Swissvoice ePure HD Manual

Cordless handset (DECT)
Internet:
www.swissvoice.net
© Swissvoice SA 2015
All rights as well as delivery possibilities
and technical changes reserved.
20408041en_qs_epure_hd_a1
SV 20408041
Welcome to swissvoice
Thanks for choosing ePure HD.
The ePure HD handset is aimed to be
used with a CAT-iq 2.0 base station or
gateway to ensure full functionality.
Registered to a GAP or CAT-iq 1.0
base, the handset supports incoming
and outgoing external calls, and
features a local phonebook and a
local call list to ensure proper
functionality.
The ePure HD offers excellent voice
quality, including HD Voice calls.
The HD Voice sound quality is richer,
more dynamic, and offers a better
listening experience. Now callers can
feel closer to each other.
Setting your handset
Contents of the package
- 1 handset
- 1 charging station
- 1 power supply MN-A002-A080,
7.5 V , 300mA from MEIC
- 1 rechargeable battery
Li-Ion 3.7 V / 550 mAh
1- Make sure the base station
is ready
To register your handset you must
install a base station or gateway first!
Check in your base station user
manual, how to register a DECT
handset, and open the registration
mode.
2- Insert the battery
Install the battery pack the right way
in the handset battery compartment:
position the 3 metal contacts of the
battery pack against the 3 blade
contacts.
Green dots
Place the cover: align the green dot
on the handset with the one on the
cover. Align the cover top against the
handset top, then press until middle
and bottom sides click into place
3- Select the language
Press to scroll to the desired
language. Confirm with OK.
4- Installation assistant
The handset is starting the installation
process to register the handset. Press
OK when ready.
5- Select the base
Choose your gateway or base in the
compatibility list displayed. If your base
does not appear in the list, select
OTHER BASE. Confirm by OK.
6- Register the handset
The handset is starting the registration
process. In case the base does not use
0000 as a system pin code, the handset
will request the pin.
Make sure the base station is in registra-
tion mode (see the base user manual).
7- Finalize the installation
After successful registration the hand-
set is automatically assigned a name
(e.g. DECT 1, INT 1 or Handset 1).
If you have registered to a base where
the time can not be synchronised, the
handset will ask you to setup the
time.
If you have more than one IP line: you
can select the line(s) the handset will
ring for and the default outgoing line.
8- Connect the charger
Main power socket
Insert the plug into the correspon-
ding socket on the charger. Then
insert the power supply in the 230 V
socket.
9- Congratulations ! You have
now set up your ePure HD.
For proper operation of the handset
the battery must be fully charged
initially. The battery will take around
4 hours to fully charge
.
User manuals
For complete operating instructions
about your new ePure HD, please
download the user manual from our
website :
http://product.swissvoice.net/en/epure-hd
Troubleshooting
Start the installation process again if you
fail to register your ePure HD with the
base station. Press «OK».
«Our contacts», and shared call lists are
CAT-iq 2.0 functions not available with
GAP bases; when registered to a GAP
base, «My contacts» and local call lists are
available.
Fulleco/NEMO (non-emission mode),
SUOTA, HD Voice and Repeater features
must also be supported and enabled by
the base station in order to work with the
ePure HD handset.
Your ePure-HD Fulleco functionality is
based on the DECT CAT-iq 2.0 NEMO
standard. Some base stations are using
non-emission modes not compatible with
the DECT NEMO standard. If the handset
is loosing lock in idle or is not ringing
when some incoming calls are presented
to the base, please disable the non-emis-
sion mode on the base.
Some functionalities may be available or
not from base to base, please refer to our
website for more information.
Some functionalities may not be available
depending on your network operator.
Support
If you have any questions about products,
please visit our FAQ on:
www.swissvoice-faq.net
In case you need additional help, please
contact Swissvoice Customer Service
either through :
www.swissvoice.net/contact or
on freephone number 00 800 10 18 10 10.
Warranty conditions
Your telephone is subject to a guarantee from the
date of purchase in accordance with the legal
provisions of the country in which the telephone
was purchased. As evidence of the date of
purchase, please keep the receipt or the warranty
card completed by the retailer. All defects attribut-
able to material and manufacturing faults will be
corrected free of charge within the warranty period,
either by repairing or replacing the defective
equipment. The warranty does not cover expend-
able materials (battery cells), defects which affect
the value or use of the equipment only insignificant-
ly, and damage caused by incorrect use, ordinary
wear and tear, or manipulation by third parties. This
warranty does not cover consequential damage
caused by the use, failure or defectiveness of the
product. In particular, no liability whatsoever is
accepted for damage to property and pecuniary
loss. To claim under this warranty, please contact
the retailer where you purchased your telephone.
