Power Supply Notes; Amplifier Max. Remote Outlets; Notes - PROception proLINK22 Supplementary Installation Instructions

Power supply notes

■ The proLINK22 itself is always powered from the Sky box , via the I/O cable.
■ An additional power unit is only required where necessary to power a distribution
amplifier – see the table below and the application example diagrams in the
proLINK22 instruction leaflet.
Amplifier
None
proAMP12R
proAMP24R
proAMP26R
proAMP28R
proAMP104X
proAMP310X
proMHD14R

Notes

1. Assumes that the main TV is connected via HDMI and does not require an RF feed.
The no. of remote outlets can be increased to three using an additional splitter (see
proLINK22 instruction leaflet).
2. Connect proPSA125 power adapter to the proLINK22, not to the proAMP104X.
3. Use either a proPSA125 power adapter connected to the proAMP310X or a
proPSU112X connected in-line between the proLINK22 and the UHF input of the
proAMP310X.
