Summary of Contents for SVOA M521N

  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety Warning uninterrupted power supply.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...

  • Page 15: Table Of Contents

    Preface Contents Notice .................I System Map: Right View ..........1-11 FCC Statement .............II System Map: Bottom View ..........1-12 Instructions for Care and Operation ......IV Windows XP Start Menu & Control Panel ....1-13 Power Safety .............. VI Video Features .............1-14 Battery Precautions ...........VII Display Devices &...
  • Page 16 Preface Power Management Authorized Driver Message .........4-4 Version Conflict Message ...........4-4 Overview ................3-1 Updating/Reinstalling Individual Drivers ....4-4 Advanced Configuration and Power Interface ....3-1 Driver Installation ............4-5 The Power Sources ............3-2 Service Pack Installation ..........4-6 AC/DC Adapter ............3-2 New Hardware Found ..........4-6 Battery .................3-2 Manual Driver Installation .........4-6 Turning on the Computer ..........3-3...
  • Page 17 Preface Non-Fatal Errors ............5-3 Upgrading The Computer The Setup Program ............5-4 Overview ................6-1 Entering Setup .............5-4 When Not to Upgrade ..........6-2 Setup Screens ...............5-5 Removing the Battery ............6-3 Main Menu ..............5-6 Upgrading the Hard Disk Drive ........6-4 System Time & Date (Main Menu) .......5-6 Upgrading the Optical (CD/DVD) Device ....6-6 IDE Channel 0/1 Master (Main Menu) ......5-7 Upgrading the System Memory (RAM) ......6-8...
  • Page 18 Preface Troubleshooting Optional Port Replicator Ports and Jacks .....A-5 DC-In Jack ..............A-5 Overview ................8-1 External Monitor (VGA) Port ........A-5 Basic Hints and Tips ............8-2 Parallel Port ..............A-5 Backup and General Maintenance .........8-3 Serial Port ..............A-5 Viruses ................8-4 RJ-45 LAN Jack ............A-5 Upgrading and Adding New Hardware/Software ..8-5 USB 2.0/1.1 Ports ............A-6 Problems &...
  • Page 19 Preface Video Adapter ............... C-3 Storage ................C-3 Audio ................C-3 Keyboard & Pointing Device ........C-3 PCMCIA ............... C-4 Card Reader ..............C-4 Interface ................ C-4 Communication ............. C-4 Power Management ............C-4 Power ................C-5 Environmental Spec ............C-5 Dimensions &...
  • Page 20 Preface XVIII...

  • Page 21: Quick Start Guide Overview

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 22: Model Designs

    Quick Start Guide Model Designs This notebook series includes two different model designs which vary slightly in color and appearance. However both designs incorporate the same features, ports and jacks etc. Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install”...

  • Page 23: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows XP) and applications (e.g. word processing, spreadsheet and database pro- grams) have their own manuals, so please consult the appropriate manuals. System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find this manual refers to the Microsoft Win- dows XP (Home &...

  • Page 24: System Startup

    Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter (Note: If you have included the Port Replicator in your purchase option see page...

  • Page 25: System Map: Top View With Lcd Panel Open

    Quick Start Guide System Map: Top View with LCD Panel Open Optional PC Camera Wireless Device Built-In Speakers * 2 Operation Aboard LED Status Indicators Aircraft Hot-Key Buttons Power Button The use of any portable Keyboard electronic transmission de- TouchPad and Buttons vices aboard aircraft is usu- ally prohibited.

  • Page 26: Led Indicators

    Quick Start Guide LED Indicators Icon Color Description The two sets of LED indicators (LED Status Indica- Green The Computer is On tors and LED Power & Communication Indicators) Blinking The Computer is in Stand by on the computer display helpful information about the Green Mode current status of the computer.

  • Page 27: Hot Key Buttons & Keyboard

    Quick Start Guide Hot Key Buttons & Keyboard The keyboard has an embedded numerical keypad for easy numeric data input, and features Function Keys to These buttons give instant access to the default Inter- allow you to change operational features instantly (see net browser, e-mail program, and the EMAMCAP Figure 1 - 3).

