SWAGTRON ST045 Quick Start Manual

Stunt Scooter
Quick Start Guide
BEFORE OPERATING THIS VEHICLE, PLEASE READ ALL INSTRUCTIONS. This guide will walk
you through the functions, usage, and proper care of your SWAGTRON
questions or cannot find the information you need in this guide, please contact your place of purchase or
our customer service at 1-844-299-0625.

Box Contents

1
Front Assembly x 1 Rear Assembly x 1
Axle x 1 Rear Foot Peg x 1
For ST046
Product Overview
2
ST045
1
2
3
7
3
6
8
1
Handle Bars
4
Front Foot Peg
2
Stem
5
Rear Foot Peg
3
Clamp
6
Deck
ST045, ST046, ST047
®
Stunt Scooter. If you have any
Allen Key x 2
Quick Start Guide x 1
For ST046
ST046 ST047
1
2
2
7
3
6
8
5
8
4
7
Brake
8
Turning Fork

Assembling the Scooter

3
1. Place the Stem over the Turning Fork and push it down until it connects with the rest of the scooter.
2. Adjust the front wheel and the Clamp so that the Front Wheel is perpendicular to the Stem.
3. Use one of the included Allen Keys to tighten the Clamp's screws. Make sure the Stem is securely attached
to the Turning Fork before riding.
8
Special Instructions for ST046 and ST047 Scooters
1. Headset bearings, HIC shim, compression cap, and compression bolt come pre-assembled (Figure 1).
2. If the HIC needs to be adjusted, place the HIC shim over the Turning Fork and tighten the bolt through the
top cap and into the top of the fork until there is no headset wobble and the fork rotates freely (Figure 2).
3. Slide the Stem over the Turning Fork (Figure 3).
4. Rotate the Clamp until its opening is centered over the slit in the Stem (Figure 4).
5. Once the Stem and Clamp are properly aligned, use one of the included Allen Keys to tighten the three
bolts on the clamp until it closes around the Stem (Figure 5).
Figure 1
Rear Pedal Installation for ST046 Scooter
1. Unfasten the nut at the side of the rear wheel to remove the original axle that passes through the rear
wheel.
2. Insert the Axle through the wheel and use one of the included Allen Keys to tighten the nut on the other
side. Look over the illustration carefully to be sure all parts are in the right order.
Scooter Usage
4
How to Use Your Scooter
■ Age-appropriate protective gear including an age-appropriate ASTM F1492 approved
1
helmet, elbow pads, knee pads, and wrist guards must be worn at all times.
■ The scooter supports up to 260 lbs (118kg).
You should equip children with suitable protective gear and use the scooter on level surfaces. For your safety,
please carefully read this entire section before attempting to ride. Use with adult supervision and inform your
child of the following safety guidelines.
• Hold both handles firmly.
7
• Put one foot towards the front of the deck.
• With your other foot, push off the ground to propel the scooter forward.
6
• Both feet can fit on the deck when the desired speed has been reached.
• To stop, step on the brake with your rear foot.
Practicing Guidelines
Practice until you are comfortable with using the scooter. See the following tips below.
• Wear casual clothing and flat shoes to maintain your flexibility and stability.
• Practice until you can easily get on, move forward, turn, stop, and dismount with ease.
• Make sure the pavement is even. Do not ride on slopes until you are experienced.
• The scooter is designed for relatively smooth, flat terrain. When riding on uneven terrain, slow down.
• Until you are comfortable using the scooter, avoid riding in places with pedestrians or obstacles.
1
Figure 2 Figure 3
Rear Wheel
Axle Rear Foot Peg Screw Spacers
Figure 5
Figure 4
