Bellari Tube Phono Preamp USB VP530 User Manual

SPECIFICATIONS

I/ O Connectors:
Input Sensitivity:
Input Impedance:
Output Impedance:
Max Output Level:
Equalization:
Rumble Filter:
THD
S/N Ratio:
PWR:
Size:
Weight:
Indicator:

VERY IMPORTANT NOTES:

Occasionally with certain confi gurations, you may experience
excessive hum or buzz. In this case, try connecting the Ground
connection from your turntable directly to your receiver/ampli-
fi er, thus bypassing the VP530.
If you connect the output of the VP530, either the RCA or head-
phone outs, without connecting a turntable to the input - you
will experience noise. The combination of the VP530 and the
turntable (with its RIAA equalization curve) - complete a crucial
circuit for proper operation.
FOR WARRANTY INFORMATION SEE OUR WEBSITE:
WWW.ROLLS.COM
RCA, 1/4" TRS Stereo
30 dB gain @ 1kHz, 47k ohms Input Z
50k ohms
8 ohms Headphone, 100 ohms RCA
>10dB @ 1kHz at at .1% dist.
RIAA +/- 1.5 dB, 20Hz to 20kHz
20Hz
.02% @ 1KHz
>80 dB unweighted
12-15 VDC - 700-1000mA
6"w x 2.5"h x 5.4"d
2 lb
1 Power LED
Bellari is a division of Rolls Corporation
Salt Lake City, UT
01/10
VP530
Tube Phono Preamp USB
ground INPUT OUTPUT
Tube Phono Preamp
VP530
ACTIVE OFF FLAT
MUTE
ON RIAA
MUTE RUMBLE RIAA
FILTER EQ
USER GUIDE
STEREO HEADPHONE/ 12 VAC
LINE OUTPUT
USB
USB
OUTPUT HEADPHONE
LEVEL LEVEL
pwr