  • Page 28: Function Keys

    Quick Start Guide Function Keys To use the function keys, press and hold the Fn key, then press the appropriate function key (F1 - F12 etc.). Function Function Function Key Fn + F8 Decrease LCD Brightness Special Characters Fn + F1 TouchPad Toggle Fn + F9 Increase LCD Brightness...

  • Page 29: System Map: Front & Rear Views

    Quick Start Guide System Map: Front & Rear Views Figure 1 - 4 Front & Rear Views LED Power & Communication Indicators 4-in-1 Card Reader Optional PC Camera 7-Pin S-Video-Out Jack RJ-11 Phone Jack Battery Slot (Battery Removed) Security Lock Slot 4-in-1 Card Reader The card reader allows you to use the most popular digital storage card formats: MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /...

  • Page 30: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 5 - Left View DC-In Jack External Monitor Port Mini-IEEE 1394 Port RJ-45 LAN Jack Vent/Fan Intake/Outlet 2 * USB 2.0 Ports PC Card Slot (see page Mini-IEEE 1394 Port The Mini-IEEE 1394 Port only supports SELF POWERED IEEE 1394 devices.

  • Page 31: System Map: Right View

    Quick Start Guide System Map: Right View Figure 1 - 6 - Right View 1 * USB 2.0 Ports Headphone-Out/Speaker-Out Jack Microphone-In Jack S/PDIF-Out Jack Line-In Jack Optical (CD/DVD) Device Drive Changing DVD Regional Codes Bay (see page The pictured system includes the 8-Cell Extended battery Go to the Control Panel and double-click System >...

  • Page 32: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 7 - Bottom View Battery Component Bay Cover Hard Disk Bay Cover Battery Information Always completely dis- charge, then fully charge, a new battery before us- ing it. Completely dis- charge and charge the The CPU is not a user serviceable part.

  • Page 33: Windows Xp Start Menu & Control Panel

    Quick Start Guide Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 34: Video Features

    Quick Start Guide Video Features Your computer will have built-in Intel (Intel GMA 950) on-board video. You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the appropriate vid- eo driver is installed. For more detailed video information see “Intel Video Driver Controls”...
  • Page 35 Quick Start Guide Figure 1 - 9 - Display Properties Desktop Intel Display Mode Description Single Mode One of the connected displays is used as the display device Intel(R) Dual Display Clone Mode Both connected displays output the same view and may be configured independently Extended Desktop Mode Both connected displays are treated as separate devices, and act as a virtual desktop Table 1 - 5 - Display Options...

  • Page 36: Power Management Features

    Quick Start Guide Power Management Features The Power Options control panel icon in Windows (see page 13) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk (by means of Power Schemes), or you may use either Stand by or Hibernate mode to conserve power throughout the system (enable Hibernate support from the control panel as pictured in Figure 1 - 10).

  • Page 37: Features & Components Overview

    Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • 4-in-1 Card Reader • PC Card Slot •...

  • Page 38: Hard Disk Drive

    Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.

  • Page 39: Optical (Cd/Dvd) Device

    Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 3). The Adjustment optical device is usually labeled “Drive D:”...

  • Page 40: Handling Cds Or Dvds

    Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.

  • Page 41: Dvd Regional Codes

    Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 DVD Regional Region Geographical Location Coding USA, Canada Western Europe, Japan, South Africa, Middle East & Egypt Figure 2 - 3 South-East Asia, Taiwan, South DVD Regions...

  • Page 42: 4-In-1 Card Reader

    Features & Components 4-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).

  • Page 43: Pc Card Slot

    Features & Components PC Card Slot The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PCMCIA PC Card Slot Cover CardBus PC Card Slot. Make sure you install the PCMCIA/Card Reader Card driver (see “PCMCIA/Card Reader” on page 4 - Make sure you keep the cover in the PC Card Inserting and Removing PC Cards...

