  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply. If you are unsure of your local power specifications, consult Warning your service representative or local power company.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...

  • Page 15: Table Of Contents

    Preface Contents Notice .................I System Map: Front & Rear Views .......1-11 FCC Statement .............II System Map: Left View ..........1-12 Instructions for Care and Operation ......IV System Map: Right View ..........1-13 Power Safety .............. VI System Map: Bottom View ..........1-14 Battery Precautions ...........VII Windows Vista Start Menu &...
  • Page 16 Preface Drivers & Utilities USB Printer ..............2-12 Parallel Printer ............2-12 What to Install ..............4-1 Module Driver Installation ..........4-1 Power Management Driver Installation ............4-2 Overview ................3-1 Updating/Reinstalling Individual Drivers ....4-3 The Power Sources ............3-2 User Account Control (Win Vista) ......4-4 AC/DC Adapter ............3-2 Windows Security Message .........4-4 Battery .................3-2 New Hardware Found ..........4-4...
  • Page 17 Preface Fatal Errors ..............5-3 Upgrading the System Memory (RAM) ......6-11 Non-Fatal Errors ............5-3 Upgrading the Processor ..........6-14 Setup Screens ...............5-4 Modules & Options Main Menu ..............5-5 System Time & Date (Main Menu) .......5-5 Overview ................7-1 IDE Channel 0/2 Master (Main Menu) ......5-6 802.11 b/g USB WLAN Module ........7-2 System/Extended Memory: (Main Menu) .....5-6 802.11 b/g WLAN Driver Installation ......7-2...
  • Page 18 Preface Interface (Ports & Jacks) Specifications Overview ............... A-1 Processor ............... C-1 Notebook Ports and Jacks ..........A-2 Core Logic ..............C-1 Card Reader Port ............A-2 Memory ................. C-2 DC-In Jack ..............A-2 Security ................. C-2 External Monitor (VGA) Port ........A-2 BIOS ................
  • Page 19 Preface Advanced Configuration and Power Interface ..D-16 AC/DC Adapter ............D-17 Battery ..............D-17 Hibernate Mode vs. Shutdown ......... D-21 Stand by Mode vs. Hibernate Mode ......D-21 Recharging the Battery with the AC/DC Adapter ..D-25 Battery FAQ ............. D-27 Updating/Reinstalling Individual Drivers ....
  • Page 20 Preface XVIII...

  • Page 21: Quick Start Guide

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 22: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...

  • Page 23: Model Differences

    Quick Start Guide Model Differences This notebook series includes two different design styles (Model B includes either a fingerprint module or a card reader module, depending on your purchase configuration). Not Included Operating Systems (e.g. Windows Vista/Windows XP) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.

  • Page 24: System Software

    Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the following operating systems are sup- ported.

  • Page 25: System Startup

    Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the right of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.

  • Page 26: System Map: Model A - Lcd Panel Open

    Quick Start Guide System Map: Model A - LCD Panel Open Figure 1 - 2 LCD Panel Open Model A Wireless Device Optional Built-In PC Operation Aboard Aircraft Camera The use of any portable electronic Speaker transmission devices aboard air- craft is usually prohibited.

  • Page 27: System Map: Lcd Panel Open - Model B

    Quick Start Guide System Map: LCD Panel Open - Model B Figure 1 - 3 LCD Panel Open Model B Wireless Device Optional Built-In PC Operation Aboard Aircraft Camera The use of any portable electronic transmission devices aboard air- Speakers craft is usually prohibited.

  • Page 28: Led Indicators

    Quick Start Guide LED Indicators Icon Color Description The two sets of LED indicators (LED Status Indica- Green The Computer is On tors and LED Power & Communication Indicators) Blinking on the computer display helpful information about the The Computer is in Sleep Mode Green current status of the computer.

  • Page 29: Hot Key Buttons & Keyboard

    Quick Start Guide Hot Key Buttons & Keyboard The keyboard has an embedded numerical keypad for easy numeric data input, and features function keys to These buttons give instant access to the functions indi- allow you to change operational features instantly (see cated in the table below.

  • Page 30: Function Keys & Visual Indicators

    Quick Start Guide Function Keys & Visual Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is in- stalled (see “Hot Key”...

  • Page 31: System Map: Front & Rear Views

    Quick Start Guide System Map: Front & Rear Views Figure 1 - 5 Front & Rear Views LED Power & Communication Indicators 7-in-1 Card Reader External Monitor Port Security Lock Slot Battery 7-in-1 Card Reader *Note: Model B computers may have either a fingerprint The card reader allows you to use the most popular digital storage card formats: module or card reader mod- ule, depending on your pur-...

  • Page 32: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 6 Left View RJ-45 LAN Jack Vent/Fan Intake 2 * USB 2.0 Ports S/PDIF-Out Jack Recording Line-In Jack ExpressCard Slot ExpressCard Slot The ExpressCard Slot accepts either ExpressCard/34 or ExpressCard/54 formats. 1 - 12 System Map: Left View...

