LightRaise™ interactive projector quick connect guide
For more detailed instructions, see the LightRaise interactive projector textless installation guide included with
your projector or download it at smarttech.com/kb/170259.
1. Surface selection
Warp
<5 mm
<5 mm

2. Projector mounting

<10 mm
Tilt
> 4"
(10 cm)
© 2014 SMART Technologies ULC. All rights reserved. LightRaise, smarttech and the SMART
logo are trademarks or registered trademarks of SMART Technologies ULC in the U.S. and/
or other countries.
<5 mm
<5 mm
D max.
(mm)
0–6
7–12
13–19
20–26
27–33
34–39
40–46
47–52
53–60
<5 mm
<5 mm
Diagonal
(170 cm)
Table 1
(173 cm)
# of # of Indicator
shims spacers setting
(178 cm)
0 0 3
(183 cm)
0 0 9
0 0 16
(188 cm)
1 0 10
0 1 10 (193 cm)
0 1 16
(198 cm)
1 1 10
0 2 9
(203 cm)
0 2 16
(208 cm)
(213.5 cm)
Z
(218.5 cm)
(223.5 cm)
(228.5 cm)
Gray area
Y
represents
(234 cm)
"No Fly Zone"
(239 cm)
(244 cm)
(249 cm)
(254 cm)
~
~
120 min.
Table 2
Y
(image height)
67" 35"–36"
(89 cm–91.5 cm)
68" 36"–37"
(91.5 cm–94 cm)
70" 37"–38"
(94 cm–96.5 cm)
72" 38"–39"
(96.5 cm–99 cm)
74" 39"–40"
(99 cm–101.5 cm)
76" 40"–41"
(101.5 cm–104 cm)
78" 41"–42"
(104 cm–107 cm)
80" 42"–43"
(107 cm–109 cm)
82" 43"–44"
(109 cm–112 cm)
84" 44"–45"
(112 cm–114 cm)
86" 45"–46"
(114 cm–117 cm)
88" 46"–47"
(117 cm–119.5 cm)
90" 47"–48"
(119.5 cm–122 cm)
92" 48"–49"
(122 cm–124.5 cm)
94" 49"–50"
(124.5 cm–127 cm)
96" 50"–51"
(127 cm–129.5 cm)
98" 51"–52"
(129.5 cm–132 cm)
100" 52"–53"
(132 cm–134.5 cm)
All dimensions +/- 1/4" (0.5 cm)
smarttech.com/support
smarttech.com/contactsupport
Z
(plate height)
14 1/2"
(37 cm)
14 1/2"
(37 cm)
14 3/4"
(37.5 cm)
15"
(38 cm)
15 1/4"
(39 cm)
15 1/2"
(39.5 cm)
15 3/4"
(40 cm)
16"
(40.5 cm)
16 1/4"
(41 cm)
16 1/4"
(41 cm)
16 1/2"
(42 cm)
16 3/4"
(42.5 cm)
17"
(43 cm)
17 1/4"
(44 cm)
17 1/2"
(44.5 cm)
17 3/4"
(45 cm)
18"
(46 cm)
18 1/4"
(46.5 cm)
1023792 Rev 01