  • Page 44: Touchpad And Buttons/Mouse

    Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an exter- nal mouse your operat- ing system may be able...

  • Page 45: Audio Features

    Features & Components Audio Features You can configure the audio options on your computer from the Sounds and Audio Sound Volume Devices Windows control panel, or from the Realtek HD Audio Manager Adjustment icon in the taskbar/control panel (this will bring up the Realtek Audio Configuration menus).

  • Page 46: Adding A Printer

    Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- ble to the printer.

  • Page 47: Power Management Overview

    Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer uses the ACPI functions will vary slight- power management system. Power management conserves power by controlling in- ly depending on your dividual components of the computer (the monitor and hard disk drive) or the whole operating system.

  • Page 48: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack on the left of the computer.

  • Page 49: Turning On The Computer

    Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shutdown er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Stand by/Hibernate/ ways shut your comput- er down by choosing the Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and...

  • Page 50: Power Schemes

    Power Management Power Schemes You can set your computer to conserve power through individual components by Resuming means of Power Schemes. You can also adjust the settings for each scheme to set Operation the monitor to turn off after a specified time, and the computer's hard disk motor to turn off if the hard disk drive has not been accessed for a specified period of time (if The system can resume the system reads or writes data, the hard disk motor will be turned back on).
  • Page 51 Power Management Each Windows Power Scheme will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experienc- ing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the com- puter is powered from an AC power source.

  • Page 52: System Power Options

    Power Management System Power Options You can use the system power options to stop the computer’s operation and restart where you left off. This system features Stand by and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - Figure 3 - 2).

  • Page 53: Stand By

    Power Management Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle System Resume at its slowest speed.

  • Page 54: Configuring The Power Button

    Power Management Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hiber- nate mode (Figure 3 - 3). In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery) or orange (AC/DC adapter). If you are in a power saving mode set to save power through individual components (e.g.

  • Page 55: Battery Information

    Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ” When the battery is criti- cally low, immediately on page 3 - 12 for instructions on how to do this).

  • Page 56: Recharging The Battery With The Ac/Dc Adapter

    Power Management Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. Conserving Battery Power We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...

  • Page 57: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.

  • Page 58: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t Caution turn off the computer by yourself even when you see a message that indicates the Danger of explosion if battery is critically low, just let the computer use up all of the battery power and shut battery is incorrectly re-...

  • Page 59: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual CD- of the computer’s subsystems. The system takes ad- ROM contains the drivers and utilities necessary for vantage of some newer hardware components for the proper operation of the computer (the optional...
  • Page 60 Drivers & Utilities Navigate (Browse..) to D: You will notice that many of the instructions for driver in- stallation require you to “Navigate (Browse) to D:”. We assume that you will install all drivers and utilities from the built-in CD device and it is assigned to “Drive D:”. In addition, all file extensions can be seen In this case “D:”...

  • Page 61: Service Packs

    Drivers & Utilities Service Packs Check the warnings on the following pages regarding installation of the appropriate Service Pack for your Windows XP Service Pack 2 Windows OS. Make sure you have installed the appro- priate Service Pack before installing all the drivers. Make sure you install Windows XP Service Pack 2 (or a Windows XP version which includes Service Pack 2) before installing any drivers.

  • Page 62: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message Updating/Reinstalling Individual Drivers If you receive a message telling you that the driver you If you wish to update/reinstall individual drivers it are installing is not authorized (Digital Signature Not may be necessary to uninstall the original driver.To do Found), just click Yes or Continue Anyway to ignore this go to the Control Panel in the Windows OS and the message and continue the installation procedure.

  • Page 63: Driver Installation

    Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1 on page 4 - 6 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the CD-ROM and click Install WinXP Drivers (button), Drivers Installer menu below.

  • Page 64: Service Pack Installation

    Drivers & Utilities Service Pack Installation WinXP SP2 Driver Page # Make sure you install the appropriate service pack for your operating system before installing any drivers Install the appropriate Service Pack for WinXP Page 4 - 3 (see “Windows XP Service Pack 2” on page 4 - Chipset Page 4 - 7 Video...

