PROFESSIONAL HOT AIR GUN KIT
- WITH LCD DISPLAY
Adjustable temperature between 60 - 600
230v~50Hz, with 2 metre
industrial grade rubber power
cord fitted with a 3 pin plug.
3 stage airflow switch and
digital LCD temperature adjuster.
Supplied with 4 detachable
nozzles and a paint scraper.
Stainless steel nozzle outlet and detachable
heat protection sleeve allows for access into
narrow areas.
Overheating protection.
Can be used free standing on a work surface facing
upwards for hands free use.
Air inlet with lattice guard to keep out foreign matter.
Supplied in a tough blow moulded carrying case.
Used for a wide range of jobs safely and reliably,
such as soldering, welding PVC, shaping, drying,
shrink-fitting, stripping paint, removing sticky labels etc.
WARNING: THE SAFETY INFORMATION
GIVEN INSIDE MUST BE READ AND
UNDERSTOOD BY ANY PERSON
OPERATORS MANUAL
Please retain this information for future reference.
MODEL HAG200-D
ORDER CODE KBE-279-2140K
USING, INSTALLING, REPAIRING
OR MAINTAINING THIS PRODUCT
2000W
°
C.
ALWAYS WEAR
APPROPRIATE
PERSONAL
PROTECTIVE
EQUIPMENT.
Digital LCD
temperature display
Advertisement
Table of Contents
Related Manuals for KOBE HAG200-D
Summary of Contents for KOBE HAG200-D
- Page 1 PROFESSIONAL HOT AIR GUN KIT 2000W - WITH LCD DISPLAY MODEL HAG200-D ORDER CODE KBE-279-2140K ° Adjustable temperature between 60 - 600 230v~50Hz, with 2 metre Digital LCD industrial grade rubber power temperature display cord fitted with a 3 pin plug.
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS KOBE INDUSTRIAL POWER TOOLS have been specifically designed to help you work SAFELY and EFFICIENTLY. Your care and good judgement are the best protection against injury, but always ensure that the appropriate safety equipment is worn. All possible hazards cannot be covered here, but the most relevant ones have been highlighted. - Page 3 TECHNICAL DATA & PARTS SPECIFICATIONS MODEL NUMBER ........HAG200-D WEIGHT - GUN ..........910g ORDER CODE ........KBE-279-2140K NET WEIGHT ........... 2.2Kg POWER SUPPLY ........230V~50Hz AIRFLOW AND TEMPERATURE ........INPUT POWER ..........2000W Stage I 350L/min 60°C (140°F) DIMENSIONS - GUN ..190(H) x 270(W) x 80(D)mm...
- Page 4 OPERATION Always use the correct supply voltage! The voltage of the power source must be the same as the value given on the rating plate of the unit. Units designed for 230V can also be operated with 220V. SWITCHING ON/OFF & SETTING THE AIRFLOW TEMPERATURE Ensure that the Hot Air Gun is switched OFF (O) before connecting it to the power supply or when attaching any nozzles to it!
- Page 5 OPERATION REMOVING THE HEAT GUARD SLEEVE CAUTION - Be careful of the hot nozzle! There is an increased danger of burning when working without the heat guard. For working in especially narrow places, the Heat Guard can be removed. 1. To remove or mount the heat guard, the unit must be in the "OFF" position and be allowed to cool down until cold.
- Page 6 WORKING EXAMPLES Temperature settings given in the application examples All application examples (except B) can be performed are suggested values that depending on the material without accessories. However, the use of the characteristics, can deviate. The distance between the recommended accessory parts simplify the work and nozzle and work piece is dependent on the material to significantly improve the quality of the results.
- Page 7 Place on the reflector nozzle (5). Heat the frozen zone always from the outside to the middle . Be especially careful when warming plastic pipes and connections between pipe pieces to prevent damage. ACCESSORIES Available from your local KOBE agent. REDUCTION REFLECTOR SURFACE WINDOW...
-
Page 8: Declaration Of Conformity
Please retain supplier invoice as proof of purchase. DECLARATION OF CONFORMITY We hereby certify that KOBE HAG2000-D Professional Hot Air Gun - with LCD Display complies with all the relevant provisions of the following directives: Electromagnetic Compatibility 2004/108/EC and Low Voltage 2006/95/EC.
