About Code Reader
DISPLAY FUNCTIONS
6. FREEZE FRAME icon - Indicates that there is Freeze Frame data
from "Priority Code" (Code #1) stored in the vehicle's computer
memory.
7. MIL icon - Indicates the status of the Malfunction Indicator Lamp
(MIL). The MIL icon is visible only when a DTC has commanded
the MIL on the vehicle's dashboard to light.
8. Code Number Sequence - Code Reader assigns a sequence
number to each DTC that is present in the computer's memory,
starting with "01." This helps keep track of the number of DTCs
present in the computer's memory. Code number "01" is always
the highest priority code, and the one for which "Freeze Frame"
data has been stored.
If "01" is a "Pending" code, "Freeze Frame" data may or
may not be stored in the vehicle's computer memory.
9. CODE icon - Identifies the Code Number Sequence display area.
10. Pending icon - Indicates the currently displayed DTC is a
"Pending" code.
11. Monitor icons - Indicates which Monitors are supported by the
vehicle under test, and whether or not the associated Monitor has
run its diagnostic testing (Monitor status). When a Monitor icon is
solid, it indicates that the associated Monitor has completed its
diagnostic testing. When a Monitor icon is flashing, it indicates
that the vehicle supports the associated Monitor, but the Monitor
has not yet run its diagnostic testing.
10 OBD 2
