REPEATIT Trinity-123 Lite Quick Start Manual

Trinity-100 Lite Series Quick Start Guide
http://www.repeatit.se/support/trinity/trinity100lite.html
Before you start climbing verify that the equipment works on the ground. Power up both units
and put them between your computer and network access, you should have full communication
within a few minutes of powering up the units. (If the units have no internal antenna make sure
you place the antenna connectors directly opposite each other.)
The units are pre-configured and paired from factory with the following parameters.

Setting up the link

• Mount the first unit, point it towards the site of the second unit. Power it up and make sure
the Power LED is lit and the status LED blinks slowly.
• Mount the second unit. Power it up and adjust it for best signal using the status LED.
• Adjust the first unit for best signal using the Status LED.
• Make sure all cables are secured and connect the link to the network.
• Configure the distance parameters at the master unit to reflect the correct distance between
the units.
Note Make sure that the polarization on both units are in the same direction. Unaligned
polarization will significantly reduce the signal strength.

Package contents

Trinity-100 Lite
2 Trinity-100 Lite units
with N-female antenna
connector
2 Mounting kits
2 PoE with power adapter
for your local region.
2 IP65 RJ-45 connectors.
Repeatit AB
Hamngatan 33
172 66 Sundbyberg
Sweden
The full manual can be retrieved from
Master
IP address 10.0.0.1
Username admin
Password public
Trinity-116 Lite
2 Trinity-116 Lite units
with integrated 16 dBi
antenna.
2 Mounting kits.
2 PoE with power adapter
for your local region.
Client
10.0.0.2
admin
public
Trinity-123 Lite
2 Trinity-123 Lite units
with integrated 23 dBi
antenna.
2 Mounting kits.
2 PoE with power adapter
for your local region.
2 IP65 RJ-45 connectors.
Tel: +46 8 570 106 66
Fax: +46 8 570 106 67
E-mail: info@repeatit.se
www.repeatit.se
