- Page 1 0554 0452 Instruction manual...
-
Page 2: General Information
1. General Information Please read this documentation through carefully and familiarise yourself with the operation of the product before putting it to use. Keep this document to hand so that you can refer to it when necessary. 2. Product Description Platzhalter Function and battery Schallpegel... -
Page 3: Safety Advice
3. Safety Advice Product safety/preserving warranty claims: Operate only within the parameters specified. Do not use force. Do not expose to electromagnetic radiation (e.g. microwaves, induction heating), static charge, heat or strong fluctuations in temperature. Never store with solvents (e.g. acetone). Ensure that liquid does not enter into the calibrator. -
Page 4: Intended Purpose
The product should only be opened if expressly described in the documentation for maintenance and repair purposes. Ensure correct disposal: Dispose of defective rechargeable batteries and spent batteries at the collection points provided. Send the product directly to us at the end of its life cycle. -
Page 5: Technical Data
5. Technical data Feature Values Sound pressure level 94dB/114dB in reference conditions, switchable Accuracy: ±0.5dB Sound pressure level Frequency 1000Hz ±2% Reference conditions - Temperature +23°C (74°F) - Relative humidity - Air pressure 1013hPa Operating conditions - Temperature 0 to +40°C (32 to 140°F) - Relative humidity 10 to 90%RH - Air pressure... -
Page 6: Initial Operation
Feature Values Battery test Internal circuit for permanent battery status monitoring. Calibrator does not emit signal if the LED changes from green to red, voltage is then too low. Dimensions in mm (lxbxh) 113 x 63 x 44 Weight Approx. 170g (incl. battery) EC guideline 89/336/EEC 6. -
Page 7: Operation
7. Operation 1 Attach calibrator to microphone with a rotary motion. Use the corresponding adapter for instruments with a ½ inch microphone. 2 Switch on instrument and set the measurement range from 80 to 130 dB. 3 Set time weighting (Fast/Slow) and frequency weighting (dB(A),dB(C)) to the values in which the instrument is usually operated. - Page 8 Height offset values Height in m amsl Pressure p in mbar Offset in dB 0-250 1013-984 >250-850 983-915 -0.1 >850-1450 914-853 -0.2 >1450-2000 852-795 -0.3 Example: Height above mean sea level = 500 Target value = 94dB - 0.1dB = 93.9 dB If the value displayed deviates from the target value, the instrument should be recalibrated.
-
Page 9: Care And Maintenance
If the value displayed deviates by more than ±0.2dB from the target value and it also cannot be reduced by recalibration, please contact your dealer or Testo Customer Service. You will find contact details at www.testo.com . 8. Care and Maintenance... - Page 10 9. Accessories Name Part no. Calibrator 0554 0452 (incl. battery, case and ½ inch adapter) 9V rechargeable battery 0515 0025 Recharger 0554 0025 for external recharging of rechargeable batteries...
- Page 12 AG Postfach 11 40, 79849 Lenzkirch Testo-Straße 1, 79853 Lenzkirch Telefon: (07653) 681-0 Fax: (07653) 681-100 E-Mail: info@testo.de Internet: http://www.testo.com 0973.0800/01/C/wh/20.07.2004...
