ACTON BLUETOOTH - STEREO LOUDSPEAKER

USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Acton Bluetooth and is the answer not in the manual?

Questions and answers

Related Manuals for Marshall Amplification Acton Bluetooth

Summary of Contents for Marshall Amplification Acton Bluetooth

  • Page 1: User Manual

    ACTON BLUETOOTH - STEREO LOUDSPEAKER USER MANUAL...

  • Page 2: Legal Notice

    • Marshall, Marshall Amps, their respective logos, “Marshall”, “Marshall” trade dress as well as corporate and product identities used herein, are trademarks and intellectual property of Marshall Amplification PLC and may not be used without permission. • The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Zound Industries International AB is under license.

  • Page 3: Installation & Connection

    INSTALLATION & CONNECTION • Connect the product according to the instructions in this manual. • Connect the product only to the correct mains voltage as shown on the equipment. • Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit the apparatus.

  • Page 4: Ic Statement

    IC STATEMENT This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 5: Table Of Contents

    BOX CONTENTS 008. GENERAL DESCRIPTION 010. PLUGGING IN THE ACTON BLUETOOTH 011. TURNING THE POWER ON/OFF 012. USING THE ACTON BLUETOOTH WITH YOUR DEVICES 013. CONNECTING VIA BLUETOOTH (PAIRING) 015. BLUETOOTH AUTO CONNECTION 016. CONNECTING SOUND SOURCE VIA CABLE 017.

  • Page 6: Box Contents

    BOX CONTENTS 001. QUICKSTART MANUAL AND SAFETY INFORMATION 002. DOUBLE-ENDED COIL CORD WITH 3.5MM STEREO PLUGS TO CONNECT TO YOUR MUSIC PLAYER 001. 002. 006.

  • Page 7: Power Cord

    BOX CONTENTS CONTINUED 003. MARSHALL ACTON BLUETOOTH ACTIVE STEREO LOUDSPEAKER 004. POWER CORD 003. 004. CAUTION LIFT ACTIVE LOUDSPEAKER FROM BOTTOM. DO NOT LIFT BY PROTECTIVE BAG FOR RISK OF DROPPING THE PRODUCT. 007.

  • Page 8: General Description

    GENERAL DESCRIPTION 001. INPUT FOR 3.5MM STEREO PLUG 002. SOURCE INDICATORS 003. VOLUME KNOB 004. BASS KNOB 005. TREBLE KNOB 006. PAIR BUTTON 007. SOURCE BUTTON 008. POWER SWITCH 008.
  • Page 9 GENERAL DESCRIPTION CONTINUED 009. BACKPLATE 010. BASS PORT 011. POWER JACK 012. POWER CORD 009. 010. NOTE: DATE CODE AND SERIAL NUM- BER STICKER LOCATED HERE . 011. 012. 011. 012. 009.

  • Page 10: Plugging In The Acton Bluetooth

    PLUGGING IN THE ACTON BLUETOOTH 001. PLUG THE POWER CORD INTO THE POWER JACK ON THE BACK OF THE ACTON BLUETOOTH. 002. PLUG THE POWER CORD INTO THE WALL SOCKET. CAUTION: ALWAYS UNPLUG THE POWER CORD FROM THE WALL SOCKET BEFORE DISCONNECTING IT FROM THE SPEAKER.

  • Page 11: Turning The Power On/Off

    TURNING THE POWER ON/OFF 001. SWITCH THE ON/OFF SWITCH TO TO TURN ON THE ACTON BLUETOOTH. 002. THE RED BLUETOOTH INDICATOR STARTS FLASHING AS THE SPEAKER SEARCHES FOR A BLUETOOTH DEVICE. 003. TO TURN THE SPEAKER OFF, SWITCH THE ON/OFF SWITCH TO 004.

  • Page 12: Using The Acton Bluetooth With Your Devices

    USING THE ACTON BLUETOOTH WITH YOUR DEVICES THERE ARE MANY WAYS TO CONNECT TO YOUR ACTON BLUETOOTH, WHETHER VIA YOUR PHONE, TV OR WIRELESSLY VIA WIRELESS BLUETOOTH® TECHNOLOGY. BELOW YOU WILL FIND MORE DETAILS ABOUT THE CONNECTION SOURCES: • WIRELESS CONNECTION VIA BLUETOOTH •...

  • Page 13: Connecting Via Bluetooth (Pairing)

    CONNECTING VIA BLUETOOTH (PAIRING) FOLLOW THESE STEPS TO PAIR THE ACTON BLUETOOTH WIRELESSLY TO YOUR BLUETOOTH DEVICE. 001. ENSURE THAT THE SPEAKER IS POWERED ON. 002. PUSH THE PAIR BUTTON. 003. THE RED BLUETOOTH INDICATOR STARTS TO FLASH RAPIDLY. 002.