  • Page 33: System Map: Right View

    Quick Start Guide System Map: Right View Figure 1 - 7 Right View Headphone-Out Jack Microphone-In Jack USB 2.0 Port RJ-11 Phone Jack Optical Device CD Emergency Eject Changing DVD Regional Codes Drive Bay (for CD/ If you need to manually eject a CD/DVD Go to the Control Panel and double-click DVD Device - see (e.g.

  • Page 34: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 8 Bottom View Vent/Fan Intake Battery Module Bay Cover The CPU is not a user serviceable part. Opening this compartment, Hard Disk Cover or accessing the CPU in any way, may violate your warranty.

  • Page 35: Windows Vista Start Menu & Control Panel

    Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 36: Video Features

    Quick Start Guide Video Features You can switch display devices, and configure display options, from the Display Settings control panel (in Per- sonalization) in Windows Vista. For further information see “Video Driver Controls” on page B - To access Display Properties in Windows Vista: Click Start, and click Control Panel (or point to Settings and click Control Panel).

  • Page 37: Power Options

    Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 15) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
  • Page 38 Quick Start Guide 1 - 18...

  • Page 39: Features & Components

    Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • 7-in-1 Card Reader • ExpressCard Slot •...

  • Page 40: Hard Disk Drive

    Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.

  • Page 41: Optical (Cd/Dvd) Device

    Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 2). The Adjustment optical device is usually labeled “Drive D:”...

  • Page 42: Handling Cds Or Dvds

    Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually Note the following: eject a CD (e.g.

  • Page 43: Dvd Regional Codes

    Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...

  • Page 44: 7-In-1 Card Reader

    Features & Components 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).

  • Page 45: Expresscard Slot

    Features & Components ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g. rubber cover provided in CompactFlash card reader.

  • Page 46: Application Hot Key

    Features & Components Application Hot Key To configure a program to open when the application hot key button is pressed Hot Key Driver (Windows Media Player is the default program), follow the instructions below. Double-click the icon Double-click the Hot Key driver icon in the taskbar.

  • Page 47: Mail Check Program

    Features & Components Mail Check Program After you have installed the driver for the Mail Check program (see “AutoMail” on Mail Check Driver page 4 - 5) you may then configure it to give notification when new mail is received. You must be online to receive this notification (note that this program only supports Check with your Internet the POP3 protocol), and your default mail program does not need to be open.

  • Page 48: Touchpad And Buttons/Mouse

    Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an ex- ternal mouse your op- erating system may be...

  • Page 49: Audio Features

    Features & Components Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the VIA Audio Deck icon in the taskbar, or on the Adjustment desktop (this will bring up the VIA Audio Deck menu). The volume may also be adjusted by means of the Fn + F5/F6 key combination.

  • Page 50: Adding A Printer

    Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- ble to the printer.

  • Page 51: Power Management

    Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.

  • Page 52: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack on the right of the computer.

  • Page 53: Turning On The Computer

    Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot- ways shut your comput- key button when it is pressed for less than 4 seconds (pressing and holding the power er down by choosing the...

  • Page 54: Power Plans

    Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and If the display is off the to send the computer into Sleep after a period of inactivity.
  • Page 55 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance for maximum performance when the computer is pow- ered from an AC power source.

  • Page 56: System Power Options

    Power Management System Power Options You can use the system power options to stop the computer’s operation and restart Sleep Button where you left off. The system features Sleep and Hibernate power saving states (Hibernate will need to be enabled from power plan Advanced Settings see Figure The Sleep Button 3 - 1 on page 3 -...

  • Page 57: Sleep

    Power Management Sleep Sleep uses very little system power, and takes a short time to return to full operation. After an extended period of time in Sleep the computer will save the contents of sys- Sleep Mode & tem memory (e.g. any open documents and applications) to the hard disk and shut Mobile PC Battery the system down.

  • Page 58: Configuring The Power Buttons

    Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to either Sleep or Hibernate. In Sleep, the LED will blink green. Protection In Hibernate the LED will be off (battery) or orange (AC/DC adapter). If only the display is turned off, the LED will remain green.

  • Page 59: Battery Information

    Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- cally low, immediately grams you are running, and peripheral devices attached.

  • Page 60: Conserving Battery Power

    Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that Windows Mobility this may have an affect on computer performance. Center • Lower the brightness level of the LCD display. The system will decrease LCD Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.

  • Page 61: Battery Life

    Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...

  • Page 62: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.

  • Page 63: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
  • Page 64 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
  • Page 65 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
  • Page 66 Power Management 3 - 16...

  • Page 67: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual CD- of the computer’s subsystems. The system takes ad- ROM (Win Vista OR WinXP) contains the drivers and vantage of some newer hardware components for utilities necessary for the proper operation of the com-...