  • Page 65: Chipset

    Drivers & Utilities Chipset Audio 1. Click 1.Install Chipset Driver > Yes. 1. Click 3. Install Audio Driver > Yes. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse..) to (Browse..) to D:\Drivers\00Chipset\setup.bat and click D:\Drivers\02Audio\Setup.exe and click OK.

  • Page 66: Modem

    Drivers & Utilities Modem 1. Click 4.Install Modem Driver > Yes. 1. Click 5.Install LAN Driver > Yes. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse..) to (one of the following): (Browse..) to D:\Drivers\03Modem\Conexant\Setup.exe D:\Drivers\04LAN\Setup.exe D:\Drivers\03Modem\Moto\ssetup.exe...

  • Page 67: Touchpad

    Drivers & Utilities TouchPad PCMCIA/Card Reader 1. Click 6.Install TouchPad Driver > Yes. 1. Click 7.Install PCMCIA Driver > Yes. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse...) to (Browse...) to D:\Drivers\05Touchpad\Setup.exe and click D:\Drivers\06PCMCIA\setup.exe and click 2.

  • Page 68: Wireless Lan

    Drivers & Utilities Wireless LAN Bluetooth See install procedure in “Intel PRO/Wireless WLAN See install procedure in “Bluetooth Driver Installa- Module” on page 7 - 2 “802.11 b/g USB WLAN tion” on page 7 - Module” on page 7 - Port Replicator PC Camera See install procedures in...

  • Page 69: Bios Utilities Overview

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The Setup utility up Defaults with <F9>.

  • Page 70: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...

  • Page 71: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 72: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and manage ba- sic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 5 - 1 on page...

  • Page 73: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with five (5) menu headings. When you Setup menus select a heading, a new screen appears. Scroll through the features listed on each shown in this section are screen to make changes to Setup.

  • Page 74: Main Menu

    BIOS Utilities Main Menu Figure 5 - 2 PhoenixBIOS Setup Utility Main Menu Main Main Advanced Security Boot Exit Item Specific Help System Time: [16:11:05] System Date: [05/21/2006] <Tab>, <Shift Tab>, or IDE Channel 0 Master [FUJITSU MHV2060BH-(S1)] <Enter> selects field. IDE Channel 1 Master [UJDA770 DVD/CDRW-(SM)] System Memory:...

  • Page 75: Ide Channel 0/1 Master (Main Menu)

    BIOS Utilities IDE Channel 0/1 Master (Main Menu) Press Enter here to open the sub-menu to show the configuration of hard disks and CD/DVD device(s) on the computer’s IDE Channels. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable.

  • Page 76: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Advanced Security Power Boot Exit Item Specific Help Chipset Information Menu Display Chipset Reset Configuration Data: [No] information. Legacy USB Support: [Enabled] Boot-time Diagnostic Screen: [Enabled] Power on Boot Beep: [Disabled]...

  • Page 77: Reset Configuration Data: (Advanced Menu)

    BIOS Utilities Reset Configuration Data: (Advanced Menu) This item is set to No as default. You can change the setting to Yes if you have in- stalled a new add-on which has reconfigured the system, resulting in such a serious system conflict that the operating system is unable to boot.

  • Page 78: Security Menu

    BIOS Utilities Security Menu Security Menu PhoenixBIOS Setup Utility Security Main Advanced Security Boot Exit changes make here affect the Item Specific Help access to the Setup Supervisor Password Is: Clear utility itself, and also Supervisor Password access to your ma- Set Supervisor Password [Enter] controls access to the...

  • Page 79: Password On Boot: (Security Menu)

    BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password should be entered to boot the computer. If “En- abled” is selected, only users who enter a correct password can boot the system (see Password Warning the warning in the sidebar). The default setting is “Disabled”. If you set a boot pass- word (Password on boot Note: To clear existing passwords press Enter and type the existing password, then...