  • Page 14: Connecting Via Bluetooth

    CONNECTING VIA BLUETOOTH (PAIRING) 004. ENABLE BLUETOOTH FUNCTIONALITY ON YOUR DEVICE. (SMARTPHONE, TABLET, COMPUTER). 005. ON YOUR DEVICE, SELECT ACTON BLUETOOTH FROM THE BLUETOOTH LIST AND ACCEPT PAIRING. 006. THE BLUETOOTH INDICATOR ON THE SPEAKER TURNS TO A STEADY RED AND THE UNITS ARE NOW CONNECTED.

  • Page 15: Bluetooth Auto Connection

    BLUETOOTH AUTO CONNECTION IF A BLUETOOTH CONNECTED DEVICE IS MOVED OUTSIDE THE RANGE OF THE ACTON BLUETOOTH (APPROXIMATELY 10 METRES WITHOUT OBSTACLES), IT IS DISCONNECTED. THE DEVICE IS AUTOMATICALLY CONNECTED AGAIN WHEN IT IS MOVED BACK WITHIN RANGE. THE SPEAKER STORES UP TO SIX DEVICES AND TRIES TO CONNECT TO THE LAST CONNECTED BLUETOOTH DEVICE FIRST.

  • Page 16: Connecting Sound Source Via Cable

    CONNECTING SOUND SOURCE VIA CABLE THERE IS ANOTHER WAY TO CONNECT TO YOUR ACTON BLUETOOTH – THE OLD FASHIONED WAY, USING THE INCLUDED COIL CORD AND THE 3.5MM INPUT. USE THE DOUBLE-ENDED COIL CORD WITH 3.5MM PLUGS TO CONNECT EXTERNAL AUDIO SOURCES.

  • Page 17: Input - 3.5Mm Stereo Plug

    INPUT - 3.5MM STEREO PLUG 001. ENSURE THAT THE ACTON BLUETOOTH IS TURNED OFF. 002. CONNECT THE CORD WITH THE 3.5MM STEREO PLUG TO THE INPUT LABELLED INPUT ON THE SPEAKER. 003. CONNECT THE CORD WITH THE 3.5MM STEREO PLUG TO THE MUSIC PLAYER AND TURN ON THE SPEAKER.

  • Page 18: Choosing Your Source

    CHOOSING YOUR SOURCE THE INPUT SOURCE THAT IS CURRENTLY SELECTED IS SHOWN BY A LIT INDICATOR. TO SELECT A DIFFERENT SOUND SOURCE: 001. PUSH THE SOURCE BUTTON TO CHOOSE YOUR SOURCE AND/OR TO SWITCH BETWEEN CONNECTED SOURCES. 002. A LIT INDICATOR SHOWS WHICH SOURCE YOU HAVE SELECTED. •...

  • Page 19: Adjusting The Volume/Bass/Treble Sound

    ADJUSTING THE VOLUME/BASS/TREBLE SOUND THE ACTON BLUETOOTH HAS THREE KNOBS FOR ADJUSTING THE SOUND: 001. VOLUME KNOB 002. BASS KNOB 003. TREBLE KNOB 001. 002. 003. 001. 002. 003. 019.

  • Page 20: Technical Information

    TECHNICAL INFORMATION SOUND SPECIFICATION • ACTIVE STEREO LOUDSPEAKER WITH BASS REFLEX SYSTEM • DIGITAL CLASS D AMPLIFIER: 2X8W + 1X25W • ¾” DOME TWEETERS: 2X • 4” WOOFER: 1X • BASS AND TREBLE TONE CONTROLS • FREQUENCY RESPONSE: 50 - 20,000Hz +/-3dB •...

  • Page 21: Troubleshooting

    The amplifier is clipping as it Decrease the volume on your THERE IS A has run out of output power. sound source. CRACKLING SOUND Lower the volume or bass on the ACTON BLUETOOTH, see page 021.
  • Page 22 Lower the volume on the ACTON BLUETOOTH. speaker, see page Too much bass/treble on the Lower the bass/treble on the speaker. speaker, see page Move the ACTON BLUETOOTH ERRATIC Interference from another to another spot. electronic device. PERFORMANCE Turn off or move the interfering electronic device.
  • Page 23 FOLLOWING CASES: • WHEN SOME PART OF THE BODY IS IN CONTACT WITH THE RECEIVING/TRANSMITTING SYSTEM FOR THE BLUETOOTH DEVICE OR THE ACTON BLUETOOTH. • ELECTRICAL VARIATIONS DUE TO OBSTACLES IN THE FORM OF WALLS, CORNERS, ETC. • EXPOSURE TO ELECTRICAL DISRUPTIONS FROM DEVICES WITHIN THE SAME FREQUENCY BAND, FOR EXAMPLE MEDICAL EQUIPMENT, MICROWAVE OVENS AND WIRELESS NETWORKS.
  • Page 24 WWW.MARSHALLHEADPHONES.COM 024.