  • Page 68: Driver Installation

    Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the CD-ROM and click Install Drivers (button)/Option Drivers Installer menu below.

  • Page 69: Updating/Reinstalling Individual Drivers

    Drivers & Utilities Updating/Reinstalling Individual Drivers Driver Page # If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do Video Page 4 - 4 this go to the Control Panel in the Windows OS and Modem Page 4 - 4 double-click the Programs and Features icon (Pro-...

  • Page 70: User Account Control (Win Vista)

    Drivers & Utilities User Account Control (Win Vista) Driver Installation Procedure If a User Account Control prompt appears as part of Insert the Device Drivers & Utilities + User’s Manual the driver installation procedure, click Continue or CD-ROM and click Install Drivers (button). Allow, and follow the installation procedure as direct- Video 1.

  • Page 71: Audio

    Drivers & Utilities Audio Hot Key 1. Click 3.Install Audio Driver > Yes. 1. Click 6.Install Hotkey Driver > Yes. 2. Click Next. 2. Click Next > Install. 3. Click the button to accept the license and click 3. Click Finish > Finish to restart the computer. Next.

  • Page 72: Card Reader

    Drivers & Utilities Module Drivers See the following referenced pages for the driver in- stallation procedures for any of the optional modules Windows Update included in your purchase configuration. After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security up- Card Reader dates etc.

  • Page 73: Wireless Lan Module

    Drivers & Utilities Wireless LAN Module PC Camera Module See the introduction in “802.11 b/g USB WLAN Mod- See the introduction in “PC Camera Module” on ule” on page 7 - 2, and check the installation proce- page 7 - 11, and check the installation procedure.
  • Page 74 Drivers & Utilities 4 - 8...

  • Page 75: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- The Setup utility up and restore the Set- up Defaults with <F9>.

  • Page 76: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...

  • Page 77: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 78: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with five (5) menu headings. When you Setup menus select a heading, a new screen appears. Scroll through the features listed on each shown in this section are screen to make changes to Setup.

  • Page 79: Main Menu

    BIOS Utilities Main Menu PhoenixBIOS Setup Utility Figure 5 - 2 Main Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:11:05] System Date: [09/13/2007] IDE Channel 0 Master [Optiarc DVD RW AD-7530B-(] <Tab>, <Shift Tab>, or IDE Channel 2 Master [FUJITSU MHV2100BH PL-(S1)] <Enter>...

  • Page 80: Ide Channel 0/2 Master (Main Menu)

    BIOS Utilities IDE Channel 0/2 Master (Main Menu) Pressing Enter opens the sub-menu to show the configuration of either a DVD/CD Device or HDD on the computer’s IDE Channels. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable.

  • Page 81: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Advanced Security Boot Exit Item Specific Help Boot-time Diagnostic Screen [Enabled] Display the diagnostic Advanced Chipset Control screen during boot Legacy USB Support: [Enabled] Reset Configuration Data: [No] Help Select Item...

  • Page 82: Advanced Chipset Control (Advanced Menu)

    BIOS Utilities Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to alter advanced features of the chipset. The Frame Buffer Size item in the Internal VGA Control menu allows you to adjust the amount of system memory to be allocated for use by the integrated graphic system. The default memory size allocated is 128MB.

  • Page 83: Security Menu

    BIOS Utilities Security Menu Figure 5 - 4 PhoenixBIOS Setup Utility Main Advanced Security Boot Exit Security Menu Item Specific Help Supervisor Password Is: Clear User Password Is: Clear Supervisor Password Set Supervisor Password [E E nter] controls access to the setup utility.

  • Page 84: Set User Password (Security Menu)

    BIOS Utilities Set User Password (Security Menu) You can set a password for user mode access to the Setup utility. This will not affect access to the computer OS, (only the Setup utility) unless you choose to set a Pass- Password Warning word on Boot (see below).

  • Page 85: Boot Menu

    BIOS Utilities Boot Menu PhoenixBIOS Setup Utility Figure 5 - 5 Main Advanced Security Exit Boot Boot Menu Item Specific Help Boot priority order: USB HDD: Keys used to view or IDE 0: Optiarc DVD RW AD-7530B-(P configure devices: IDE 4: FUJITSU MHV2100BH PL-(S1) Up and Down arrows USB KEY: select a device.

  • Page 86: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 6 PhoenixBIOS Setup Utility Main Advanced Security Boot Exit Exit Exit Menu Item Specific Help Exit Saving Changes Exit System Setup and Exit Discarding Changes save your changes to Load Setup Defaults CMOS. Discard Changes Save Changes Help...

  • Page 87: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview Warranty Warning Please check with your This chapter contains information on upgrading the computer. Follow the steps out- service representative lined to make the desired upgrades. If you have any trouble or problems you can con- before undertaking any tact your service representative for further help.

