Eterna BULKLED Installation Instructions

LED LAMP SPECIFICATIONS:
900 lm
Lumens total flux
Rated Wattage 11.2W
Rated luminous flux 900 lm
Nominal life time of the lamp 30,000 hrs
Colour temperature 6500K
Number of switching cycles
before premature lamp ≥15,000
failure
Warm-up time up to 60 % of
Instant full light
the full light output
Dimmable No
Nominal beam angle 120°
Rated power 11.2W
Rated lamp lifetime 30,000 hrs
Lamp power factor >0.5
Lumen maintenance factor at
>80%
end of nominal life
Starting time <0.5s
Colour rendering ≥80
Within 6 step
Colour consistency
Macadam ellipse
Rated peak intensity 230cd
Rated beam angle 120°
Voltage 240V
Not suitable for accent lighting
EVENTUALLY, YOU MAY WANT TO
REPLACE THIS PRODUCT:
Regulations require the recycling of Waste from
Electrical and Electronic Equipment (European
"WEEE Directive" effective August 2005—UK
WEEE Regulations effective 2nd January 2007).
Environment Agency Registered Producer: WEE/
GA0248QZ.
WHEN YOUR PRODUCT COMES TO THE END OF
ITS LIFE OR YOU CHOOSE TO REPLACE IT, PLEASE
RECYCLE IT WHERE FACILITIES EXIST - DO NOT
DISPOSE WITH HOUSEHOLD WASTE.
Email: sales@eterna-lighting.co.uk / technical@eterna-lighting.co.uk
www.eterna-lighting.co.uk
Visit our website:
Issue 1117
MODELNO.
BULKLED/PC/MW
874/2012
LAMP REPLACEMENT:
The light source is designed to last the lifetime of the
luminaire.
The light source contained in this luminaire
shall only be replaced by the manufacturer,
service agent or a similar qualified person.
CAUTION, RISK OF ELECTRIC SHOCK.
CLEANING:
Clean this light fitting only with a soft dry cloth.
Do not use any chemical or abrasive cleaners.
IF YOU EXPERIENCE PROBLEMS:
If you believe your product is defective, please return
it to the place where you bought it. Our Technical
Team will gladly advise on any Eterna Lighting
product, but may not be able to give specific
instructions regarding individual installations.
Made in China
INSTALLATION INSTRUCTIONS
A guide for qualified electricians
L
N
Model:
BULKLED / BULKLEDPC / BULKLEDMW
11W IP65 LED Bulkhead / With Photocell / With Microwave Sensor
These instructions are provided as a guideline to assist you.
PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLATION
AND RETAIN FOR FUTURE REFERENCE
Photocell
version
shown
Pack contents:
1 x 11W LED bulkhead
1 x Fixing kit
1 x TRS gland
Daylight
Antenna
Sensor
Module
BULKLEDMW
Microwave
Sensor
L1
Daylight
-
Time
5 sec - 12 min
Sensitivity
10-100%
