- Page 1 OWNER'S MANUAL CONDITIONER Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times. TYPE : WALL MOUNTED English www.lg.com MFL69781201 Rev.01_041817...
-
Page 2: Table Of Contents
TABLE OF CONTENTS This manual may contain images or content different from the model you purchased. This manual is subject to revision by the manufacturer. SAFETY INSTRUCTIONS ........... 3 IMPORTANT SAFETY INSTRUCTIONS ..........3 OPERATION ............... 11 Notes for Operation ................11 Parts and Functions ................ -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk. - Page 4 Installation •Do not install the air conditioner on an unstable surface or in a place where there is danger of it falling. •Contact an authorized service center when installing or relocating the air conditioner. •Install the panel and the cover of the control box safely. •Do not install the air conditioner in a place where flammable liquids or gases such as gasoline, propane, paint thinner, etc., are stored.
- Page 5 •Install dedicated electric outlet and circuit breaker before using the air conditioner. •Do not connect the ground wire to a gas pipe, a lightning rod, or a telephone ground wire. Operation •Be sure to use only those parts listed in the service parts list. Never attempt to modify the equipment.
- Page 6 •Do not block the inlet or outlet of air flow. •Do not insert hands or other objects through the air inlet or outlet while the air conditioner is operating. •Make sure that the power cable is neither dirty, loose, nor broken. •Never touch, operate, or repair the air conditioner with wet hands.
- Page 7 Technical Safety •Installation or repairs made by unauthorized persons can pose hazards to you and others. •The information contained in the manual is intended for use by a qualified service technician who is familiar with the safety procedures and equipped with the proper tools and test instruments.
- Page 8 CAUTION To reduce the risk of minor injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following: Installation •Do not install the air conditioner in an area where it is directly exposed to sea wind (salt spray).
- Page 9 Operation •Remove the batteries if the remote control is not to be used for an extended period of time. •Make sure that the filter is installed before operating the air conditioner. •Be sure to check if there is a refrigerant leak after installing or repairing the air conditioner.
- Page 10 Maintenance •Never touch the metal parts of the air conditioner when removing the air filter. •Use a sturdy stool or ladder when cleaning, maintaining, or repairing the air conditioner at a height. •Never use strong cleaning agents or solvents when cleaning the air conditioner or spray water.
-
Page 11: Operation
OPERATION Notes for Operation Suggestion for Energy Saving • Do not cool excessively indoors. This may be harmful for your health and may consume more electricity. • Block sunlight with blinds or curtains while you are operating the air conditioner. •... -
Page 12: Wireless Remote Control
Wireless Remote Control Operating Method Point the remote control towards the signal Inserting Batteries receiver at the right side of the air conditioner to operate it. If the display screen of the remote control begins to fade, replace the batteries. Insert AAA (1.5 V) batteries before using the remote control. - Page 13 Setting the Current Time Operating the Air Conditioner without the Remote Control Insert batteries. You can use the ON/OFF button of the indoor • The icon below blinks at the bottom of the unit to operate the air conditioner when the display screen.
- Page 14 Using Wireless Remote Control You can operate the air conditioner more conveniently with the remote control. Display Description Button Screen To turn on/off the air conditioner. To adjust the desired room temperature in cooling, heating or auto changeover mode. To select the cooling mode. To select the heating mode.
- Page 15 Display Description Button Screen To turn on/off air conditioner automatically at desired time. TIMER SET/ To set/cancel the special functions and CANCEL timer. To cancel the timer settings. CANCEL To adjust time. *LIGHT To set the brightness of the display on the indoor unit.
- Page 16 Display Description Button Screen To purify the air by removing particles that enters the indoor unit. To reduce noise from outdoor units. To keep your skin moisturized by generating ion clusters. To lower indoor humidity quickly. To maintain a minimum room FUNC.
