Muji WORKING CHAIR Assembly Instruction

WORKING CHAIR
JAN# 4548718121298
Assembly Instruction
Parts List
③
Parts Q'ty
for
Leg
for
Sea
for
Back
①
Caution:
Do not disassemble parts #02
(Gas Spring).
It may burst and cause injury.
②
⑤
Plate
Remove Parts# 05~08 from back side of # 04.
Ope
When assembling,
use a rug to protect
floor from damage.
Square hole for
Long-Bolt
Square
④
Remove Part# 11, and then Part#10 from
slide out
pull out
pull out
Open
Pull to open the bottom part of
#11 in indicated direction by
hand.
Use string into pull out #11 if it is
Caution:
Do not break Part# 11.
Keep reach of out of children.
Carefully handle sharp edges.
Put together Parts# 09 and # 04.
Long-Bolt
Metal Base
⑥
Put Parts# 10 and # 11 back
Long-Bolt
Pipe of Metal Base
Metal Base
⑦
Put Parts# 05~08 back together.
Top
Botto
Long-Bolt
Lift up
Lift up the square bottom
part to attach to the plate
and make sure long-bolt is
fastened firmly.
Caution:
When you loosen the handle
to adjust the seat back,
please remain at least 1mm
(0.04 inch) of top of
Long-Bolt to avoid the parts
coming off.
⑧
Close
Usage Instruction
1) Seat height adjustment
Please be seated and push the lever up to make the seat
higher.
2) Use handle to adjust the rocking of the seat back.
Caution:
Do not too much
loosen the handle. It
may make the seat
back to come off
and cause injury.
Top of Long-Bolt
Show
more
than
1mm
(0.04
Tighten Loosen
Caution:
Do not stand up
on chair or use
as stool.
Keep away from
fire.
Lever
Handl
