- Page 1 8004576B HDMI DVD Player with USB HDMI 1080p converting DVD/DVD+/-R/ DVD+/-RW/CD/ CD-R/CD-RW/Kodak picture formats Instruction Manual Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.
-
Page 3: Table Of Contents
Contents Important Safety Instructions ............2-5 FCC/ICES-003 . -
Page 4: Important Safety Instructions
Important Safety Instructions The lightning flash with arrowhead symbol within an equilateral CAUTION triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’ s enclosure that may be of RISK OF ELECTRIC SHOCK sufficient magnitude to constitute a risk of electric shock to persons. - Page 5 Important Safety Instructions Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit. For example, this unit may not have the capability to be connected to an outdoor antenna. 1) Read these instructions. All the safety and operating instructions should be read before the product is operated. 2) Keep these instructions. The safety and operating instructions should be retained for future reference. 3) Heed all warnings.
- Page 6 Important Safety Instructions 17) Overloading Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. 18) Object and liquid entry Never push objects of any kind into the product through openings as they may touch dangerous voltage points or short out parts that could result in fire or electric shock. Never spill or spray any type of liquid on the product. 19) Outdoor antenna grounding If an outside antenna is connected to the product, be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges. Section 810 of the National Electric Code ANSI/NFPA 70 provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge product, size of grounding conductors, location of...
- Page 7 Important Safety Instructions NOTES ON MOISTURE CONDENSATION: NOTES ON HANDLING: • Moisture condensation damages the DVD When shipping the DVD player, always use the player. Please read the following carefully. original shipping carton and packing materials. For maximum protection, repack the unit as it • Moisture condensation occurs, for example, when was originally packed at the factory. you pour a cold drink into a glass on a warm day. Drops of water form on the outside of the glass.
-
Page 8: About Discs
About Discs THE REGION NUMBER FOR THIS DVD PLAYER IS: See below for information regarding region numbers. PLAYABLE DISCS: The following discs can be played back on this DVD player: DISC TYPES: Data on most DVDs is divided into sections called titles and then into subsections called chapters, each of which is given a title or chapter number. Some features of this DVD player will not operate with some DVD discs as they are preset. -
Page 9: Product Overview
Product Overview Front View 5. ( ) Open/Close Button 1. ( ) Power ON/Standby Button 6. USB Port 2. Disc Tray 7. ( ) Previous Button 3. Remote Control Receiver 8. ( ) Play/Pause Button 4. LED Display 9. ( ) Next Button Rear View 1. Power Cable to 120 V ~ 60Hz Power Source 5. Left Audio Output Jack 2. -
Page 10: Remote Control Overview
Remote Control 1. ( ) OPEN/CLOSE BUTTON Opens and closes the disc tray. 2. 0-9 BUTTONS To locate a title / chapter / track /specific time or enter parental control. 10+ Button To select and switch to a track that is higher than 10. 3. -
Page 11: Power Button
Remote Control 17. POWER BUTTON Turns the power on or restores the DVD player to standby mode. 18. VOL +/– BUTTONS To increase and decrease volume. 19. MUTE BUTTON To mute and restore your DVD sound output. 20. SETUP BUTTON To access or exit the SETUP menu. -
Page 12: Operating The Remote Control
Operating the Remote Control Battery Installation 1. Press the tabs on the back door and lift off. 2. Insert two AAA size batteries (included) into the battery compartment as shown in the illustration and follow the (+) and (–) polarity symbol markings inside the battery compartment. 3. Replace the battery door. BATTERY PRECAUTIONS: • Improper or incorrect use of batteries may cause corrosion or battery leakage, which could cause fire, personal injury or... -
Page 13: Connections
Connections Connecting To TV Through VIDEO Output Jacks (A/V connection cable included) Yellow Television White Connecting To TV Through Output Jacks (YUV connection cable not included) Yellow Television White... -
Page 14: Connecting To Tv Through 5.1-Channel Output Jacks
Connections Connecting To TV Through Output Jacks 5.1-CHANNEL (5.1-Channel connection cable not included) Yellow Television White Amplifier Center Speaker Right Front Left Front Speaker Speaker Subwoofer Left Surround Speaker Right Surround Speaker Connecting To TV Through HDMI OUTPUT (connection cable not included) Television... -
Page 15: Connecting To Tv Through Coaxial Output Jack
Connections Connecting To An External Audio Amplifier Through Coaxial Output Jack (Coaxial connection cable not included) Yellow Television White (with built-in digital audio recorder) Connecting to USB Port 1. If a disc is loaded, press the DVD/USB button on remote control, “detecting device” and “Waiting” will appear on display, then the USB files will appear. -
Page 16: Operating Systems
Operating Systems Playback of a DVD Unless otherwise stated, all operations described are based on Remote Control use. 1. Insert the AC plug (with the two blades) from the DVD player to a conveniently located AC outlet. The POWER indicator on the front of the cabinet will light. 2. Connect the DVD player to the external TV (see illustrations on pages 11 to 13). - Page 17 Operating Systems OSD (ON SCREEN DISPLAY) During playback, press the OSD button repeatedly to read the information of playback status. ZOOM During the playback of the DVD disc, press the ZOOM button to enlarge or minimize pictures. Each time the ZOOM button is pressed, the picture enlarges in sequence. ANGLE If the multi-angle icon “ ” appears on the screen, it means more than one scene is available on the current DVD. Press the ANGLE button repeatedly to select the desired scenes.
