8

Terminal data

8.1

Encoder inputs (PL1)

Ab, Fd, and Fr encoders
1
2
3
4
5
6
Type
Maximum frequency
Line loading
Line termination components
Working common mode range
Absolute maximum applied voltage relative to
0V
Absolute maximum applied differential voltage
7
8.1.1 SM-Encoder Plus
8
Maximum voltage
8.1.2 SM-Encoder Output Plus
8
Supply voltage
Maximum output current
The encoder supply voltage is controlled by Pr x.13. The default for this parameter is 5V
(0) but this can be set to 8V (1) or 15V (2). Setting the encoder voltage supply too high
for the encoder could result in damage to the feedback device.
The termination resistors should be disabled (Pr x.16 = 0) if the outputs from the
encoder are higher than 5V.
38
Channel A, Frequency or Forward inputs
Channel A\, Frequency\ or Forward\ inputs
Channel B, Direction or Reverse inputs
Channel B\, Direction\ or Reverse\ inputs
Marker pulse channel Z
Marker pulse channel Z\
0V Common
External power supply decoupling
Encoder supply voltage
SM-Encoder Plus & SM-Encoder Output Plus User Guide
www.controltechniques.com
EIA 485 differential receivers
500kHz
<2 unit loads
Ω
120
+12Vdc to –7Vdc
±25V
±25V
±50Vdc
5V, 8V or 15V
300mA for 5V and 8V
200mA for 15V
Issue: 4
