SPECIFICATION
Input Port
3xHDMI(Female connector)
Output Port
1xHDMI(Female connector), 1xIR Channel
Output Resolution
480i~1080P@50/60,1080P@24/50/60,
VGA~UXGA
Operating Temperature
-15℃~55℃/5°F~131°F
Deep Color
36bit
Chassis
Metal
Dimension
112mm(L)x75mm(W)x24mm(H)
Weight
205g
Power Supply
DC 5V
SAFETY PRECAUTIONS
Please read the following safety precautions carefully before you unpack
and install this equipment.
1.Do not expose the unit to rain, moisture or any other dripping liquids. And
keep it away from any wet locations such as fishing tanks, vases.
2.Do not install the unit close to fire or any other heat sources.
3.Keep the unit in dry and ventilated area. Do not install in bookcase,
cabinet or any other confined space.
4.Stop using the unit during thundering or lightening storms.
5.Avoid the power cable to be stepped on or pinched. Position the unit
carefully to avoid damage or accident.
6.Clean the unit only with dry cloth.
7.Only use accessories specified by the manufacturer.
8.Unplug the equipment when unused for a long period of time.
9.Do not try to open any non-serviceable parts. Contact your authorized
servicing center and personnel.
Keep Away
Keep Dry
from Heat
3x1 HDMI Switcher
Danger Electric
Shock Risk
Full 3D Pass-through
SW31NN00N
User Manual
Advertisement
Table of Contents
Related Manuals for MyCableMart SW31NN00N
Summary of Contents for MyCableMart SW31NN00N
-
Page 1: User Manual
7.Only use accessories specified by the manufacturer. 8.Unplug the equipment when unused for a long period of time. 9.Do not try to open any non-serviceable parts. Contact your authorized servicing center and personnel. SW31NN00N User Manual Keep Away Danger Electric... -
Page 2: Panel Description
INTRODUCTION PANEL DESCRIPTION INSTALLATION HDMI Switcher is designed to make your A/V equipment use more comfortable, Front Panel •Connect HDMI input ports to the signal source equipments such as more productive and less expensive. This 3x1 HDMI Switcher allows your three DVD player, Blue-ray player, Set-top box etc.
