- Page 1 NSTALLATION ® ® EFINITION OMPONENT PCH-14X PCH-314 / PCH-414 PCH-514 / PCH-614 & O PERATION YSTEMS ®...
-
Page 2: Practice Safe Sound
To add the finishing touch to your new Rockford Fosgate image order your Rockford accessories, which include everything from T-shirts and jackets to hats and sunglasses. -
Page 3: Table Of Contents
Installation Section of this manual or refer to the icons listed below. Other information can be located by using the Table of Contents. We, at Rockford Fosgate, have worked very hard to make sure all the information in this manual is current. But, as we are constantly finding new ways to improve our product, this information is subject to change without notice. -
Page 4: Package Contents
In today’s vehicles, space for everything is at a premium. Many times, the space that car designers dedicate for the stereo system is an afterthought. Rockford Fosgate realizes that people who want stereo systems in their vehicles have to contend with these real world problems. Our solution is the Punch Splits High Definition Component Systems . -
Page 5: Technical Design Features
ECHNICAL Midrange Features PVA Treated Cone The lightweight paper cones are treated with PVA (PolyVinyl Acetate) for environmental stability and increased rigidity. This treatment promotes smooth midrange performance and low frequency extension free of distortion. THE RESULT: Strong and lightweight high performance cones. Vented Pole Piece The vented pole piece by design, ensures proper ventilation to cool the voice coil and maintains lower operating temperatures. - Page 6 Tweeter Features Neodymium Magnets The high ionic compound of neodymium enables a smaller tweeter magnet assembly to be used as opposed to the much larger ferrite magnets that are commonly used in speaker manufacturing. THE RESULT: An efficient magnet which allows smaller tweeter construction.
-
Page 7: Installation Considerations
To maximize the performance in difficult or custom installa- tions, please see your Authorized Rockford Fosgate Dealer. Warning! Please read the entire Installation section before attempting the installation of your Punch Splits Speakers. - Page 8 • Place the speakers where they have a direct path to the listening area. • When using the Punch Splits, there are two options for speaker place- ment between the midrange and tweeter. For the best integration be- tween the midrange and tweeter, the tweeter should be placed less than 2"...
-
Page 9: Mounting The Midrange
Punch Splits speakers with minimum path length differences will ensure the best staging and imaging possible from your audio system. N S TA L L AT I O N The mounting of the Punch Splits speakers and crossovers is just as important as choosing the location for the speakers. -
Page 10: Flush Mounting The Tweeter
5. Place the mounting ring over the hole. 6. Attach the wires and be sure to observe the proper speaker polarity. Keep the speaker wires away from sharp and moving objects. 7. Place the speaker into the hole and screw the speaker into place. Be careful not to bend the speaker frame during this step. -
Page 11: Mounting The Punch Splits Plates
Mounting the Punch Splits Plates 1. Cut the proper size hole for the midrange/woofer and tweeter. The midrange/woofer hole should be slightly larger than the mounting plate woofer hole. 2. Place the mounting plate over the mounting holes and mark the location of the screw mounting holes. - Page 12 Wiring the PCH-314 ® ® ACTIVE TWEETER PROTECTION TX-4186 – + – + Input Protection Output from Amplifier ® (Rear View) (Rear View) – 100 f capacitor – 9 – PCH-14 Dot indicates “+” Terminal Striped Wire PCH-34 Dot indicates “+”...
- Page 13 Wiring the TX-4186 (Crossover/Tweeter Protection) CROSSOVER ® OUTPUT FROM AMPLIFIER • Striped Wire indicates “+” terminal of tweeter Wiring the TX-4186 (Tweeter Protection Only) ® OUTPUT FROM AMPLIFIER • Striped Wire indicates “+” terminal of tweeter • WARNING: Use an external high-pass filter of at least 6kHz @ 18dB when configuring crossover for Tweeter Protection Only Mode TWEETER...
- Page 14 Tweeter Level Matching (Bottom view of PCH-142x/TX-4186 • Factory set tweeter level is 0dB • Cut jumper wire on bottom of crossover to reduce tweeter level by –3dB Horizontal Logo Mounting ® ® ACTIVE TWEETER PROTECTION TX-4186 • Configure logo into desired position and snap into place Vertical Logo Mounting •...
