- Page 1 Trinity-300 Series Installation and Operational Guide Repeatit AB Tel: +46 8 570 106 66 Hamngatan 33 Fax: +46 8 570 106 67 172 66 Sundbyberg E-mail: info@repeatit.se Sweden www.repeatit.se...
-
Page 2: Quick Start
Quick start electricity/safety competence and who is familiar with Before proceeding with installation, verify that equipment works on the ground. Power up both units and put them between your computer and network access, you should have full communication within a few minutes of powering up the units. - Page 3 • Adjust the first unit for best signal using the Status LED.
- Page 4 Trinity-300 Series • Make sure all cables are secured and connect the link to the network. • Configure the distance parameters at the master unit to reflect the correct distance between the units. Note Make sure that the polarization on both units is the same.
-
Page 5: Table Of Contents
1.4 Unit description ............... 5 1.5 Installation ................5 1.6 Mounting a Trinity-300 unit ............ 6 Mounting instruction for Trinity-323 and Trinity-316 . . Mounting instruction for Trinity-300 1.7 Ethernet cabling ..............8 1.8 Installing the power supply ........... 8 1.9 Finalizing the installation ............ - Page 6 CONTENTS Trinity-300 Series Extended information ............21 Status information .............. 22 3.2 Link Diagnostic Tools ............... 23 Spectrum analyzer ............. 23 Speed test ................24 3.3 Firmware upgrading ............25 3.4 Restore to defaults ............. 25 4 Support 5 Technical Specifications 6 Usage restrictions and legal information CONTENTS...
-
Page 7: Installation Guide
Installation Guide Who should use this guide Installing fixed outdoor radio links requires technical expertise and should only be carried out by a trained technician. You should only attempt to install and configure the Trinity link if you have • Experience in mounting outdoor radio equipment and aligning antennas. - Page 8 • Drill for wall mounting • Ground cables • Cable ties to secure cabling...
-
Page 9: Unit Description
Unit description There are three LEDs on the units: power, status and Ethernet link/activity. Colour Status Description Power (P) Green Power on Flashing Signal strength pattern Status (S) Green Blinking Firmware upgrade in progress Ethernet (E) Green On/blinking Reflects Ethernet traffic and link status No Ethernet link Installation... - Page 10 updated in the web interface • Distance - should accurately reflect the distance in kilometers between the units.
-
Page 11: Mounting A Trinity-300 Unit
Mounting a Trinity-300 unit A Trinity-300 unit should preferably be mounted in location that allows the unit to be placed high above interfering objects like buildings and trees. Radio masts often provide the best mounting conditions, but when mounting radio equipment with other wireless systems in the vicinity you should always be careful as sufficient isolation between your antenna and other antennas/equipment has to be secured. -
Page 12: Mounting Instruction For Trinity-323 And Trinity-316
Mounting instruction for Trinity-323 and Trinity-318 See the supplied document for detailed mounting instructions. Figure 1 - Trinity-323 and Trinity-318 pole mounting Mounting instruction for Trinity-300 The Trinity-300 is supplied with mounting brackets for pole mounting. 1. Run the pole clamps around the mounting pole. -
Page 13: Ethernet Cabling
Ethernet cabling Run Cat5E Ethernet cable from the location where the PoE is to be installed to the location of the Trinity-300 unit, allow for some slack on the wire to avoid putting extra strain on the Ethernet con- nectors. Make sure the Ethernet cable you are using is rated for outdoor use to avoid decreased cable life time. -
Page 14: Finalizing The Installation
Tip Make a loop on the Ethernet cable indoors near the PoE to allow water to drain more easily from the cable, before reaching the PoEs unprotected Ethernet connector! Connect the PoE port marked ”P+DATA OUT” to the Trinity-300 unit using an outdoor-rated Cat5E Ethernet cable. The PoE port marked ”DATA IN’... -
Page 15: Securing The Installation
Pulses from dBm to dBm 1 pulse 2 pulses 3 pulses 4 pulses 5 pulses 6 pulses Web interface The web interface contains status indicators for both link status and signal strength. Color Status Green Very good signal strength Yellow/green Good signal strength Orange Bad signal strength... -
Page 16: Configuration
Configuration The Trinity-300 series units can be configured via a web interface built-in to the unit or by using the Repeatit network management system, Radio Configuration Software (RCS). Trinity-300 series Configuration concepts The Trinity-300 series features an advanced configuration management system with the ability to roll back to previously working settings, even with automatic rollback in case of link loss. -
Page 17: Configuring Using The Trinity-300 Series Web Interface
Factory defaults Static bare basic configuration. Note The factory default IP address is 10.0.0.1, the default username is “admin” and default password is “public”. Configuring using the Trinity-300 series web interface Both units in your Trinity-300 series link can be fully configured using the built-in web interface. - Page 18 Figure 3 - Configuration tab with highlighted fields. Short description on these three fields: 1. Configuration management pane. Anything related to apply, save or load of configuration changes is handled here. 2. View selector. By changing between Radio settings, Network settings, QoS settings and System settings, the information in the configuration pane is changed to allow you to reach the corresponding settings.