-
Page 17: Restarting The Air Conditioner Automatically
Restarting the Air Conditioner Using the Mode Function Automatically This function allows you to select the desired function. When the air conditioner is turned on again after a power failure, this function restores the Cooling Only Model previous settings. Disabling Auto Restart Cooling Mode Open the front cover (Type2) or horizontal vane (Type1). -
Page 18: Heating Mode
Heating Mode Fan Mode This mode only circulates the indoor air without Turn the appliance on. changing the room temperature. Turn the appliance on. Press MODE button repeatedly to select the Heating Mode. Press MODE button repeatedly to select the •... -
Page 19: Using The Jet Mode Function
Auto Operation (Artificial Using the Jet Mode Function Intelligence) Changing Room Temperature Quickly Cooling Only Model This mode automatically sets the fan speed This function allows you to cool indoor air quickly and temperature depending on the room during the summer or warm it quickly during temperature. -
Page 20: Using The Fan Speed Function
Using the Fan Speed Function Using the Air Flow Direction Function Adjusting the Fan Speed This function adjusts the direction of the air flow • Press FAN SPEED button repeatedly to adjust vertically (horizontally). the fan speed. • Press ) button repeatedly and select SWING SWING the desired direction. -
Page 21: Setting The On/Off Timer
Setting the On/Off Timer Setting the Off Timer This function sets the air conditioner to turn on/ Press button repeatedly. off automatically at desired time. TIMER • The icon below blinks at the bottom of the display screen. Setting the On Timer Press button repeatedly. -
Page 22: Using The Sleep Function (Optional)
Using the Sleep Function Using the Simple Timer (Optional) Function (Optional) This function turns off the air conditioner This function turns off the air conditioner automatically when you go to sleep. automatically when you go to sleep. Turn the appliance on. Turn the appliance on. -
Page 23: Using The Energy Display Function (Optional)
Using the Energy Display Using the Light Off Function Function (Optional) (Optional) This function displays the amount of electricity Display Screen Brightness generated on the indoor display as the product You can set the brightness of the indoor unit operates. display screen. -
Page 24: Using The Energy Saving Function (Optional)
Using the Energy Saving Using the Energy Control Function (Optional) Function (Optional) This function minimizes power consumption Turn the appliance on. during Cooling and increases the set temperature to the optimal level for a more comfortable environment. The temperature Press ENERGY CTRL button. automatically settles at 22 °C if room ambient •... -
Page 25: Using Special Functions
Using Special Functions Display Description Screen Turn the appliance on. To purify the air by removing particles that enters the indoor Press FUNC button repeatedly to select the unit. desired function. To reduce noise from outdoor units. To keep your skin moisturized Press SET/CANCEL button to finish. - Page 26 Canceling Special Functions Using the Silent Function This function prevents potential claims by Press FUNC button repeatedly to select the neighbors, reducing noise from outdoor units. desired function. is displayed on the display screen. • Press SET/CANCEL button to cancel the NOTE function.
-
Page 27: Using The Auto Clean Function
Using the Low Heating Function Using the Auto Clean Function This function operates the heating system to In the Cooling and Dehumidification Mode, maintain a minimum room temperature and moisture is generated inside the indoor unit. This prevent objects in the room from freezing where function removes such moisture. -
Page 28: Smart Functions
• To verify the Wi-Fi connection, check that Wi-Fi icon on the control panel is lit. • LG Smart ThinQ is not responsible for any Create an account and sign in. network connection problems or any faults, malfunctions, or errors caused by network Select Register. - Page 29 Smart Diagnosis™. copyright notices are available for download. Open the LG Smart ThinQ application on LG Electronics will also provide open source the smart phone. code to you on CD-ROM for a charge covering...
-
Page 30: Maintenance
MAINTENANCE WARNING • Before cleaning or performing maintenance, disconnect the power supply and wait until the fan stops. If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition. Clean the product regularly to maintain optimal performance and to prevent possible breakdown. - Page 31 Type Description Interval Air filter Clean with a vacuum or hand wash. 2 weeks Triple filter Clean with a vaccum or brush. Every 3 months 3M filter Clean with a vaccum or brush. Every 6 months Ionizer (Optional) Use dry cotton bud to remove any dust. Every 6 months Clean the Indoor unit surface by using a soft, dry cloth.
-
Page 32: Clean The Air Filter
Clean the Air Filter Push down hooks to assemble the air filter. Clean the air filters once every 2 weeks, or more, if necessary. NOTE • The air filter can be broken when it is bended. • When the air filter is not assembled correctly, Check the side of the front cover for correct dust and other substances come into the assembly of the air filter. -
Page 33: Clean The 3M And Triple Filter (Optional)
Clean the 3M and Triple Filter Insert the 3M and Triple filters. (Optional) Turn off the power and unplug the power Type1 cord. Remove the air filters from the indoor unit. Remove the 3M and Triple filters from the indoor unit. Type2 Type1 Assemble the air filters. -
Page 34: Troubleshooting
TROUBLESHOOTING Self-diagnosis Function This product has a built-in self-diagnosis function. If an error occurs, the lamp of the indoor unit will blink in 2 second intervals. If this occurs, contact your local dealer or service center. Before Calling for Service Please check the following before you contact the service center. - Page 35 Problem Possible Causes Corrective Action • Make sure that there are no curtains, Air is not circulating properly. blinds, or pieces of furniture blocking the front of the air conditioner. • Clean the air filter once every 2 weeks. The air filter is dirty. •...
- Page 36 Problem Possible Causes Corrective Action • Allow the Auto Clean function to The indoor unit is continue since it removes any still operating even The Auto Clean function is remaining moisture inside the indoor when power has being operated. unit. If you do not want this feature, been turned off.