- Page 18 Operating Systems A-B REPEAT Repeat a section between points A and B within a Title / Chapter / Track. 1. Press the A-B button to choose a starting point A. 2. Press the A-B button again to set an ending point B and complete the setting. The selected section A-B will be repeated.
-
Page 19: Playback Of A Cd
Operating Systems Playback of a CD 1. Press the POWER button to turn the player on. OPEN/CLOSE button to open the disc tray. Place the disc in the center of 2. Press the OPEN/CLOSE button. tray with the label side face up. Close the tray by pressing the The unit will start playback automatically. -
Page 20: Jpeg (Picture) Discs Operation
Operating Systems JPEG (picture) Discs Operation 1. Press the POWER button to turn the player on and place the disc into the player as previously instructed. The folder/file list will appear on the screen. 2. Use the , , , direction buttons to highlight the desired folder, then press the ENTER button to confirm. -
Page 21: System Setup
System Setup System Setup NOTE: Preference page can be opened only when no disc is playing. Press the SETUP button, the setting menu will appear on the screen as below. Use the direction buttons , , , to select and highlight the function you need to set or reset. Press the ENTER button to enter or confirm the selection. After setting, press the SET UP button to save the settings and exit. -
Page 22: Dolby Setup Page
System Setup DOLBY SETUP PAGE: 1. If Dual Mono is selected, use the direction and ENTER buttons to set it to Stereo, L-Mono (Play Left channel on all speakers), R-Mono (Play Right channel on all speakers) or Mix-Mono (Mixed Right and Left channel then play on all speakers) as desired. (Functions depend on the recording of the disc). 2. If Dynamic is selected, use the direction and ENTER buttons to set the dynamic level as desired or turn it off. VIDEO SETUP PAGE: ~ Set the component to YUV if the DVD player is connected to Y/PbCb/PrCr jacks. ~ Set the component to Off to shut off the YUV output. ~ Set Resolution to the match the performance of your TV. ~ Set HDMI to On if the DVD player connected to TV through HDMI port. -
Page 23: Care And Maintenance
Care and Maintenance CARING FOR DISCS Treat the disc carefully. Handle the disc only by its edges. Never allow your fingers to contact the shiny, unprinted side of the disc. • Do not attach adhesive tape, stickers, etc. to the disc label. • Clean the disc periodically with a soft, lint-free,dry cloth, Never use detergents or abrasive cleaners to clean the disc. If necessary, use a CD cleaning kit. • If a disc skips or gets stuck on a section of the disc, it is probably dirty or damaged(scratched). • When cleaning the disc, wipe in straight lines from the center of the disc to the outer edge of the disc. Never wipe in circular motions. • Discs should be stored in their cases after each use to avoid damage. • Do not expose discs to direct sunlight, high temperatures or dust, etc. Prolonged exposure or extreme temperatures can warp the disc. • Do not stick or write anything on either side of the disc. Sharp writing instruments, or the ink, may damage the surface. CLEANING THE UNIT • To prevent fire or shock hazard, disconnect your unit from the AC power source when cleaning. -
Page 24: Troubleshooting
Troubleshooting Guide CHECK THE FOLLOWING SYMPTOMS BEFORE REQUESTING SERVICE: PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION No power. AC cord is unplugged. Plug AC cord into an AC outlet. Power is on, but unit Condensation has formed. Unplug the unit and wait about 1-2 hours for unit to dry is not functioning out. -
Page 25: Specifications
Specifications Power Source ..............AC 120 V ~ 60Hz Power Consumption ..........10 W Power Source of the Remote Control ....2 × AAA size batteries (included) Signal System ..............NTSC / PAL Operating Temperature ..........+5°C to +35° C Operating Humidity Range ........5% to 90% (no condensation) DISCS PLAYED: DVD-VIDEO DISC 12cm single-sided, single layer 12cm single-sided, dual layer 12cm double-sided, single layer 8cm single-sided, single layer 8cm single-sided, dual layer 8cm double-sided, single layer COMPACT DISC (VIDEO CD) -
Page 26: Warranty
Imported by: The Source, Barrie, Ontario, Canada, L4M 4W5 Please Recycle Manufactured in China For product support please visit © 2014 The Source www.thesource.ca All rights reserved.