- Page 19 Figure 4 - Click the question mark next to a parameter to see a description of the parameter and selectable parameter values. This example shows the Mode of the unit. How to make configuration changes To make configuration changes successfully, follow the steps that are summarized in the figure and the steps below.
- Page 20 button is clicked. "Egypt" is still the valid configuration. A reboot would completely remove the “Finland” value at this stage. 4. When “Set” was clicked, the configuration pane to the left should also have been populated with an “Apply” button and an option to select “Safe apply”...
-
Page 21: Rolling Back Settings
“Apply” and “Save” by using the dedicated “Restore to default” function available on the “Admin” tab or by using the Repeatit RTD client software, see section 3.4 for more information on this. -
Page 22: Radio Settings
following section describes available configuration parameters in more detail. Radio settings The radio settings control parameters related to the radio interface. Mode A Trinity unit can operate in three different modes as described in the table below. Defines the channel to operate on and the Point-to-Point Master distance to its client. - Page 23 'Client settings' menu (this menu is only available when the node is set to operate as Multi-Point master). Max Transmit rate This setting actually configures the modulation used for transmission. If you change the "Channel bandwidth" the same modulation will be used but the actual data rate is changed as reflected by the bitrate displayed.
- Page 24 Prefered channels Any known bad channel selections can be disabled here, this will stop radar roaming to those channel. Channel bandwidth The bandwidth determines the spacing between available channels and how the frequency spectrum is divided. This effects the available channels. Channel space Controls the steps between individual channels.
-
Page 25: Cac Policy
Max Tx rate master Maximum data rate from the master unit. Note! The value does not always reflect the actual maximum capacity. The capacity could be limited by other settings like channel bandwidth and division of time between master/client. A low limit can destroy for the built in speed test. -
Page 26: Network Settings
Regulates how much buffering that is used. Higher level removes more out-of-order packets but increases latency. Network settings IP-address on this Trinity-300 series unit. Netmask IP-netmask to use. Gateway Specifies the default gateway for this unit. VLAN VLAN (IEEE 802.1Q) ID, range 1-4094. Note Configuring an invalid VLAN ID might result in the loss of Ethernet connectivity if the there is a mismatch with your switch configuration. - Page 27 Note: Beeping turns off 15 minutes after startup or settings change regardless of setting. Use a syncmaster The SyncMaster is a unit that allows several links to operate on the same channel at the same time at a site. Refer to Repeatit’s SyncMaster white paper for more information.
- Page 28 Syncmaster identity The unique identity of a SyncMaster. VLAN id The VLAN id for SyncMaster packets. By default set to 0 (untagged). Policy for lost connection to syncmaster Should the link raise an alarm and go down if the SyncMaster is lost or keep on without the sync? Enable cloud management server Login to the free cloud management server.
-
Page 29: Unit Operation
RSSI level is measured as the difference in received signal strength and noise floor level. Repeatit’s Deployment Guideline explains how to interpret the signal levels and how to install antennas so the link quality is optimized. The two chains should have similar (+/- two-three dB) -
Page 30: Status Information
Figure 12 - The upper part of the status tab gives an indication of Ethernet/Radio connectivity and radio link quality. Radio status Right below the graphical status bars, the Radio Status information is displayed. See figure below. Figure 13 - Radio status information Below is a short description of the Radio Status parameters. - Page 31 The background noise measured by the receiver (dBm). Signal level The received signal level on incoming packets as measured by the receiver (dBm). Tx Rate The Tx Rate of the last incoming packet. By monitoring this value, you get a feeling of which rate the link actually uses. Note that you should check the rate at both sides of the link to get the full picture.
