8.2

Encoder Outputs (PL2)

SM-Encoder Output Plus only
Simulated Ab, Fd and Fr encoder output
1 0V Common
2 0V Common
3
Channel A, Frequency or Forward
4 Channel A\, Frequency\ or Forward\
5
Channel B, Direction or Reverse
6
Channel B\, Direction\ or Reverse\
8
Marker pulse Z
9 Marker pulse Z\
Type
Maximum frequency
Line loading
Line termination components
Working common mode range
Absolute maximum applied voltage relative to 0V
Absolute maximum applied differential voltage
SM-Encoder Plus & SM-Encoder Output Plus User Guide
Issue: 4 www.controltechniques.com
EIA 485 differential receivers
500kHz
1 unit load
Ω
120
+12V to –7V
±25V
±25V
39
