- Page 1 HDMI Switcher 5x1 with 600MHz User Manual...
-
Page 2: Table Of Contents
Contents 1.0 INTRODUCTION --------------------------------------- 1 2.0 FEATURES --------------------------------------------- 1 3.0 SPECIFICATIONS -------------------------------------- 2 4.0 PACKAGE CONTENTS --------------------------------- 2 5.0 CONNECTION ------------------------------------------ 2 6.0 CONNECTION DIAGRAM ------------------------------ 3... -
Page 3: Introduction
HDMI Switcher 5x1 with 600MHz DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. INTRODUCTION This is a high-performance HDMI 5x1 Switcher which not only has the key-press-switching function, but also has intelligent function. -
Page 4: Specifications
SPECIFICATIONS Signal Inputs/Output Input Video HDMIx5 Maximum Single Link Range Full 3D and 4kx2k@60HZ Output Video HDMIx1 Operating Frequency Vertical Frequency Range 24/30/50/60Hz Video Amplifier Bandwidth 6Gbps/600MHz Resolutions(HDTV) Interlaced(50&60Hz) 480i,576i,1080i Progressive(50&60Hz) 480p,576p,720p,1080p,4k*2k@30HZ, 4kx2k@60HZ, Mechanical Size(L-W-H) 80X58X15mm Weight(Net) Warranty Limited Warranty 1 Year Parts and Labor Environmental Operating Temperature... -
Page 5: Connection Diagram
1) Connect the HDMI input source into the HDMI switcher. (Input cables are optional) *Please refer to connection diagram section. 2) Connect the HDMI Display into the output of the Switcher 3) Press the button to select the inputs 4) Insert 5V DC Power Adapter Attention: Insert / Extract cable gently.