  • Page 80: Boot Menu

    BIOS Utilities Boot Menu PhoenixBIOS Setup Utility Figure 5 - 5 Boot Menu Main Advanced Security Exit Boot Item Specific Help Boot priority order: USB FDC: Keys used to view or USB KEY: configure devices: IDE CD: UJDA770 DVD/CDRW-(SM) Up and Down arrows IDE HDD: FUJITSU MHV2040BH-(S1) select a device.

  • Page 81: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 6 PhoenixBIOS Setup Utility Exit Menu Main Advanced Security Boot Exit Exit Item Specific Help Exit Saving Changes Exit System Setup and Exit Discarding Changes save your changes to Load Setup Defaults CMOS. Discard Changes Save Changes Help...
  • Page 82 BIOS Utilities 5 - 14...

  • Page 83: Upgrading The Computer Overview

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- lined to make the desired upgrades. If you have any trouble or problems you can con- Warranty Warning tact your service representative for further help. Before you begin you will need: Please check with your service representative...

  • Page 84: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning • Your system is still under warranty or a service contract Before you undertake •...

  • Page 85: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Your computer may come with a standard battery , or an optional extended battery , depending on your purchase configuration.

  • Page 86: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" Serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 3). Follow your Warning operating system’s installation instructions, and install all necessary drivers and util- ities (see...
  • Page 87 Upgrading The Computer Remove screws to release the hard disk from the assembly cover, and reverse the process to install any new hard disk. Figure 6 - 3 Hard Disk Assembly Removal Upgrading the Hard Disk Drive 6 - 5...

  • Page 88: Upgrading The Optical (Cd/Dvd) Device

    Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Locate the component bay cover and remove screws Figure 6 - 4 Removing the Component Cover 6 - 6 Upgrading the Optical (CD/DVD) Device...
  • Page 89 Upgrading The Computer Carefully (a fan and cable are attached to the under side of the cover) lift up the component bay cover. Carefully disconnect the fan cable , and remove the cover Remove the optical device screw Use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device.

  • Page 90: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO- DIMM) DDRII (DDR2) type memory modules (see “Memory” on page C - 2 details of supported module types). The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 91 Upgrading The Computer Carefully (a fan and cable are attached to the under side of the cover) lift up the component bay cover. Carefully disconnect the fan cable , and remove the cover Figure 6 - 7 Removing the Bay Cover Gently pull the two release latches on the sides of the memory socket.
  • Page 92 Upgrading The Computer The RAM module will pop-up, and you can remove it. Contact Warning Be careful not to touch the metal pins on the module’s connecting edge. Even the cleanest hands have oils which can attract particles, and degrade the module’s performance.

  • Page 93: Modules & Options Overview

    Modules & Options Chapter 7: Modules & Options Wireless Device Overview Operation Aboard This chapter contains the information on the WLAN, PC Camera, Bluetooth and Aircraft Port Replicator modules which may come with your computer, depending on the The use of any portable configuration purchased.

  • Page 94: Intel Pro/Wireless Wlan Module

    Modules & Options Intel PRO/Wireless WLAN Module If you have included an Intel PRO/Wireless 3945ABG (802.11a/b/g) PCIe Wireless Device WLAN module in your purchase option, make sure that the Wireless LAN module Operation Aboard is on (the LED will be orange) before installing the driver. Aircraft Use the Fn + F11 key combination (see “Function Keys”...

  • Page 95: Intel Wlan Driver Installation

    Modules & Options Intel WLAN Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive. User Guide 2. Click Optional and then click 1.Wireless Lan > Yes. You can view the User 3.

  • Page 96: 802.11 B/G Usb Wlan Module

    Modules & Options 802.11 b/g USB WLAN Module If you have included an 802.11 b/g USB WLAN module in your purchase option, Wireless Device make sure that the Wireless LAN module is on (the LED will be orange) before Operation Aboard installing the driver.
  • Page 97 Modules & Options Network Connection Use the Windows Net- work Connections con- trol panel access available wireless net- works (Start > Settings > Network Connections or Start > Connect To > Show all Connections). Figure 7 - 3 Wireless Network Control Panels 802.11 b/g USB WLAN Module 7 - 5...