  • Page 88: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...

  • Page 89: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Turn the computer off, and turn it over. Please check with your Slide the latch in the direction of the arrow, and hold it in place.
  • Page 90 Upgrading The Computer Lift the battery out in the direction of the arrow Figure 6 - 2 Battery Up Lift the battery out. Figure 6 - 3 Battery Out 6 - 4 Removing the Battery...

  • Page 91: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 2). Follow your Warning operating system’s installation instructions, and install all necessary drivers and util- ities (as outlined in...
  • Page 92 Upgrading The Computer For Model A computers: Slide the hard disk and cover assembly in the direction of arrow Lift the hard disk and cover assembly up in the direction of arrow Remove the hard disk and cover assembly Figure 6 - 5 Model A HDD &...
  • Page 93 Upgrading The Computer Remove the screws to release the hard disk from the assembly cover , and reverse the process to install any new hard disk. Figure 6 - 6 Model A HDD Assembly Cover Removal (Model A Computers Only) Upgrading the Hard Disk Drive 6 - 7...
  • Page 94 Upgrading The Computer For Model B computers: Remove the cover Pull the tab to slide the hard disk and case assembly in the direction of arrow Lift the hard disk and case assembly out of the bay in the direction of arrow 10.

  • Page 95: Upgrading The Optical (Cd/Dvd) Device

    Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Remove screws (Model A)/ (Model B), and remove the component bay cover Model A Model B Figure 6 - 8 Removing the Component Bay Cover...
  • Page 96 Upgrading The Computer Use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device. Figure 6 - 9 Removing the Optical (CD/DVD) Device 6 - 10 Upgrading the Optical (CD/DVD) Device...

  • Page 97: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO- DIMM) DDR2 (DDRII) type memory modules (see “Memory” on page C - 2 details of supported module types). Turn off the computer, and turn it over and remove the battery.
  • Page 98 Upgrading The Computer Locate the RAM socket(s) Figure 6 - 11 RAM Socket Location Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows ( & Figure 6 - 12 RAM Socket Release Latches 6 - 12 Upgrading the System Memory (RAM)
  • Page 99 Upgrading The Computer The RAM module will pop-up, and you can remove it. Contact Warning Be careful not to touch the metal pins on the module’s connecting edge. Even the cleanest hands have oils which can attract particles, and degrade the module’s performance.

  • Page 100: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a fast- Warranty er/new one you will need to contact your customer service representative. We rec- ommend that you do not do this yourself, since if it is done incorrectly you may The CPU is not a user damage the processor or mainboard.

  • Page 101: Modules & Options

    Modules & Options Chapter 7: Modules & Options Overview Wireless Device Operation Aboard This chapter contains information on the following modules, which may come with Aircraft your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.

  • Page 102: 802.11 B/G Usb Wlan Module

    Modules & Options 802.11 b/g USB WLAN Module Before installing the 802.11b/g USB WLAN driver, make sure that the Wireless Wireless Device LAN module is on. Use the Fn + F11 key combination (see “Function Keys & Vi- Operation Aboard sual Indicators”...

  • Page 103: Connecting To A Wireless Network

    Modules & Options Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 1 Taskbar Menus Click icon...
  • Page 104 Modules & Options Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network).
  • Page 105 Modules & Options To disconnect from the wireless network you can click the taskbar wireless icon , and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make...

  • Page 106: Windows Mobility Center

    Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).

  • Page 107: Bluetooth Module

    Modules & Options Bluetooth Module Before installing the Bluetooth driver, make sure that the optional Bluetooth mod- Wireless Device ule is on. Use the Fn + F12 key combination (see “Function Keys & Visual Indi- Operation Aboard cators” on page 1 - 10) to toggle power to the Bluetooth module.

  • Page 108: Bluetooth Configuration In Windows Vista

    Modules & Options Bluetooth Configuration in Windows Vista Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Taskbar Make the device discoverable (to do this check your device documentation). Icon If you cannot see the To Turn the Bluetooth Module On...
  • Page 109 Modules & Options To Add a Bluetooth Device Access the Bluetooth Devices control panel. Click Options (tab), and make sure that Allow Bluetooth devices to connect to this computer check box (Connections) has a tick inside it. Click Devices (tab), and then click Add. The Add Bluetooth Device Wizard will appear.
  • Page 110 Modules & Options To Change Settings for the Bluetooth Device Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click General, type a new name and click OK). •...

  • Page 111: Pc Camera Module

    Modules & Options PC Camera Module There are 2 camera options available for this computer, depending on your purchase Latest PC Camera configuration. The 1.3M pixel camera module uses the BisonCap application to Driver Information capture video files, and the 2.0M pixel camera module uses the VideoView appli- cation to capture video files.

