READY, SET, GO!

Using your ToneBug Reverb
Insert a 9 Volt alkaline battery or connect the pedal to one of the
T-Rex FuelTank power supplies (not included).
This pedal accepts both 9 and 12 Volt DC (see technical specs).
Plug your guitar into the INPUT jack, and run a lead from the OUT-
PUT jack into your amp.
Set the mode switch to MODERN for a contemporary reverb sound
or SPRING, for a more retro sound.
Adjust the DECAY setting to determine how long your reverb will
last, and the DEPTH setting to determine how "heavy" it will be.

TECHNICAL SPECIFICATIONS:

Input Impedance @ 1KHz
Output Impedance @ 1KHz
Power supply
Minimum Power supply Voltage
Maximum Power supply Voltage
Current Draw @ 9V DC
Maximum input signal Vp/p
Battery Type
Battery Life
External connectors
Controls
Depth
Width
Height
Weight (excl. battery)
Higher than 1 M Ohm
Lower than 1 K Ohm
9V DC
8V DC
12,5V DC
75 mA
2,5 Vp/p
9V battery 6F22 Alkaline
0,5 to 1 Hours
Input Jack. Output Jack, 9V DC Jack (center
pin negative)
On/Off, Decay, Modern/Spring, Depth
120 mm
78 mm
60 mm
0,404 Kg