  • Page 98: Pc Camera Module

    Modules & Options PC Camera Module If you have included a PC Camera module in your purchase option, you will have Taking Still Pictures the appropriate software CD provided for your module. Before installing the PC Camera driver, make sure that the optional PC Camera is on. Use the Fn + F10 key You may take still pic- combination (see “Function Keys”...

  • Page 99: Pc Camera Driver Installation

    Modules & Options PC Camera Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive (click Cancel if you see a “New Hardware Found” message) . 2.

  • Page 100: Pc Camera Audio Setup

    Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double-click the Sounds &...
  • Page 101 Modules & Options Select Realtek HD Audio Input from the Mixer device: menu. Click Recording (button). Click Mic Volume (check box) if it is not checked, then click OK. Figure 7 - 6 Recording > Mic Volume The Recording Control window will pop-up. Boost the Recording volume as high as it will go.

  • Page 102: Emamcap

    Modules & Options EMAMCAP The EMAMCAP video viewer can capture video files to .avi format, and is useful for basic general purpose video viewing and testing (a number of commercially Pre-Allocating File available programs support advanced video capture features). Space Run the EMAMCAP program (or press the PC Camera hot key) from the Start You may pre-allocate...
  • Page 103 Modules & Options Eliminating Screen Flicker If you find that the video screen in the EMAMCAP program is flickering, you can try to adjust the setting in the Lighting Selection options. Run the EMAMCAP program. Go to Options and scroll down to select “Video Capture Filter...”. Click Video Image (tab).

  • Page 104: Pc Camera Hot Key

    Modules & Options PC Camera Hot Key You can use the PC Camera hot key to run the EMAMCAP program, to take still pictures and to start the video capture process (if you have installed the hot key and PC Camera drivers - see “Hot Key Utility”...

  • Page 105: Bluetooth Module

    Modules & Options Bluetooth Module If you have included a Bluetooth module in your purchase option, make sure that Wireless Device the optional Bluetooth module is on (the LED will be green) before installing Operation Aboard the Bluetooth driver. Aircraft Use the Fn + F12 key combination (see “Function Keys”...
  • Page 106 Modules & Options User Guide Send To Bluetooth View BlueSoleil Right-Click to select User Guides from the any file and scroll down Help Menu (or press the to Send To ... Blue- F1 key) in the IVT Cor- tooth Device. poration BlueSoleil - Main Window.

  • Page 107: Port Replicator Module

    Modules & Options Port Replicator Module If you have included the Port Replicator in your purchase option, the device will al- Port Replicator low you to easily attach the notebook to standard, non-portable devices e.g. a printer AC/DC Adapter or monitor. Note the sidebar warning on the power supply. You will be provided with AC/DC...

  • Page 108: Port Replicator Setup Instructions

    Modules & Options Port Replicator Setup Instructions: Turn the computer OFF. Attach the Port Replicator’s external monitor cable to the external monitor port on the left of the computer. Attach the Port Replicator’s power cable to the DC-In jack on the left of the computer.

  • Page 109: Port Replicator Network (Lan) Driver (Winxp)

    Modules & Options Port Replicator Network (LAN) Driver (WinXP) 1. Attach the Port Replicator as per the instructions in “Port Replicator Mod- ule” on page 7 - 15 2. Insert the provided Port Replicator CD into the computer’s CD/DVD drive. 3.
  • Page 110 Modules & Options 7 - 18...

  • Page 111: Troubleshooting Overview

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 112: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, “LED Indi- make sure it is actually working.

  • Page 113: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.

  • Page 114: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.

