RunCam Micro Swift
USER MANUAL
Connection
* Unplug the 5D-OSD menu cable after OSD setting.
Dimensions & Installation
Parameters
Model
Image Sensor
Horizontal Resolution
Lens
Signal System
S/N Ratio
Electronic Shutter Speed
Auto Gain Control (AGC)
Back Light Compensation (BLC)
Min. Illumination
WDR
DNR
Day/Night
Power
Net Weight
Dimensions
Transmitter
Power in
GND
UP
L
R
DOWN
5D-OSD menu cable not included
RunCam Micro Swift
1/3" SONY Super HAD II CCD
600TVL
2.1mm Lens(M8)
PAL/NTSC
>60dB (AGC OFF)
PAL: 1/50~100,000; NTSC: 1/60~100,000
Yes
Yes
0.01Lux@1.2F
D-WDR
2DNR
Color/Auto/B&W
DC 5-36V
5.6g
19mm*19mm*19mm
5-36V in
GND
Video out
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for RunCam Micro Swift
Summary of Contents for RunCam Micro Swift
-
Page 1: User Manual
RunCam Micro Swift USER MANUAL Connection * Unplug the 5D-OSD menu cable after OSD setting. Transmitter Power in 5-36V in Video out DOWN 5D-OSD menu cable not included Dimensions & Installation Parameters Model RunCam Micro Swift Image Sensor 1/3" SONY Super HAD II CCD... - Page 2 Camera Menu · MAIN MENU · EXPOSURE SETUP EXPOSURE CAM TITLE SHUTTER AUTO EXPOSURE BRIGHTNESS BACKLIGHT WHITE BAL ATW1 DWDR COLOR DAY＆NIGHT RETURN IMAGE ADJ LANGUAGE ENGLISH RESET EXIT · CAM TITLE (ON/OFF) · SHUTTER (AUTO / 50-100000 / FLK) ·...
