device Setting: submitting the PID filter table to the device...
  • Page 36 NetUP HDMI Encoder 8x User’s Manual Input PID and Output PID The Old (Input) PID is the PID number in the TS from given Port. The correspondent New (output) PID number could be same as input PID number while it could be different if a PID remapping is needed.
  • Page 37 NetUP HDMI Encoder 8x User’s Manual ：The parameter describes the output TS’s network ID ：The parameter describes the output TS’s network name. Insertion private description ： This checkbox will allow user to insert the private descriptor into the output TS. The private descriptor includes two parts. One is descriptor tag, and the other is descriptor information.
  • Page 38 NetUP HDMI Encoder 8x User’s Manual up the following dialogue box, say, the added descriptor is apply for the DVB-C network. The interface will show as below after the NIT parameters being added： ：The “Modify” button will trigger a modify window and allow user to modify the selected items in the NIT.

  • Page 39: Other Settings

    NetUP HDMI Encoder 8x User’s Manual 4.4 Other Settings 4.4.1 Difference between Set and Remote Save In many cases during the configuration of parameters in NMS, users save the modified configuration by clicking “Set”, in which way the configuration can only be saved temporarily and will restore the last saved configuration if the device reboots.
  • Page 40 NetUP HDMI Encoder 8x User’s Manual Users can click Operate and select Modify IP in the drop-down list, and a dialog box presents itself as shown below. Users input the new NMS IP Address for the device and click OK button to confirm.
  • Page 41 NetUP HDMI Encoder 8x User’s Manual After finishing all the parameters setting, user should click button on the toolbar to save the modifications to the device’s flash. 4.4.3 User Add When logging in, user will note that the default user name is admin and no password.
  • Page 42 NetUP HDMI Encoder 8x User’s Manual 40 / 44 Addr: 119311, Russia, Moscow, Ulofa Palme bldg.1, sect 7 Web: http://netup.tv Phone: +7 (495) 510-10-25 E-mail: info@netup.tv...

  • Page 43: Chapter 5 Troubleshooting

    NetUP HDMI Encoder 8x User’s Manual Chapter 5 Troubleshooting Precautions:  Install the device at a place with average temperature between 0 to 45 °C  Provide good ventilation for the heat-sink on the rear panel and other heat-sink bores if necessary ...

  • Page 44: Chapter 6 Packing List

    NetUP HDMI Encoder 8x User’s Manual Chapter 6 Packing list  NetUP HDMI Encoder 8x 1pcs  User’s manual 1pcs  HDMI cable 8pcs  ASI cable 1pcs  Power cord 1pcs 42 / 44 Addr: 119311, Russia, Moscow, Ulofa Palme bldg.1, sect 7 Web: http://netup.tv...
