Duarib Tandem 7 Instruction Manual

TANDEM 7 PLIANT (FOLDING) INSTRUCTION MANUAL
(Compliant with norm NF P 93-352 ie PIR)
WORKING LOAD: 150 Kg
FLOOR SIZE: 0.40m x 0.50m
FLOOR HEIGHT - 4 settings:
T7P adjustable legs (18176)
1,72m 2,07m
1,49m 1,89m
1,26m 1,72m
1,03m 1,53m
Length: 1,74m
Height: 0,52m
Weight: 30,6 Kg
Length

2. Use: - Opening:

Déplier la partie garde-corps puis
vérifier la mise en place des verrous.
Open the device by
pulling on the wheel
side, legs touching
the ground.
Moving while in working
setup:
- Hold the empty platform by the
legs on the access side. The
wheels touch the ground and the
stabilizers are retracted or not,
depending on the environment.
2,45m
2,52m
2,44m
2,13m

1. Product description and marking code:

These Plates-formes Individuelles Roulantes (Individual Rolling
Platform, IRP) are used to work safely in heights.
Two wheels are designed to move the I.R.P. and they cannot be
moved.
Two independent stabilizers are telescopic, the locking is automatic
and the product's stability is guaranteed in fair use conditions as
recommended by the norm.
Check the floor lock is
set.
Route de la Limouzinière BP41
44310 St PHILBERT DE GRAND LIEU
Phone: +33 (0)2 40 78 97 22
Fax: +33 (0)2 40 78 78 71
www.duarib.fr
Pull the stabilizer to
the ground.

Transport:

- Once the platform is
folded, lift it by the
safety handrail.
D040363B
Open the safety rails
and place the upper
bar so it touches
them.
1/2