-
Page 15: Troubleshooting
R O U B L E S H O O T I N G Symptom No sound from speakers Tweeters “burn up” easily Distorted sound from speakers Engine Noise from One or More Speakers Diagnosis Wires between amplifier, crossover and speakers not connected properly. -
Page 16: Specifications
– 13 –... -
Page 17: Warranty Information
• Who is Covered This warranty covers only the original purchaser of Rockford product purchased from an Authorized Rockford Fosgate Dealer in the United States. In order to receive service, the purchaser must provide Rockford with a copy of the receipt stating the customer name, dealer name, product purchased and date of purchase. -
Page 18: International Information
– 15 –... -
Page 19: Lugar De Montaje
En los vehiculos de hoy en dia, premia el espacio para todo. Muchas veces, el espacio que los diseñadores de coches dedican al equipo de música es un requerimiento posterior al diseño. Rockford Fosgate sabe que la gente que quiere equipos de música en sus vehiculos, debe pelear con este problema cotidiano. - Page 20 4. Coloque el cable a través del agujero. 5. Coloque el aro de montaje sobre el agujero. 6. Conecte los cables al altavoz observando la polaridad del mismo. 7. Coloque el altavoz en el agujero y atornillelo. Tenga cuidado en no doblar el soporte del altavoz durante este paso.
- Page 21 Conectando el PCH-142x ® Salida del Amplificador • El hilo marcado indica el “+” del tweeter Ajuste de Nivel del Tweeter (Vista inferior del PCH-142x/TX-4186) • El ajuste de origen es –0dB • Corte el hilo en la parte inferior del tweeter para una reduccion del nivel del tweeter de –3dB Conectando el TX-4186 (Crossover/Proteccion de Tweeter)
-
Page 22: Emplacement De Montage
Dans les véhicules actuels, l'espace est primor dial. Dans beaucoup de cas, l'espace dédié au système audio par les fabricants d'automobiles se retrouve au second plan. Rockford Fosgate réalise que les gens qui veulent un système audio dans leur voiture sont confrontés à ce problème. - Page 23 4. Faire passer les fils dans le trou central. 5. Placer l'anneau de montage au-dessus du trou central. 6. Connecter les fils au haut-parleur en respectant les polarités. Eloigner les fils de toute partie tranchante ou mobile du véhicule. 7. Placer le haut-plarleur au-dessus du trou central. Visser le haut- parleur dans son emplacement.
- Page 24 Branchement du PCH-142x ® Sortie de • Le fil marqué indique la connexion “+” du tweeter Compensation du Niveau Aigu Vue d'en bas du PCH-142x/TX-4186 • Le niveau de défaut est de –0dB • Coupez le pontage au verso du filtre our atténuer l'aigu de 3dB.
-
Page 25: Montage
In Fahrzeugen unserer heutigen Zeit ist Platz oft sehr begrenzt. Oftmals sind die vom Werk vorgesehenen Plätze für Lautsprecher sehr unzureichend. Rockford Fosgate hat verstanden, da es für Viele, die eine Stereoanlage im Auto wollen ein gro es Problem ist. Die Lösung dafür ist das Punch Splits Komponenten-System. - Page 26 5. Montieren Sie den Lautsprecherring. 6. Schlie en Sie den Lautsprecher an und achten Sie darauf, da die Polung stimmt. 7. Plazieren Sie den Lautsprecher und schrauben Sie ihn fest. Bitte achten Sie darauf, da Festschrauben nicht verzieht. 8. Pressen Sie das Lautsprechergitter vorsichtig in den Montagering. Hochtöner-Einbaumontage 1.
- Page 27 Verkabelung des PCH-142x ® Ausgang vom Verstärker • das abisolierte Kabel zum “+” Terminal des Hochtöners Tweeter Level Matching (Vorderansicht) • Werkseinstellung Hochtonpegel –0dB • Durch Trennen der Kabelbrücke reduzieren Sie den Pegel des Hochtöners um –3dB Verkabelung des TX-4186 (Frequenzweiche/Hochton Sicherung) Crossover ®...
- Page 28 Negli autoveicoli di oggi non c'é molto spazio. Molte volte i progettisti di automobili si accorgono solo a vettura ultimata che mancano gli spazi per gli impianti stereo. Rockford Fosgate é conscia del fatto che la gente che vuole realizzare degli impianti stereo sulle properie autovetture deve affrontare questo problema.
- Page 29 5. Posizionate la griglia spora il foro dell'altoparlante. 6. Collegate i cavi facendo attenzione alla corretta polaritá. 7. Posizionate l'altoparlante nel foro ed avvitatelo. Assicuratevi di non piegare il cestello dell'altoparlante. 8. Incastrate la griglia sull'anello di fissaggio. Installazione ad incasso del tweeter 1.
- Page 30 Cablare il PCH-142x ® Uscita dell'amplificatore • Il cavo spellato indica il positivo del tweeter Regolazione del livello di emissione del tweeter (Vista Posteriore del PCH-142x/TX-4186) • Il livello preimpostato é –0dB • Tagliare il ponticello accessibile dal foro sul retro del crossover per ottenere un'attenuazione del tweeter di –3dB Cablare il TX-4186 (Crossover/Protezione del tweeter)
- Page 31 OTES...
-
Page 32: Made In The Usa
LIT9781 11/96 MADE IN THE USA Rockford Fosgate Rockford Corporation 546 South Rockford Drive Tempe, Arizona 85281 U.S.A. In U.S.A., (602) 967-3565...