  • Page 112: Pc Camera Driver Installation

    Modules & Options PC Camera Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 2.PC Camera, Web cam > Yes. For the 1.3M Pixel Camera Module: 1.

  • Page 113: Pc Camera Audio Setup

    Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
  • Page 114 Modules & Options Figure 7 - 11 Audio Setup for PC Camera Right-click 7 - 14 PC Camera Module...

  • Page 115: Bisoncap (1.3M Cam)/Videoview (2.0M Cam)

    Modules & Options BisonCap (1.3M Cam)/VideoView (2.0M Cam) BisonCap and VideoView are video viewers for general purpose video viewing and testing, and capturing video files to .avi format. Pre-Allocating File Space Run the BisonCap/VideoView program from the Start > Programs/All Programs >...
  • Page 116 Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties) If necessary you can re- move the recorded video file to a removable medium e.g.
  • Page 117 Modules & Options Eliminating Screen Flicker If you find that the video screen in the BisonCap/VideoView program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap/VideoView program. Go to Options and scroll down to select Video Capture Filter..For Bison Cap: Click either 50Hz or 60Hz under Frequency in Property Page (tab).
  • Page 118 Modules & Options Zoom The BisonCap and VideoView programs allow you to zoom the camera in and out. Run the BisonCap/Video View program. For Bison Cap: Go to Zoom and select Zoom Out/Zoom In. For Video View: Figure 7 - 13 Go to Options and scroll down to select Setting (Use the slider to adjust the zoom Zoom/Setting level, and click OK to save the setting).

  • Page 119: Fingerprint Reader Module

    Modules & Options Fingerprint Reader Module (Optional for Model B Computers) If you have included the fingerprint reader in your purchase option you will need to install the driver as per the instructions below. Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full security protection.
  • Page 120 Modules & Options User Enrollment Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon On the first run of the program you will be asked to click the button to accept the license, and then click OK.
  • Page 121 Modules & Options Click the button above any of the fingers to begin the enrollment process for that finger. 10. Swipe the finger three times to enroll that finger. Fingerprint 11. Repeat the process for all the fingers you wish to enroll (see sidebar), and then Enrollment click Next.
  • Page 122 Modules & Options 16. Right-click the taskbar icon to bring up the menu that allows you to Edit Fingerprints, Start Control Center, access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/All Help &...

  • Page 123: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 124: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 125: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.

  • Page 126: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.

  • Page 127: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 128 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 129: Problems And Possible Solutions

    Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 130 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
  • Page 131 Troubleshooting Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
  • Page 132 Troubleshooting Problem Possible Cause - Solution The CD/DVD cannot be The compact disc is not correctly placed in the tray. Gently try to remove the disc using the eject read. hole (see “Loading Discs” on page 2 - regional The code has been changed the maximum 5 times. See “DVD Regional Codes”...
  • Page 133 Troubleshooting Problem Possible Cause - Solution Wireless LAN/ The modules are off. Check the LED indicator to see if the WLAN/Bluetooth module is on or Bluetooth modules off (see “LED Indicators” on page 1 - 8). If the LED indicator is off, then press the Fn + F11 cannot be detected.
  • Page 134 Troubleshooting 8 - 12...

  • Page 135: Interface (Ports & Jacks)

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...

  • Page 136: Notebook Ports And Jacks

    Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.

  • Page 137: Rj-11 Modem Jack

    Interface (Ports & Jacks) Item Description RJ-11 Modem Jack This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11 telephone connection. RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot.
  • Page 138 Interface (Ports & Jacks) A - 4...

  • Page 139: Video Driver Controls

    Video Driver Controls Appendix B: Video Driver Controls VIA Video Driver Installation Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 3. Instructions for installing the video driver are repeated below. Video 1.

  • Page 140: Advanced Video Controls

    Video Driver Controls Advanced Video Controls This section is about making adjustments for the LCD, and switching display devic- Function Key es. The basic settings for configuring the LCD are outlined in “Video Features” on Combination page 1 - You can use the Fn + F7 key combination to Video Driver Controls toggle through the dis-...

  • Page 141: Via S3Tray Plus Utility

    Video Driver Controls VIA S3Tray Plus Utility The S3Tray Plus utility will appear in the taskbar when the video driver is installed. Click/Right-click the icon to bring up the menu below. From this menu you will Taskbar Icon also be able to make display adjustments, access the Display Properties control pan- If you cannot see the el, check video memory information etc.

  • Page 142: Attaching Other Displays

    Video Driver Controls Attaching Other Displays Besides the built-in LCD, you can also use an external monitor (CRT)/flat panel dis- Non DDC CRT play as your display device. Connect it to the external monitor port at the rear of the Monitors (for Win computer, and follow the instructions below: Vista Only)
  • Page 143 Video Driver Controls External displays may also be configured from S3Display tab in Advanced Display Settings : Attach the external display to the external monitor port and turn it on. S3Tray Plus Utility Click Advanced Settings in the Display Settings control panel (see “Video You can also use the Features”...

