ENDEAVOUR ET3560 Owner's Manual

CARE & MAINTENANCE
1. Keep body face clean, prevent liquid material from getting into slider
to destroy electronics.
2. Face should be cleaned with a clean, dry, lint-free cloth. Lubricate
body with a few drops of clock oil. Acetone & alcohol must not be used.
3. Keep battery compartment clean and free of corrosion.

TROUBLESHOOTING

PROBLEM: SOLUTION:
Every second 5 digits Battery voltage is under 1.45V. Remove
jump simultaneously cover and replace battery.
Display cannot count Faulty circuit. Remove battery, after 30
sec. put battery back into compartment.
Display shows 000.00 Function buttons and sliders signal end
or IN 00.000 may have shorted out. Remove the
cover, put the button springs in place
with rubber covers. Contact must be
unobstructed.
Function buttons not active Springs or rubber covers may be out of
shape due to excessive pressing. See
solution above for tips.
Reading error for full Sensor may have dirt or deposits in it
length is ≥ 0.1mm
Remove cover and slider assembly.
Blow off sensor face with clean
pressurized air (≥5kg/cm squared),
clean with a dry, lint-free cloth.
No display on LCD screen 1.) Poor battery contact. Check battery
compartment, clean if necessary.
2.) Battery voltage is under 1.3V.
Replace with correct battery.
Digital Caliper
O W N E R ' S M A N U A L
FOR YOUR SAFETY, and
CARE OF THIS TOOL
Please read these instructions
carefully and retain them for future use.
E T 3 5 6 0
03.04.0487ECC
In accordance with the
European Directive
ROHS 2002/95/CE
D4 06 07 60503 001
