- Page 1 FloPro™ VS Instructi ons for installati on and use - English Filtrati on pump Translati on of the original instructi ons in french More documents on: www.zodiac-poolcare.com H0589800.B - 2017/03...
- Page 3 • If any safety device is removed, bypassed, or shunted, the warranty will automati cally be void. This also applies if any parts are replaced with parts that are not acquired from an authorized Zodiac parts outlet. • Do not spray insecti cide or any other chemical (infl ammable or non-infl ammable) in the directi on of the appliance, as this may damage the body and cause a fi...
-
Page 4: Table Of Contents
The distributi on or modifi cati on of this document in any way is prohibited, without prior • authorisati on from Zodiac®. Zodiac® is constantly developing its products to improve their quality. The informati on • contained herein may therefore be modifi ed without noti ce. -
Page 5: ❶ Specifi Cati Ons
❶ Specifi cati ons 1.1 I Descripti on FloPro™ VS (with user (without user interface) interface) Ø63/50 mm connectors (x2) Pump bases (x2) Cable gland (x2) Remote user interface kit... -
Page 6: I Technical Specifi Cati Ons
1.2 I Technical specifi cati ons FloPro™ VS Unit Operati ng water temperature 2 to 35°C Operati ng air temperature 2 to 50°C Nominal voltage of motor 230 Vac-50 Hz Motor power - phases 1 Ph Admissible variati on in motor voltage ±... -
Page 7: I Performance Curves
1.4 I Performance curves Manometric head Flow rate... -
Page 8: ❷ Installati On
❷ Installati on 2.1 I Selecti ng the locati on • The pump must be installed: - before the fi lter, a heati ng and/or water treatment system, - at a minimum distance of 3.5 metres from the edge of the pool, to avoid any water being sprayed onto the appliance. -
Page 9: I Hydraulic Connecti Ons
2.2 I Hydraulic connecti ons • Respect the directi on of hydraulic connecti on (see § "1.3 I Dimensions and marking"). • Choose the piping size according to the pool size and in compliance with the hydraulic rules applicable in the country of installati on. -
Page 10: I Electricity Supply Connecti On
2.3 I Electricity supply connecti on • Connect the pump so that the mains power supply is never inadvertently interrupted when a speed is being used. The speeds are monitored and controlled by the user interface or by the external motor controller, and not by the mains power supply (see § "3.4.4 Timers"). •... -
Page 11: I Connecti Ng The User Interface (Depending On The Model)
2.4 I Connecti ng the user interface (depending on the model) 2.4.1 Default user interface connecti on • In order to prevent all risk of electrocuti on, which can result in serious injury or loss of life, check that the appliance has been disconnected from the power supply before performing the following steps. - Page 12 2.4.2 Remote user interface • This interface can be installed in another locati on using the supplied remote interface kit. • In order to prevent risk of electrocuti on, which can result in serious injury or loss of life, check that the appliance has been disconnected from the power supply before performing the following steps.
- Page 13 • Open the electrical compartment in front of the • Disconnect the RS485 terminal board and put it aside. user interface by unscrewing the screw and lift ing the cover. • Unscrew the cap and install a cable gland to pass the •...
-
Page 14: I Connecti On To An External Controller
2.4.3 Opti onal connecti on of an external "on/off " contact • You can connect an external dry contact to acti vate or deacti vate a speed in the case of a backwash or when using a booster pump. • Access the printed circuit board at the rear of the user interface •... - Page 15 2.5.2 Connecti on to AquaLink® TRi • In order to prevent risk of electrocuti on, which can result in serious injury or loss of life, check that the appliance has been disconnected from the power supply before performing the following steps. •...
-
Page 16: ❸ Use
❸ Use 3.1 I Operati ng principle The fi ltrati on pump forms the core of the pool and is essenti al as it is used to circulate water through the pool’s diff erent components, in parti cular the fi lter. Its motor drives the turbine in rotati on, which drives the water. -
Page 17: I Operati On
3.3 I Operati on • To prevent against any risk of explosion that may cause material damage, serious injury or even death, make sure that the hydraulic circuit is free of any debris or blockage and is not subject to excessive pressure. •... - Page 18 3.4.4 Timers • To prevent against any risk of material damage or injury, you are strongly encouraged to use the "Timers" when the pump is not managed by an external controller, in order to ensure that no speed is running in the event of a general power cut. •...
-
Page 19: I Additi Onal User Functi Ons (Model With Interface Only)
3.5 I Additi onal user functi ons (model with interface only) To access the user menu when the pump is off , press and hold for 5 seconds: Use the keys to browse the menu. To exit the menu, press the key or refrain from performing any acti ons for 1 minute. -
Page 20: I Additi Onal Functi Ons For Professionals Only (Model With Interface Only)
3.6 I Additi onal functi ons for professionals only (model with interface only) To enter the service menu, the pump must be stopped. Press and hold at the same ti me for 5 seconds: Use the keys to browse the menu. To exit the menu, press the key or refrain from performing any acti ons for 1 minute. -
Page 21: ❹ Maintenance
❹ Maintenance 4.1 I Winterising • The frost protecti on functi on is only designed to protect the appliance and pipework during short periods of subzero temperatures. It acti vates the fi ltrati on pump and circulates water to prevent freezing inside the appliance. The frost protecti on functi on does not guarantee protecti on during extended periods of subzero temperatures or power cuts. -
Page 22: ❺ Troubleshooti Ng
❺ Troubleshooti ng • If a problem occurs, before you contact your retailer, please carry out these few simple checks using the following tables. • If the problem conti nues, contact your retailer. • : Acti ons to be performed by a qualifi ed technician only 5.1 I Appliance behaviour •... - Page 23 Votre revendeur Your retailer Modèle appareil Appliance model Numéro de série Serial number Trouvez plus d’informations et enregistrez votre produit sur More informations and register you product on www.zodiac-poolcare.com ZODIAC® is a registered trademark of Zodiac International, S.A.S.U., used under license.