  • Page 144: Display Modes

    Video Driver Controls Display Modes Single Display Only one of your attached displays is used. Mirrored This display mode simply shows an exact copy of the Primary display desktop on the Secondary display(s). Extended Desktop An Extended desktop allows the desktop to span the displays to act as a large work area, thus creating a lot more screen area for display.
  • Page 145 Video Driver Controls Using Windows Vista to Enable Extended Mode Attach your external display to the external monitor port, and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Display Settings Windows Mobility Center control panel (Mobile PC >...
  • Page 146 Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external display to the external monitor port, and turn it on. Open the Display Settings control panel (see “Video Features” on page 1 - 16). Click the monitor icon (e.g. ), and make sure you have checked “Extend the desktop onto this monitor.”...

  • Page 147: Specifications

    Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed or updated due to the manufacturer's release schedule. Check with your service center for details.

  • Page 148: Memory

    Specifications Feature Specification Memory One 200 Pin SO-DIMM Socket Supporting DDRII (DDR2) 533/667 MHz 64-bit Wide DDRII (DDR2) Data Channel Memory Expandable up to 1GB (512/ 1024 MB DDRII Module) Security Security (Kensington® Type) Lock Slot BIOS Password BIOS One 8Mb Flash ROM Phoenix™...

  • Page 149: Keyboard & Pointing Device

    Specifications Feature Specification Keyboard & Winkey Keyboard Built-In TouchPad with Scrolling Function Pointing Device Interface Three USB 2.0 Ports One S/PDIF Output Jack One External Monitor Port One RJ-11 Modem Jack One Headphone-Out Jack One RJ-45 LAN Jack One Microphone-In Jack One DC-in Jack One Recording Line-In Jack Card Reader...

  • Page 150: Power

    Specifications Feature Specification Power Full Range AC/DC Adapter 19V, 3.42A or 18.5V, 3.5A (65 Watts), 100 - 240V, 50 - 60Hz 6 Cell Smart Lithium-Ion Battery Pack, 4000mAH & 4400mAH Environmental Temperature Relative Humidity Spec Operating: 5°C ~ 35°C Operating: 20% ~ 80% Non-Operating: -20°C ~ 60°C...

  • Page 151: Windows Xp Information

    Windows XP Information Appendix D: Windows XP Information This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows XP OS. D - 1...
  • Page 152 Windows XP Information DVD Regional Codes Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.
  • Page 153 Windows XP Information Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
  • Page 154 Windows XP Information Function Keys/Hot Keys The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is installed (see “Hot Key (WinXP)”...
  • Page 155 Windows XP Information Application Hot Key To configure a program to open when the application hot key button is pressed, follow the instructions below. Application.exe Double-click the hot key icon in the taskbar. You will need to locate Click Launch user specified application (button) the actual application executable (.exe) file, not just the shortcut.
  • Page 156 Windows XP Information TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an ex- ternal mouse your op- erating system may be...
  • Page 157 Windows XP Information Audio Features You can configure the audio options on your computer from the Sounds and Audio Sound Volume Devices Windows control panel, or from the VIA Audio Deck icon in the Adjustment taskbar, or on the desktop (this will bring up the VIA Audio Deck menu). The vol- ume may also be adjusted by means of the Fn + F5/F6 key combination.
  • Page 158 Windows XP Information Video Features You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the video driver is installed. For further information see either “VIA Video Driver Con- trols” on page D - 10 (from pages D - 10 14).

  • Page 159: Video Driver Controls

    Windows XP Information Advanced Video Controls This section is about making adjustments for the LCD, and switching display devic- Function Key Combination You can use the Fn + Video Driver Controls F7 key combination to The video interface lets you change the screen resolution and color output to what- toggle through the dis- ever is most comfortable/efficient for you.

  • Page 160: Via S3Tray Plus Utility

    Windows XP Information VIA Video Driver Controls VIA S3Tray Plus Utility The S3Tray Plus utility will appear in the taskbar when the video driver is installed. Click/Right-click the icon to bring up the menu below. From this menu you will also be able to make display adjustments, access the Display Properties control panel, check video memory information etc.
  • Page 161 Windows XP Information VIA S3 Display Control Panels Right-click the S3Tray Plus utility in the taskbar to bring up the menu for the individual control panels, or access the menus from the Advanced tab in the Display Help Menus Properties control panel. Right-click on almost any item in the tabs to bring up the “What’s...
  • Page 162 Windows XP Information Display Devices (VIA) Besides the built-in LCD, you can also use an external monitor (CRT)/flat panel dis- S3Tray Plus Utility play as your display device. Connect it to the external monitor port on the right of the computer.
  • Page 163 Windows XP Information Display Modes (VIA) Single Display Playing DVD Videos Only one of your attached displays is used. If you want to play a DVD video in a multiple Multiple Monitors monitor mode, then This display mode simply shows an exact copy of the Primary display desktop on choose EITHER the Secondary display(s).
  • Page 164 Windows XP Information To Enable Extended Desktop (Display Properties) 1. Attach the external display to the external monitor port and turn it on. 2. Go to the Display Properties control panel (see “Video Features” on page D - Display Settings and click Settings (tab).