  • Page 115: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 116 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 117: Problems & Possible Solutions

    Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 118 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
  • Page 119 Troubleshooting Problem Possible Cause - Solution Nothing appears The system is in a power saving mode. Toggle the Fn + F4 sleep/resume key combination (see screen. “Sleep Button” on page 3 - The screen controls need to be adjusted. Toggle the screen control key combinations Fn + F8/F9. If you’re connected to an external monitor, make sure it’s plugged in and turned on.
  • Page 120 Troubleshooting Problem Possible Cause - Solution The sound cannot be The volume might be set too low. Check the volume control in the Volume Control Panel in the heard or the volume is Windows taskbar, or use the key combination Fn + F5 and F6 (see “Audio Features”...
  • Page 121 Troubleshooting Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC/DC adapter, press the sleep (Fn the screen goes dark. + F4) key combination, or press the power button if no LEDs are lit. The system never goes Power Options features are not enabled.
  • Page 122 Troubleshooting 8 - 12...

  • Page 123: Interface (Ports & Jacks)

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...

  • Page 124: Notebook Ports And Jacks

    Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Built-In Microphone The built-in microphone allows you to record on your computer Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device.

  • Page 125: Microphone-In Jack

    Interface (Ports & Jacks) Item Description Microphone-In Jack Plug an external microphone in to this jack to record on your computer. Mini-IEEE 1394 Port This port allows a high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below). Mini-IEEE 1394 Port The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices.

  • Page 126: S/Pdif-Out Jack

    Interface (Ports & Jacks) Item Description S/PDIF-Out Jack This S/PDIF (Sony/Philips Digital Interface Format) Out Jack allows you to connect your DVD- capable PC to a Dolby AC-3 compatible receiver for “5.1” or ‘dts’ surround sound. 7-Pin S-Video-Out Jack Connect your television to your computer and view DVDs, VCDs or anything else your computer can display.

  • Page 127: Optional Port Replicator Ports And Jacks

    Interface (Ports & Jacks) Optional Port Replicator Ports and Jacks Item Description DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer. External Monitor (VGA) This port allows you to connect an external monitor, or Flat Panel Display, to get dual video or Port simultaneous display on the LCD and external monitor/FPD (see “Display Devices”...
  • Page 128 Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure you use the power supply which comes with the device).

  • Page 129: Intel Video Driver Controls

    Intel Video Driver Controls Appendix B: Intel Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Intel Video Driver Installation Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 6.

  • Page 130: Dynamic Video Memory Technology

    Intel Video Driver Controls Dynamic Video Memory Technology ® Intel DVMT 3.0 automatically and dynamically allocates as much (up to 224MB) DVMT Notes system memory (RAM) as needed to the video system (the video driver must be installed - see page 1).

  • Page 131: Intel Graphics Properties

    Intel Video Driver Controls Intel Graphics Properties More advanced video configuration options are provided by the Intel(R) Graphics Taskbar Icon Media Accelerator Driver for Mobile. You can also access the Open Display Properties (see “Video Features” on page 1 - 14) and click controller properties...
  • Page 132 Intel Video Driver Controls You may make changes to the devices, color, schemes, Hot Keys etc. by clicking the appropriate menu item or button. Click Information (button) to obtain useful in- formation about the graphics properties of the computer, and see the Support tab in Help Menus Information to get weblinks to the latest information on the Intel Website.

  • Page 133: Scheme Options

    Intel Video Driver Controls Scheme Options Use Scheme Options to configure quick settings for applications which require spe- cific resolution and color settings in order to run properly e.g. games, multimedia Application.exe programs. To set the scheme options: You will need to locate the actual application Go to the Graphics Properties control panel (see “Intel Graphics Properties”...

  • Page 134: Display Devices

    Intel Video Driver Controls Display Devices Besides the built-in LCD, you can also use an external monitor/flat panel display or Function Key TV as your display device. The following are the display options: Combination The built-in LCD. You can use the Fn + F7 An external monitor connected to the external monitor port.

  • Page 135: Attaching Other Displays

    Intel Video Driver Controls Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the external monitor Intel Display Note port on the left of the computer. Note that the notebook Attach your external monitor to the external monitor port (or TV to the 7-Pin S- is the default Primary Video-Out Jack), and turn it on.