- Page 32 RSSI Ext Chain1 / Chain2 In cases where an additional 20MHz spectrum is used by the link, the remote RSSI for that spectrum is shown here. So this row will only be visible when 40MHz spectrum is configured for the link. Link status The figure below shows the status information of the radio link.
- Page 33 The IP address of the RCS server. Syncmaster Connectivity status of the SyncMaster. If no SyncMaster is configured, the state is “Disabled”. Ethernet The actual rate used on the wired Ethernet link. Radio statistics The figure below shows the radio statistics information. Note that these statistics are aggregates of the last five seconds and that they are intended to be used mainly for troubleshooting purposes.
- Page 34 Consider moving the equipment or change channels. The spectrum scan tool gives useful information (see tools section in this document or refer to Repeatit’s Deployment Guideline). Radar PHY errors Total number of PHY errors received by the radio card that could be potential radar signals.
- Page 35 Retries The number of retransmitted frames over the past 5 seconds. Excessive retries This is the number of radio frames that have been retransmitted the maximum number of times without success, and hence are dropped. Duplicates If the receiver gets the same packet more than once, it means the remote end has not received the acknowledgement packet for the first transmission.
-
Page 36: Link Diagnostic Tools
Link Diagnostic Tools The “Tools” page contains diagnostic tools for optimizing your Trinity- 300 series link. Figure 19 – Tools page. Spectrum analyzer The spectrum analyzer tool assists you in selecting a clear channel free from other radio traffic and with minimum amount of background noise. -
Page 37: Speed Test
analyzer is running! Speed test The integrated speed test will show you the available raw radio throughput (±10%) of your link. The speed test takes approximately 5-10 seconds to complete and does not interrupt normal traffic. Up to 10 test runs are stored (4 shown in the figure below) so that you are able to monitor improvements or link degradations. -
Page 38: Firmware Upgrading
To upgrade the firmware, follow the steps below. 1. Download the latest software to your computer from Repeatits site (http://www.repeatit.se/product- support/trinity/). The result should be that you have the .img file stored. Figure 23 – Download the latest Trinity firmware from the web site. -
Page 39: Restore To Defaults
3. In the pop-up window, click the “Choose file” button (“Välj fil” in the picture below), localize the .img file that you downloaded and then click “Upgrade Firmware”. Figure 25 – Select file and click “Upgrade Firmware”. 4. When the firmware is loaded and written to the flash disc, the node has to be rebooted (you can select this to be automatically done). - Page 40 3. There is also Restore to default client software available at http://www.repeatit.se/support. This software will automatically detect any Repeatit units within the first few minutes after boot, and allows you to restore the unit to its default settings.
-
Page 41: Support
Support Support as well as firmware updates for the Trinity-300 product series can be obtained from Repeatits web site at http://www.repeatit.se. There you will also find product news, FAQs and other useful information related to our products. -
Page 42: Technical Specifications
Technical Specifications Trinity-316 Plus Trinity-323 Plus Trinity-300 Radio Frequency Bands 5.150 - 5.845 GHz 5.150 - 5.845 GHz 5.150 5.845 GHz Channel widths supported 10/20/40 MHz 10/20 10/20/40 MHz(Plus) 10/20/40 MHz Capacity 190 Mbps aggregated 100/190(Plus) Mbps aggregated 190 Mbps aggregated... -
Page 43: Usage Restrictions And Legal Information
5GHz bands. Requirements for individual countries may change, Repeatit recommends that you check w i t h your local regulatory agency for the latest status on regulations for 5GHz fixed radio links. - Page 44 Denmark In Denmark, the band 5150-5350 MHz is also allowed for outdoor useage. Italy The use of 5.8GHz (5725-5850 MHz) is forbidden in Italy. United Kingdom A license from Ofcom (ofcom.org.uk) is required for use of the 5.8GHz (5725.5850 MHz) band in the United Kingdom.
- Page 45 4. The warranty is not valid if service is performed on the product by a, by Repeatit, non-unauthorized person or company. 5. The warranty is not valid if any products that are not Repeatit original accessories are used with the product.