  • Page 165: Power Management Features

    Windows XP Information Power Management Features The Power Options control panel icon in Windows (see page 3) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk (by means of Power Schemes), or you may use either Stand by or Hibernate mode to conserve power throughout the system (enable Hibernate support from the control panel tab).

  • Page 166: Advanced Configuration And Power Interface

    Windows XP Information Overview To conserve power, especially when using the battery, your computer uses the ACPI OS Note power management system. Power management conserves power by controlling in- dividual components of the computer (the monitor and hard disk drive) or the whole Power management system.

  • Page 167: Ac/Dc Adapter

    Windows XP Information The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/DC adapter will damage the computer and its components.
  • Page 168 Windows XP Information Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shutdown er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Stand by/Hibernate/ ways shut your comput- er down by choosing the Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and...

  • Page 169: Power Schemes

    Windows XP Information Power Schemes You can set your computer to conserve power through individual components by Resuming means of Power Schemes. You can also adjust the settings for each scheme to set Operation the monitor to turn off after a specified time, and the computer's hard disk motor to turn off if the hard disk drive has not been accessed for a specified period of time (if Press a key on the key- the system reads or writes data, the hard disk motor will be turned back on).
  • Page 170 Windows XP Information Each Windows Power Scheme will also adjust the processor performance of your machine in order to save pow- er. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.

  • Page 171: Hibernate Mode Vs. Shutdown

    Windows XP Information System Power Options You can use the system power options to stop the computer’s operation and restart where you left off. This sys- tem features Stand by and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - see “Hibernate”...
  • Page 172 Windows XP Information Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle System Resume at its slowest speed.

  • Page 173: Configuring The Power Button

    Windows XP Information Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hiber- Sleep Button nate mode. In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery) or orange (AC/DC adapter).
  • Page 174 Windows XP Information Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery New Battery Warning Always completely discharge, then fully charge, a new battery (see “Battery FAQ” When the battery is criti- on page D - 27 for instructions on how to do this).

  • Page 175: Recharging The Battery With The Ac/Dc Adapter

    Windows XP Information Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. Conserving Battery Power We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...
  • Page 176 Windows XP Information Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.

  • Page 177: Battery Faq

    Windows XP Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t Caution turn off the computer by yourself even when you see a message that indicates the bat- Danger of explosion if tery is critically low, just let the computer use up all of the battery power and shut battery is incorrectly re-...
  • Page 178 Windows XP Information Driver Installation WinXP SP2 Driver Page # The Device Drivers & Utilities + User’s Manual CD- Install the appropriate WinXP Service Pack Page D - 30 ROM contains the drivers and utilities necessary for the proper operation of the computer. Table D - 3 lists Chipset...
  • Page 179 Windows XP Information What to Install Check the driver installation order from Table D - 3, on page D - 28 (all the drivers must be installed Insert the Device Drivers & Utilities + User’s Manual in this order) which is the same as that listed in the CD-ROM and click Install Drivers (button)/Option Drivers Installer menu below.

  • Page 180: Updating/Reinstalling Individual Drivers

    Windows XP Information Updating/Reinstalling Individual Drivers If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do Windows XP Service Pack 2 this go to the Control Panel in the Windows OS and double-click the Add/Remove Programs item. If you Make sure you install Windows XP Service Pack 2 (or a Windows XP version which includes Service Pack 2) see the individual driver listed (if not see below), un-...

  • Page 181: Authorized Driver Message

    Windows XP Information Authorized Driver Message WinXP Driver Installation Procedure If you receive a message telling you that the driver you Insert the Device Drivers & Utilities + User’s Manual are installing is not authorized (Digital Signature Not CD-ROM and click Install Drivers (button). Found), just click Yes or Continue Anyway to ignore the message and continue the installation procedure.
  • Page 182 Windows XP Information Bus (WinXP) Audio (WinXP) 1. Click 3.Install Bus driver > Yes. 1. Click 5.Install Audio Driver > Yes. 2. If you see the message “New Hardware 2. Click Next > Next > Next. Found”, click Cancel to close the window. 3.