  • Page 136: Display Modes

    Intel Video Driver Controls Display Modes Single Display Only one of your attached displays is used. Intel(R) Dual Display Clone This mode will drive multiple displays with the same content. Each device may be configured independently for different resolutions, refresh rates, color quality etc. Use this feature to display the screen through a projector for a presentation.
  • Page 137 Intel Video Driver Controls To Enable Intel(R) Dual Display Clone Mode Attach your external monitor to the external monitor port (or TV to the 7-Pin S- Video-Out Jack), and turn it on. Go to the Graphics Properties control panel (see “Intel Graphics Properties”...
  • Page 138 Intel Video Driver Controls To Enable Extended Desktop Mode: Attach your external monitor to the external monitor port (or TV to the 7-Pin S- Video-Out Jack), and turn it on. Display Settings Go to the Graphics Properties control panel (see “Intel Graphics Properties”...
  • Page 139 Intel Video Driver Controls To Enable Extended Desktop (Display Properties) Attach your external monitor to the external monitor port (or TV to the 7-Pin S- Video-Out Jack), and turn it on. Display Settings Click Start, point to Settings (or click Control Panel) and click Control Panel (if Extended Desktop you are in Category View choose Appearance and Themes).

  • Page 140: Tv Settings

    Intel Video Driver Controls TV Settings If you are using a TV as a display device adjust the display settings as follows: Function Key Use an S-Video cable to attach your TV to the 7-Pin S-Video-Out Jack and turn it on. Combination Go to the Graphics Properties control panel (see “Intel Graphics Properties”...

  • Page 141: Specifications

    Specifications Appendix D: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release sched- ule.

  • Page 142: Processor

    Specifications Feature Specification Processor Intel® Core™ 2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package 4MB On-die L2 Cache & 667MHz FSB T7200/ T7400/ T7600 2.0/ 2.16/ 2.33 GHz Intel® Core™ 2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package 2MB On-die L2 Cache &...

  • Page 143: Security

    Specifications Feature Specification Security Security (Kensington® Type) Lock Slot BIOS Password BIOS One 4Mb Flash ROM Phoenix™ BIOS LCD Options 12.1" WXGA (1280*768) Glare Type Flat Panel TFT 12.1" WXGA (1280*768) Non Glare Type Flat Panel TFT Video Adapter Intel 945GM Integration Intel®...

  • Page 144: Pcmcia

    Specifications Feature Specification PCMCIA One Type-II PCMCIA (3.3V/5V) CardBus PC Card Slot Card Reader Embedded 4-in-1 Card Reader (MS/ MS PRO/ SD/ MMC) Interface Three USB 2.0 Ports (1.1 Compatible) One RJ-11 Modem Jack One Mini-IEEE 1394 Port One RJ-45 LAN Jack One Headphone-Out/Speaker-Out Jack One DC-in Jack One Microphone-In Jack...

  • Page 145: Power

    Specifications Feature Specification Power Full Range AC/DC Adapter - AC Input 100~240V, 50~60Hz / DC Output 19V, 3.42A Full Range AC/DC Adapter - AC Input 100~240V, 47~63Hz / DC Output 20V, 4.5A (Supplied for the Optional Port Replicator Only) 4 Cell Smart Lithium-Ion Battery Pack, 14.8V / 2.4 AH, 4S1P (Standard Battery) 8 Cell Smart Lithium-Ion Battery Pack, 14.8V / 4.4 AH, 4S2P (Optional Extended Battery) Environmental Temperature...

  • Page 146: Optional

    Specifications Feature Specification Optional Optical Device Module Options: MDC 56K Fax Modem - V.90 & V.92 Compliant DVD/CD-RW Combo Drive Module (Factory Option) DVD-Dual Drive Module Intel PRO/Wireless 3945ABG PCIe Interface Software DVD Player Wireless LAN Module Battery Charger Module 802.11 b/g Wireless LAN Module Port Replicator (10/100 Base-T Ethernet Port, 4 * USB (2.0) Bluetooth Module (Factory Option)

Table of Contents