  • Page 183: Module Drivers

    Windows XP Information Module Drivers Wireless LAN Module See the following pages for the driver installation pro- “802.11 b/g USB WLAN Module” on page D - cedures for any of the optional modules included in Bluetooth Module your purchase configuration. Note: The operating system is the default setting for Card Reader (WinXP) Bluetooth control in Windows XP, and does not re-...
  • Page 184 Windows XP Information 802.11 b/g USB WLAN Module Before installing the 802.11b/g USB WLAN driver, make sure that the optional Wireless Device Wireless LAN module is on. Use the Fn + F11 key combination (see “Function Operation Aboard Keys & Visual Indicators” on page 1 - 10) to toggle power to the Wireless LAN Aircraft module.
  • Page 185 Windows XP Information Network Connection Use the Windows Net- work Connections con- trol panel access available wireless net- works (Start > Settings > Network Connections or Start > Connect To > Show all Connections). Figure D - 18 Wireless Network Control Panels 802.11 b/g USB WLAN Module D - 35...
  • Page 186 Windows XP Information Bluetooth Module The operating system’s Bluetooth Devices control panel is used to configure the Wireless Device Bluetooth settings in Windows XP, and therefore does not require a driver. Use the Operation Aboard Fn + F12 key combination (see “Function Keys &...
  • Page 187 Windows XP Information Bluetooth Local Area Connection Icon If you want to display the Local Area Connection icon for the Bluetooth connection in the taskbar, set it up as follows: Access the Network Connections control panel in Windows (Start > Settings > Network Connections OR Start >...

  • Page 188: Bluetooth Configuration In Windows Xp

    Windows XP Information Bluetooth Configuration in Windows XP Setup your Bluetooth Device so the Computer Can Find it 1. Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Taskbar 2. Make the device discoverable (to do this check your device documentation). Icon To Turn the Bluetooth Module On If you cannot see the...
  • Page 189 Windows XP Information To Add a Bluetooth Device Access the Bluetooth Devices control panel. Click Options (tab), and make sure that Allow Bluetooth devices to connect to this computer check box (Connections) has a tick inside it. Click Devices (tab), and then click Add. The Add Bluetooth Device Wizard will appear.
  • Page 190 Windows XP Information To Change Settings for the Bluetooth Device 1. Access the Bluetooth Devices control panel. 2. Click on the device you want to change and click Properties to: • Change the name of the device (click General, type a new name and click OK). •...
  • Page 191 Windows XP Information PC Camera Module There are 2 camera options available for this computer, depending on your purchase configuration. The 1.3M pixel camera module uses the BisonCap application to Taking Still Pictures capture video files, and the 2.0M pixel camera module uses the VideoView appli- Double-click cation to capture video files.
  • Page 192 Windows XP Information PC Camera Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual CD-ROM (WinXP) into the CD/DVD drive. Stand by/Hibernate 2. Click Option Drivers. or Shutdown Error 3.
  • Page 193 Windows XP Information PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double- click the Sounds &...
  • Page 194 Windows XP Information Figure D - 24 Audio Setup D - 44 PC Camera Module...
  • Page 195 Windows XP Information BisonCap (1.3M Cam)/VideoView (2.0 Cam) BisonCap and VideoView are video viewers for general purpose video viewing and testing, and capturing video files to .avi format. Pre-Allocating File Space Run the BisonCap/VideoView application from the Start > Programs/All Pro- grams >...
  • Page 196 Windows XP Information Eliminating Screen Flicker If you find that the video screen in the BisonCap/VideoView program is flickering, you can try to adjust the setting in the Video Capture Filter options. 1. Run the BisonCap/VideoView program. 2. Go to Options and scroll down to select Video Capture Filter..For Bison Cap: 3.
  • Page 197 Windows XP Information Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties) If necessary you can remove the recorded video file to a removable medium e.g.
  • Page 198 Windows XP Information Zoom The BisonCap and VideoView programs allow you to zoom the camera in and out. 1.Run the BisonCap/VideoView program. For Bison Cap: 2.Go to Zoom and select Zoom Out/Zoom In. For VideoView: Figure D - 26 3.Go to Options and scroll down to select Setting (Use the slider to adjust the zoom Zoom/Setting level, and click OK to save the setting).
  • Page 199 Windows XP Information Fingerprint Reader If you have included the fingerprint reader in your purchase option you will need to Help & Manual install the driver as per the instructions below. Right-click the taskbar icon Make sure you have administrator’s rights to your computer, and have a Windows to bring up the menu to password enabled for full security protection.
  • Page 200 Windows XP Information User Enrollment 1. Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon 2. On the first run of the program you will be asked to click the button to accept the license, and then click OK.
  • Page 201 Windows XP Information Click the button above any of the fingers to begin the enrollment process for that finger. Swipe the finger three times to enroll that finger. Fingerprint Repeat the process for all the fingers you wish to enroll (see sidebar), and then Enrollment click Next.
  • Page 202 Windows XP Information 14. Right-click the taskbar icon to bring up the menu that allows you to Edit Fingerprints, Start Control Center, access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/All Programs menu.

Table of Contents
